Prorack K372 Operation and installation manual

K372
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 4 x 4 x 2 x 2
x 4 x 4
Revision No: 9D 1

Fitting Kit K372
MAX kgs (lbs)
W/P WHD
Citroen
C3 Panoramic Window, 5dr Hatch 09-16 EU 70 kgs (154 lbs) 70 kgs (154 lbs)
C3 Panoramic Window, 5dr Hatch 10-+ NZ 70 kgs (154 lbs) 70 kgs (154 lbs)
C3 Panoramic Window, 5dr Hatch 10-14 AU 70 kgs (154 lbs) 70 kgs (154 lbs)
2

Fitting Kit K372
X
A B C 1 2 3
C3 Panoramic Window, 5dr Hatch 09-16 (EU) -70mm 610mm - 730mm 695mm -
-2 -3/4ths" 24" - 28 3/4ths" 27 3/8ths" -
C3 Panoramic Window, 5dr Hatch 10-+ (NZ) -70mm 610mm - 730mm 695mm -
-2 -3/4ths" 24" - 28 3/4ths" 27 3/8ths" -
C3 Panoramic Window, 5dr Hatch 10-14 (AU) -70mm 610mm - 730mm 695mm -
-2 -3/4ths" 24" - 28 3/4ths" 27 3/8ths" -
3

Fitting Kit EN
K372
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
●Use keys to remove covers.
4

Fitting Kit EN
K372
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
●Adjust crossbar in or out to suit vehicle.
Refer to the crossbar instructions for
crossbar adjustment.
●Attaches to factory-fitted mounting points
●Please check the front of this manual for
information relating specifically to your
vehicle.
5

Fitting Kit EN
K372
●Tighten adjusting screw to 5 Nm (3.7 ft lb)
hand tight.
●Remove plastic clamp block by gripping bar
leg with fingers and push firmly with
thumbs until clamp block drops out behind
leg.
●Select plastic internal block (from fitting kit)
and insert into foot.
●Repeat for all legs.
6

Fitting Kit EN
K372
●Refer to the underside of the pad for the
part number.
●It is important to put the pads in the correct
position on the vehicle.
●Letters refer to the pad part numbers and
position.
●Pad Part Number:
A = 11-04-229
B = 11-04-230
●Fit rubber pads (supplied with fitting kit) to
foot. Pad may vary in shape to that shown.
●Make sure the pad fits into the holes
underneath the foot.
7

Fitting Kit EN
K372
Fitment
●Open or remove fixed-point covers.
●Select four clamps and fit them to the
inside of the fixed-point mounts on the
vehicle.
●Repeat for all four positions.
●Mount crossbars over clamps.
●Ensure the pads are in the correct position
and the clamp threads pass through the
crossbar feet.
8

Fitting Kit EN
K372
●Place washer over clamp thread as shown.
●Ensure that tab is inserted into clamp
block.
●Tighten the plastic knob. The side with the
nut showing should be facing up.
●Ensure the plastic knob is in the position
shown when fully tightened.
●Repeat for all legs.
9

Fitting Kit EN
K372
●Check crossbar is securely attached to the
vehicle.
●Use keys to fit and lock covers
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
10
