Proxim TeraOptic 4221e User manual

Description
The TeraOptic 4221e is the latest in a line of high-bandwidth, carrier-grade systems developed
by Proxim. It is unique among our solutions in that it operates via free-space optics and thus
does not use radio frequency. The system is a cost-effective solution for high-bandwidth
connectivity at ranges less than one kilometer, and is ideal for deployments such as mobile
wireless backhaul, single customer access, multi-tenant building access, enterprise E1/T1, Fast
Ethernet extension and LAN-to-LAN or campus connectivity.
Key Features
• Designed for outdoor installations providing bandwidths of 125 Mbps independent of
transport protocol
• Ideal for dense metro deployments in the range of 20 meters to 1 kilometer
• Operates at a wavelength of 850 nm and is completely eye-safe, with a Class 1 IEC/CDRH
rating, which means no warning labels or access restrictions are required
• License-free operation worldwide eliminates the need for spectrum licensing or
frequency planning
• Provides reliable performance using high-performance lasers with a mean time between
failures (MTBF) of one million (1,000,000) hours
• Lightweight, advanced industrial design includes an integrated optcalscope for ease of
alignment and high/low power settings for optimized performance
• Design includes advanced laser delivery technology which maximizes availability while
maintaining eye safety
• Includes built-in management functionality using Simple Network Management Protocol
(SNMP) version 1
• Power supplies and power cords included
TeraOptic™4221e
Free-Space Optics Solution
TeraOptic 4221e
High-Capacity Wireless Backhaul
Proxim Wireless offers extremely reliable,
secure and easily-deployed solutions for
interconnecting corporate and
telecommunications networks.
This portfolio includes:
• GigaLink®– Alternative to fiber, up to a
Gigabit speed
• Lynx.GX®– Cellular voice and data
backhaul, up to DS3 interface
• Tsunami.GX®- Carrier-class IP
Ethernet bridge for voice and data
backhaul for service providers and
enterprise applications
• TeraBridge™– Ethernet backhaul or
traditional telecommunications converged
voice and data networks
• QuickBridge®– Complete “hop-in-a-
box” Ethernet bridge for campus and
small business networks
Proxim Wireless is a global provider in scalable
broadband wireless networking. From Wi-Fi to
wireless Gigabit Ethernet – our WLAN, mesh,
point-to-multipoint and point-to-point products
are available through our extensive global
channel network.

TeraOptic 4221e
Technical Specifications
850 nm
6 mrad
20 mW / 40 mW
3.14 in (80 mm)
6 mrad
VCSEL
Silicon APD
65.6 ft to 0.62 mi (20 m to 1 km)
40 dB @ 20 meters
16 dB @ 500 meters
10 dB @ 1,000 meters
125-Mbps, Duplex MMF, 1325 nm, SC connector
IEEE 802.3 100Base-FX, Duplex MMF, 1325 nm, SC connector
IEEE 802.3 10/100Base-T, RJ-45
Three-Way, 10 to 16-AWG Terminal Block
Laptop-based software provided
UL60950
cUL - CSA C22.2 No. 60950
CE - IEC60950
CDRH - Class 1 (21 CFR 1040 per Laser Notice No. 50)
IEC - Class 1 (60825-1, Amendment 2 (2001-01)
FCC - Class A, Title 47, Vol. 1, Part 15
CE - EN55022
CE - EN55024
-40 to -57 VDC
75 Watts
1.5 Amps at -48 VDC
100 to 230 VAC, 50/60 Hz
60 Watts
0.6 to 0.26 Amps
16.2 x 10.9 x 6.5 in (412 x 277 x 165 mm)
12.8 lbs (5.8 kg)
-40°C to 55°C
-45°C to 60°C
Up to 95%, non-condensing
19 x 14.5 x 14.5 in (483 x 368 x 368 mm)
20.5 lbs (9.3 kg)
• TeraOptic 4211e Transceivers (Qty 2)
• Outdoor Mounting Kit, 4 to 4.5 in pole (Qty 2)
• Alignment Tools and Mount (Qty 2)
• CD and Manual (Qty1)
FSO PERFORMANCE
NOMINAL WAVELENGTH
FWHM DIVERGENCE
AVERAGE/PEAK
OUTPUT POWER
APERTURE DIAMETER
FULL FIELD OF REGARD
LASER TYPE
DETECTOR
OPERATING RANGE
MINIMUM TO MAXIMUM
CLEAR AIR MARGINS
INTERFACES
DATA
MANAGEMENT
INSTALLATION
POWER
MANAGEMENT
INSTALLATION TOOLS
COMPLIANCE
ELECTRICAL
LASER SAFETY
ELECTROMAGNETIC
POWER
INPUT VOLTAGE
MAX POWER
CONSUMPTION
MAX INPUT CURRENT
OUTDOOR POWER
MODULE
INPUT VOLTAGE
MAX POWER
CONSUMPTION
MAX INPUT CURRENT
DIMENSIONS
WEIGHT
ENVIRONMENTAL AND
MECHANICAL
TEMPERATURE
OPERATING
STORAGE
RELATIVE HUMIDITY
DIMENSIONS
WEIGHT
PACKAGE CONTENTS
TERAOPTIC 4221E
Proxim Wireless Corporation
www.proxim.com
For detailed technical specifications, please go to http://www.proxim.com/products/bwa/point/
©2006 Proxim Wireless Corporation. All rights reserved. Proxim is a registered trademark and the Proxim logo and TeraOptic are trademarks of Proxim Wireless
Corporation. All other trademarks mentioned herein are property of their respective owners. Specifications are subject to change without notice.
DS_0806_TO4221E_US
APPLICATIONS
•Point-to-point Wireless Bridge
•Enterprise LAN and PBX extension
•WAN connection redundancy
•ISP remote POP
•ISP direct customer connections using
point-to-point
•Extension of an existing fiber network
