Proximus AirVolt P16-41459 User manual

AirVolt - P16-41459
User’s Manual
Ages
14+
and up
3CH Mini Indoor Helicopter w/ Gyro

2
What’s in the Box................................................................................................... 3
Helicopter Part LIst ................................................................................................ 4
Installing the Batteries ........................................................................................... 5
Charging the Helicopter......................................................................................... 6
Pre-Flight ............................................................................................................... 7
Troubleshooting ..................................................................................................... 9
Care & Maintenance ............................................................................................ 10
FCC Information .................................................................................................. 10
TABLE OF CONTENTS

3
WHAT’S IN THE BOX
a.- (1) Helicopter
b.- (1) Remote Control
c.- (4) Screws
d.- (2) Main Blades
e.- (1) Balance Bar
f.- (1) Ascend and Descend Landing Gear
g.- (2) Tail Blades
h.- (2) Connection Buckle
a
b
cd
f
h
g
e

4
HELICOPTER PARTS LIST
Tail Blade
Undercarriage
Power Charger Light
Trim Adjustment Knob
Power Switch
Left/Right
Rudder Control
Throttle Stick
Balance Bar
Main Blade A Main Blade B
Power Switch
Charging Socket

5
INSTALLING THE BATTERIES
Battery Notes:
1. Turn the remote control over to access the battery compartment on the back.
2. Remove the screw and remove the battery compartment cover
3. Insert 6 AA batteries making sure to orient them according to the illustrations on
the inside of the battery compartment.
4. Replace the cover ensuring to fasten the screw.
• Do not mix new and old batteries or different brands of batteries.
• When not in use, switch off the power switch to extend usage time
• When the indicator lights of the controller flash, the controller is low on power. Make sure to change
the batteries before they are completely drained.
• If you don’t use the transmitter for an extended period of time, remove all batteries in order to avoid
leakage.

6
Battery Notes:
• Do not use or leave the battery near a heat source such as fire or heater.
• Do not allow the battery to be immersed in water. Make sure to keep the battery in a
cool and dry environment.
• When recharging, only use the battery charger included in the packaging of the product.
• Do not disassemble the battery.
• Never leave the battery unattended during charging.
• When not in use, switch off the power switch to extend usage time
• The control distance will shorter when the battery is not fully charged.
CHARGING THE HELICOPTER
• Make sure to switch OFF the helicopter prior to charging.
• Use the remote control’s charging cable located behind the front panel OR use
the included USB cable to charge the helicopter using any available USB power
port.
Charging Socket
Power Switch Charging Cable

7
PRE-FLIGHT
1. Lay your helicopter on the ground at least 6 feet away from obstructions, animals
or people.
2. Move the helicopter’s power switch located in the main housing to ON and make
sure the throttle on the remote is in the down position.
3. Stand back, and switch the remote’s power switch to ON.
4. Increase pressure on the throttle stick until the helicopter is able to just barely
hover over the floor.
5. Back off on the throttle to maintain a steady height and check to see if the he-
licopter leans in one direction or spins. If the helicopter is not stable hovering
over the floor, make micro-adjustments to the trim dials on the remote control to
correct. You may also use the included screwdriver to adjust the potentiometer
located on the helicopter’s circuit board.
6. Use very slight right and left adjustments to test the helicopter’s ability to move
right and left

8
Notes:
• Do not fly in extreme temperatures above 113°F/45° C, or below 50° F/10° C as
doing so will affect performance and may damage the helicopter.
• Do not fly in strong wind as windy conditions will limit control ability.
• Select a large, wide-open area and make sure there are no obstructions, ani-
mals or people nearby.
• If your helicopter is heading for a collision with a spectator or hard object, cut the
throttle to prevent damage.
• If there is not enough power to lift off your battery may be low. Charge the heli-
copter and try again.

9
TROUBLESHOOTING
PROBLEM CAUSE CHECK THIS
The remote control
doesn’t work
The power switch on the
remote control is OFF
Make sure the Power
switch is set to is ON
The remote control
doesn’t work
The batteries are im-
properly inserted
Confirm batteries are
correctly inserted.
Batteries lack of power Change the batteries
Unable to control the
helicopte
The power switch on the
helicopter is OFF
Turn helicopters power
switch ON
Helicopter unable to rise
Main rotor blades are
rotating too slowly
Pull up on the throttle
stick
The helicopter isn’t
charged sufficiently Charge the helicopter.

10
CARE AND MAINTENANCE
Warning
1. Recommended for indoor use only, and only in rooms without obstacles,
breakable objects or fans.
2. If the helicopter becomes damaged or broken do not fly as it may lead to
injury.
FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received including interference that
may cause undesired operation.
