Prusa i3 Hephestos User manual

RAMPS 1.4 WIRING
G3D MANUAL V1.0
25.07.2013

2
WWW.GADGETS3D.COM WWW.GADGETS3D.EU

3
RAMPS 1.4
Unpack RAMPS box (RAMPS 1.4 + arduino + sd shield);

4
Take motor wires and solder the same colors from wires with connector and use tape to protect the connection,
this will apply to X, Y and E motors;
connector wires motor wires
black yellow
green blue
red red
blue green

5
Take thermistor wires with connector and thermistor (heatbed, hotend), Solder it like before, and use tape to
protect the connection;
After soldering motors, endstops, thermistors You can connect them into RAMPS board;

6
Take endstop connector and place it;
Thermistor connectors should go near endstop pins;

7
Take motor connector and connect it near drivers;
Take flat screwdriver to loose power connector then connect power wires;
