PROmedilux PMX2A User manual

PROmedilux
USER MANUAL
Air Purifier PMX2A
KEY FEATURES:
 Destro s microorganisms such as bacteria, fungi, easts and
viruses, including the CORONAVIRUS!
 Closed-t pe device suitable for public places with frequent
movement of persons.
 Safet pin that automaticall turns off the device when the cover
is opened.
 Incredibl low noise due to its special fans.
 2x filter prevents from UV discharge lamp soiling, provides
additional air purification, and prevents from UV radiation leakage.
 LED status and the need of UV discharge lamp replacement
notification.
 Multi-functional mounting: wall-mount or desktop use.

IMPORTANT WARNING!
Read the safety features and this user manual carefully before
installing and connecting the device to power.
SAFETY FEATURES
The following safety features must be observed during device’s
use, operation and maintenance. Failure to comply with the safety
features in this manual may cause serious damage of the device,
its parts or accessories.
Do not use the device in explosive environment
Do not power up the device in the environment with flammable
gases and smokes. Do not use any electronic devices in such
environment due to the possible danger of explosion.
Water, humidit and heat
Do not use the device near water or in a high humidity
atmosphere, where condensation of water may occur inside the
device. Do not expose the device to rain. It can cause an electric
shock or a fire! Never install the device near a source of heat or
hot air. During installation, ensure that there is an access of air to
the device and the ventilation openings are not covered.
Powering up the device
To power up the device, use the original power cable. Wait for at
least 10 minutes after unpacking until the device’s temperature
adjusts to the temperature of the environment. The purifier is
protected with safety class 1 with IP20 protection. Operating
personnel must be informed about the characteristics and the
impact of the UV C ultraviolet radiation on the human being.

1. Air disinfection - use
The Air Purifier is designed for disinfection of interiors such as
hospitals, doctors’ and vets’ practices, cleaning rooms, offices
with or without AC units, food processing factories, storage rooms
and public places with frequent movement of persons. The
disinfection is achieved by forced air circulation through the
chamber with UV discharge lamps. The device is designed the
way that the radiation does not get out of the discharge lamp
chamber. So called germicidal radiation, that is ultraviolet radiation
of the UV C spectrum with a wavelength below 320 nm, is used
for disinfection. Air disinfection is accomplished by performing of
this spectrum on microorganisms that are present in the air. It is
used everywhere, where the disinfection of the environment using
ordinary methods is not possible.
2. Air purifier installation
During air purifier installation, consider natural air circulation in a
room and place it the way that there are no barriers around, which
would block getting sufficient amount of air circulation. Air purifier
can be installed on the wall with two screws introduced through
holes on the rear side. Second option is an installation on the
stand with four supplied screws. In this case, you can easily put
air purifier on the table or other surface. For stand installation, a
PH1 screwdriver is needed.

3. Microprocessor control unit description, LED and RESET
Air purifier is equipped with a
microprocessor control unit, which
manages correct operation of the
whole device, air circulation and
calculates runtime of the discharge
lamps. On the side, there are OK and
SERVICE LED indicators, RESET
button and the main switch. After
turning on the main switch, fans will
start running and the green OK LED
indicator will light up. This means that
the device is working correctly. Red
SERVICE LED indicator will start
flashing 500 hours before the
discharge lamp lifetime ends. After
the lifetime ends, the red LED will be
on permanently.
4. Replacing UV discharge lamp
You need to replace UV discharge lamps after their lifetime has
ended. Even though they seem to light with the same, standard
color, the intensity of the ultraviolet UV C element is significantly
lower.
It is possible to open the device only when it is disconnected from
the power source. Unscrew the top cover and remove it. Eject the
discharge lamp from its base and remove it from the holder. Install
new discharge lamps in the reverse order mentioned before. We
recommend original OSRAM tubes of type HNS – see specification
in the technical specifications section. When closing the device,
ensure that the cover fits the device’s body and there is no gap
that could cause UV radiation leakage. Counter must be reset
after the replacement. Turn on the main switch and hold the reset
button pressed for at least 5 seconds using a thin object. The red
SERVICE LED will switch off. Malfunctioning or broken tubes must
be disposed as electronic waste.

