protech QM7410 User manual

1.Description
Compact Non-Contact Thermometer
QM7410
User Manual
Thank you for purchasing the QM7410. This product is capable of non-contact (infrared)
temperature measurements at the touch of a button. The built-in laser pointer increases target
accuracy while handy push-buttons combine for convenien , ergonomic operation. The QM7410
can be used to measure the temperature of objects with a surface that cannot be measured by
traditional contact thermometers. Proper use and care of this meter will provide years of usage.
2.Features
• Rapid Detection Function
• Precise Non-Contact Measurements
• Single Laser Sighting
• Unique Flat Surface, Modern Housing Design
• Automatic Data Hold
• “MAX/MIN” Function
3.Wide Range Application
Food preperation, safety and fire inspectors, plastic molding, asphalt, marine, screen printing,
measure ink and dryer temperature, HVAC/R, diesel and feet amaintenance, etc.
4.Safety
• Use extreme caution when the laser beam is turned on.
• Do not let the beam shine onto your or others eyes.
• Be careful not to let the beam reflect off of a surface and into your eyes.
• Do not allow the laser light beam impinge on any gas which can explode.
5.Distance & Spot Size
6.Specifications
Temperature Range: -50 to 500°C (-58 to 932°F)
D:S: 12:1
Display Resolution: 0.1°C (0.1°F)
Emissivity: Fixed at 0.95
Accuracy: ±3°C (5.4°F) at -50 to 20°C (-58 to 68°F),
±2.0% ±2°C (3.6°F) at 20 to 500°C (68 to 932°F)
Repeatability: ±1°C (1.8°F)
Response Time: 500ms
Spectral Response: 8~14um
Over Range Indication: LCD will show “----”
Diode Laser: Output <1mW; Wavelength 630~670nm; Class 2 laser product
Operating Temperature: 0 to 50°C (32 to 122°F)
Storage Temperature: -10 to 60°C (14 to 140°F)
Relative Humidity: 10% to 90%RH operating; <80%RH storage
Power: 9V Battery (Included)
Note:
Field of View: Make sure that the target is larger than the units spot size. The smaller the
target, the closer you should be to it. When accuracy is critical, make sure the target is at
least twice as large as the spot size.
7.Panel Description
1-Laser
2-Infrared Sensor
3-Display Screen
4-°C/°F Button
5-Laser/Backlight Button
6-Max/Min Button
7-Power On/Measure Button (Automatic switch off after 10 seconds)
8-Battery Cover
ATTENTION
LASER RADIATION
DO NOT STARE INTO THE BEAM
LASER DIODE
Wavelength 630-670nm
Max. output power: <1mW
CLASS2 LASER PRODUCT EN 60825-1:2014
Distance : Spot = 12:1
0.5in@6in 1.0in@12in
12.5mm@152mm
25mm@305mm
6
7
1
2
3
4
5
8
Distributed by:
Reduction Revolution Pty Ltd
www.reductionrevolution.com.au

8.LCD Interface Instruction
1-Scan Symbol
2-Measure Data
3-Temperature Value for Max/Min
4-Data Hold Symbol
5-Laser on Symbol
6-Buzzer Symbol
7-Lower Power Symbol
8-°C/°F Symbol
9.Measurement Operation
1.Hold the meter by its Handle Grip and point it toward the surface to be measured.
2.Pull and hold the Trigger to turn the meter on and begin testing. The display will light if the battery is good.
Replace the battery if the display does not light.
3.Release the Trigger and the HOLD display icon will appear on the LCD indicating that the reading is being held.
In HOLD status, press the laser button to turn on or off the laser. And press the buzzer button to turn on or off
4.The meter will automatically power down after approximately 10 seconds after the trigger is released.
Switching °C/°F
Short press the °C/°F button
Switching Max/Min
Press the Max/Min button.
Switch ON/OFF Laser and Backlight
• Push the Laser/ Backlight button once to turn on the laser pointer .When the laser is on the laser icon will appear
on the LCD over the temperature.
• Short press the Laser/ Backlight button to turn on/turn off the l backlighting .
• Long press the Laser/ Backlight button to turn on/ turn off the laser.
10.Battery Replacement
• As battery power is not sufficient, LCD will display the lower power symbol,
replacement with one new battery type 9V is required.
• Open battery cover, then take out the battery from instrument and replace
with a new 9-volt battery. Then replace the battery cover.
1
2
3
4 5 6 7
8
9V Battery
the backlight.
