Promax DT-800 User manual

DT-800 CONTROL MODULE
DIGITAL TV HEADEND
- 0 MI1787 -
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com

SAFETY NOTES
Read the instruction manual before using the equipment, mainly "SAFETY
RULES" paragraph.
The symbol on the equipment means "SEE USER’S MANUAL". In this manual
may also appear as a Caution or Warning symbol.
Warning and Caution statements may appear in this manual to avoid injury
hazard or damage to this product or other property.

English
CONTROL MODULE. DT-800
TABLE OF CONTENTS
1. GENERAL..................................................................................................................1
1.1 Description ..........................................................................................................1
1.2 Specifications ......................................................................................................1
2. SAFETY RULES........................................................................................................3
2.1 General................................................................................................................ 3
2.2 Descriptive Examples of Over-Voltage Categories .............................................4
3. INSTALLATION ......................................................................................................... 5
3.1 DT-900 Sub-rack ................................................................................................. 5
3.2 Instalación de los módulos en el DT-900. ...........................................................7
3.3 Connecting wires.................................................................................................7
3.4 Instruccions for installation................................................................................10
4. INSTRUCCIONES DE UTILIZACIÓN...................................................................... 11
4.1 Description of the Controls and Elements.........................................................11
4.2 Arrows and Function Keys Description .............................................................12
4.3 LEDs Table........................................................................................................13
4.4 DT-800 Starting Up ...........................................................................................13
4.5 Main Screen ...................................................................................................... 14
4.6 PASSWORD .....................................................................................................16
4.7 CONFIGURATION ............................................................................................ 17
4.7.1 Description of the initial setup screen .........................................................17
4.7.2 Browsing the SETUP menu ........................................................................ 18
4.7.3 Entering, Editing and Selecting values .......................................................19
4.7.4 DT-800 Configuration.................................................................................. 21
4.8.2 PkUpdate .................................................................................................... 25
5. PRACTICAL EXAMPLES OF SYSTEMS DTTV .....................................................27
6. GLOSSARY OF TERMS .........................................................................................31
7. MAINTENANCE.......................................................................................................35
7.1 Cleaning Recommendations .............................................................................35

CONTROL MODULE. DT-800

English
CONTROL MODULE. DT-800
04-2012 Page 1
CONTROL MODULE
DT-800
DIGITAL TV HEADEND
1. GENERAL
1.1 Description
The DTTV system (Digital to TV) is based on a TV headend that receives
television signals from different sources. It processes them for its integration into an
output signal in Digital Terrestrial (DVB-T) format.
In this way, the signal can be distributed on a TV network with multiple receivers,
keeping the original wiring installation but distributing in high-quality format. This system
is applicable to hotels, hospitals, shopping centers, universities, etc. that is, local
distribution networks that want to distribute content in digital quality.
DT-800 is the control and power module, therefore is the most important module
of the DTTV system. The DT-800 controls the DTTV headend, which would be made up
to a maximum of seven modules. Two cable bus connect the control module to the
other modules of the headend. The DT-800 allows individual control and configuration
of each module.
The user can manage the DT-800 in two different ways: in local mode or in
remote mode. In local mode, the module is managed via the keypad and the LCD
screen placed on the frontal. In remote mode, the control module is connected to a
computer through a network cable and is managed by using the specific software
control (RM).
1.2 Specifications
MODULE
Control/Power Up to 7 modules DT-XXX.
Auto-config Auto-detection of connected modules.
Auto-link Auto-detection of interconnection between
modules.
Local Interface LCD screen.
Navigation keypad (6 keys).
2x information LEDs: Line On/Error.
Intuitive Navigation Menu (tree type menu).

CONTROL MODULE. DT-800
Page 2 04-2012
COMMUNICATIONS
Ethernet 10/100Mb. Via virtual serial port.
MODULES CONFIGURATION
Local Through local interface.
Remote Through Ethernet port (PC software supplied).
POWER SUPPLY
Network voltage 90 - 250 V AC
Network frequency 50 - 60 Hz.
Consumption 6 A / 3A maximum for a range lower / higher at
the input voltage.
Output Connector JST B08P-XL-HDS.
Amount 2
Output voltage +12 V, 10 A max.
+5 V, 14 A max.
OPERATING ENVIRONMENTAL CONDITIONS
Altitude Up to 2000 m
Temperature range From 5°C to 50°C
Max. Relative humidity 80% ( 31 °C), decreasing lineally up to 20% to
50 °C.
MECHANICAL FEATURES
Dimensions W. 50 x H. 262 x D. 230 mm.
Weight 1.85 kg.
ACCESORIES SUPPLIED
1 x CA005 Mains cord.
1 x CC043 Cable Alim. 3 mod.
1 x CC044 Cable Alim. 4 mod.
1 x 0 MI1787 Manual de Instructions DT-800.
OPTION
OP-800-P Power Option.
Output voltage +12 V, 18 A max.
+5 V, 14 A max.
RECOMMENDATIONS ABOUT THE PACKING
It is recommended to keep all the packing material in order to return the
equipment, if necessary, to the Technical Service.

English
CONTROL MODULE. DT-800
04-2012 Page 3
2. SAFETY RULES
2.1 General
* The safety could not be assured if the instructions for use are not closely
followed.
* Use this equipment connected only to systems with their negative of
measurement connected to ground potential or isolated from the network.
* This is a Class I equipment, for safety reasons plug it to a supply line with the
corresponding ground terminal.
* This equipment can be used in Overvoltage Category II installations and
Pollution Degree 1 environments.
* When using some of the following accessories use only the specified ones to
ensure safety.
Power cord.
* Observe all specified ratings both of supply and measurement.
* Remember that voltages higher than 70 V DC or 33 V AC rms are dangerous.
* Use this instrument under the specified environmental conditions.
* The user is not allowed to perform changes inside the equipment. Any change
on the equipment must be done exclusively by specialized staff.
* When using the power adaptor, the negative of measurement is at ground
potential.
* Do not obstruct the ventilation system of the instrument.
* Use appropriate low-level radiation cables for Input / output signals, especially
on high level signals.
* Remote configuration cables <3m.
* Follow the cleaning instructions described in the Maintenance paragraph.

CONTROL MODULE. DT-800
Page 4 04-2012
* Symbols related with safety:
2.2 Descriptive Examples of Over-Voltage Categories
Cat I Low voltage installations isolated from the mains.
Cat II Portable domestic installations.
Cat III Fixed domestic installations.
Cat IV Industrial installations.

English
CONTROL MODULE. DT-800
04-2012 Page 5
3. INSTALLATION
3.1 DT-900 Sub-rack
The DT-900 is a metallic casing (sub-rack), where the DTTV modules are
installed (Fig. 1).
Supplied accessories allow the subrack to be set up in two ways: Installing it in a
19 " rack cabinet (Fig. 2) or anchoring it on a wall.
The wall anchoring system allows, through a tilting system, accessing the rear of
the subrack, where the connectors are placed (Fig. 3).
One subrack can contain up to 8 modules. One of them must be the control
module DT-800.
The sub-rack DT-900 is supplied with an user’s manual, which describes in detail
the steps to complete the assembly.
Figure 1.- Subrack Assembly DT-900.