5. Maintenance
Air purifier requires regular maintenance. Remove the dust or
other dirt using non aggressive cleaning aid. For correct
functioning of the emitter it is necessary to keep the tube clean
and monitor its lifetime. If the emitter is not supplied with a
programmable time switch with runtime counter, an operation log
must be provided to keep track of the UV C supply status at all
times. In case of any doubts, its efficiency must be checked by
measuring the intensity of the UV radiation.
6. Prevention from harmful effects of the UV-C radiation
UV C radiation has harmful effect on a human being depending on
the intensity and the time of exposure. When it comes to a
contact with eye, radiation can cause conjunctivitis. UV C
radiation is aggressive and harmful for humans, animals and
plants.
7. Description of PURITEC® HNS® discharge lamp
OSRAM PURITEC® HNS® are low pressure discharge lamps, which
emit short wave ultraviolet radiation. They are very environmentally
friendly, and they are a great alternative to chemical cleaners. Their
radiation effectively destroys cells and it is perfect for high
effective cleaning of water, air and surfaces while eliminating the
necessity to use chemical cleaners.
Operational principle of an UV C discharge lamp:
UV C radiation has photolytic effect on the DNA of microorganisms
like bacteria, molds, yeasts and viruses causing them to be
incapable to replicate. Cleaning effect is achieved by light of a
wavelength under 320 nm, with optimal effect at 260 nm. HNS
germicidal discharge lamps emit UV light with a wavelength of 254
nm – that is approx. 85% of the optimal effect and are ozone free.

HNS® discharge lamps do not generate ozone:
Main lines of the mercury discharge spectrum appear at 254 nm
and 185 nm. Ultraviolet light with lower wavelength below 240 nm
creates ozone. Discharge lamp housing is made of fused quartz,
which eliminates radiation below 240 nm. The discharge lamp
emits radiation, which destroys microorganisms, but does not leak
radiation that generates ozone.

8. Technical specifications:
Type: PROmedilux PMX2xx
Operation voltage: 230V/50Hz
Protection: IP20
Working environment according to IEC 60364 5 51: AB5
indoor environment with a temperature of 5 – 40 ºC
absolute humidity 1 – 25 g/m
3
relative humidity 5 – 85%
Airflow: 57 m
3
/hr
Noise level: <20 dB
Dimensions: 600 x 150 x 70 mm
Color: white RAL7035
Weight: 3.9 kg
Input power (according to the version):
PMX2A36 < 45 W
PMX2A48 < 55 W
UV C radiation supply (according to the version):
PMX2A36 OSRAM HNS L 18 W 2G11 or compatible
PMX2A48 OSRAM HNS L 24 W 2G11 or compatible
9. Icon explanation
General warning: Warns the user about the presence of
important operational and maintenance instructions in the
documentation attached to the device.
Dangerous voltage: Warns the user about the presence of
non isolated dangerous voltage inside the device, which
can cause electric shock.
Warning: UV C radiation is the strongest UV radiation – its
wavelength is below 280 nm. The UV C radiation
penetrates deeply into the fiber and it is harmful for living
organisms.
Crossed dust bin symbol means that the product or its
components cannot be disposed with domestic waste.
They must be disposed as electronic waste.

10. USER WARNING
During operation with the device, it is necessary to comply with the STN
343108 68 regulations, which contain safety regulations about handling the
electronic equipment by persons without electrotechnical qualification – see
more in the regulation No. 508/2009 of the Collection of Law of the Slovak
Republic.
Before any interference with the device or the device maintenance, it is
necessary to disconnect the device from the power supply.
The device can be plugged only to correctly installed electrical system with
correct fusing that complies with lawful regulations and norms. It is
dangerous to modify the device in any way.
Failure to compl with the listed warnings can cause electric shock or
damage of the device.
Classification of the PURITEC® HNS® discharge lamps according to IEC / EN
62471 (photo-biological hazard): hazard group 3
PURITEC® HNS® discharge lamp radiation poses a health risk. It can cause
conjunctivitis and er thema (sun burn) after a short exposure. Skin and e es
must be protected against direct discharge lamp radiation!
UV-C discharge lamps cannot be used for general lighting!
