PSC QuickScan 6000 Operating instructions

P ROGRAMMING G UIDE
Handheld Laser Scanner

PSC Scanning, Inc.
959 Terry Street
Eugene, Oregon 97402-9120
Telephone: [phone]
Toll Free: [phone]
Telefax: [phone]
www.pscnet.com
PSC and the PSC logo are registered trademarks of PSC INC. QuickScan,
QuickScan 6000 and QuickScan 6000Plus are trademarks owned by PSC INC.
Allrightsreserved. Nopartofthecontentsofthisdocumentationortheproceduresdescribed
therein may be reproduced or transmitted in any form or by any means without prior written
permission of PSC Inc. Owner of PSC Inc's products are hereby granted non-exclusive,
revocable license to reproduce and transmit this documentation for the purchaser's own
internal business purposes. Purchaser shall not remove or alter any proprietary notices,
includingcopyrightnotices,containedonthisdocumentationandshallensurethatallnotices
appear on any reproductions of the documentation.
Disclaimer
Reasonable measures have been taken to ensure that all information con-
tained in this manual is complete and accurate. However, PSC reserves the
right to change any specification at any time without prior notice.

R44-1540 i
Contents
Introduction
Understanding the Basics......................................................................... 1
Integrating Peripherals With Host Systems .............................................. 1
Changing Interfaces.................................................................................. 2
Customizing Your Scanner Operation....................................................... 4
Programming Overview .................................................................................... 5
What Is Programming Mode? ................................................................... 5
How To Program Using Bar Codes ........................................................... 5
The Programming Session ....................................................................... 6
Scanner Response When In Programming Mode..................................... 6
If You Make a Mistake... ........................................................................... 7
Return to Factory Settings ........................................................................ 7
Where To Go From Here .......................................................................... 8
Interface Selection
IBM IBM 4683/84 • 4693/94 Port 5B Interface Selection.................................. 9
IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E I/F Selection ...................... 10
IBM 4682/92 Port E Interface Selection.................................................. 11
OCIA
PSC OCIA1 Interface Selection.............................................................. 12
NCR OCIA Eight Bit (short format) Interface Selection ........................... 12
NCR OCIA Nine Bit (long format) Interface Selection ............................. 12
SNI OCIA Interface Selection ................................................................. 12
OCIA Options.......................................................................................... 13
Wand Emulation
Wand Emulation Interface Selection ....................................................... 14
RS-232
RS-232 Interface Selection..................................................................... 16
SNI RS-232 Interface Selection .............................................................. 16
Hardware Control ................................................................................... 19
Software Control ..................................................................................... 20
RS-232 ACK/NAK Options...................................................................... 21
Keyboard Wedge
PC Keyboard Wedge Interface Selection ............................................... 24
PC Keyboard Wedge Interface Selection—continued ............................ 25
Connect to a Laptop/No Keyboard Attached........................................... 26
Caps Lock............................................................................................... 27
Country Mode ......................................................................................... 28
Intercharacter Delay ............................................................................... 30

ii QuickScan 6000/6000 Plus Programming Guide
Label Transmit Format Configuration Items.................................................... 32
Prefix & Suffix ......................................................................................... 32
Non-Symbology Specific Items ............................................................... 34
ASCII Character Set ............................................................................... 38
Symbology-Specific Label I.D. ................................................................ 39
Symbologies
Symbology Options Overview......................................................................... 47
Symbology Selection ...................................................................................... 49
UPC/EAN Options .......................................................................................... 52
UPC/EAN Expansion .............................................................................. 53
UPC/EAN Add-Ons................................................................................. 54
C128 and Custom Add-Ons .................................................................... 54
Price/Weight Check Digit ........................................................................ 55
Code 39 Options............................................................................................. 58
Code 128 Options........................................................................................... 62
Interleaved 2 of 5............................................................................................ 63
Check Digit and Variable Length Label Selections ................................. 64
Standard 2 of 5 ............................................................................................... 67
Check Digit and Variable Length Label Selections ................................. 68
Setting Standard 2 of 5 Fixed and Minimum Label Lengths ................... 69
Codabar Options ............................................................................................ 72
Codabar Check Digit & Variable Length ................................................. 73
Codabar Start/Stop Character ................................................................ 74
Codabar Fixed Length ............................................................................ 75
MSI/Plessey
MSI/Plessey Check Digit ........................................................................ 77
MSI/Plessey Fixed Length ...................................................................... 78
General Features
Good Read Beeper Settings................................................................... 80
Read Verification .................................................................................... 82
Low Power Mode .................................................................................... 85
Debug Mode ........................................................................................... 86
AutoSense® Stand Mode ....................................................................... 86
Appendix A
Host Programming ......................................................................................... 87
Creating MultiFunction Labels ........................................................................ 87
Need More Information?................................................................................. 87
Appendix B
Sample Bar Codes ......................................................................................... 88

R44-1540 1
Introduction
This manual contains instructions for changing interfaces and bar codes
for customizing the scanner's operation. Since the QuickScan 6000/6000 Plus
scanner contains software enhancements and characteristics that set it
apart from other scanners, it is recommended that this guide be used as
the sole source of programming labels and information (except for other
QuickScan 6000/6000 Plus product-specific publications).
The organization of this manual is intended to support a variety of users
while making it quick and easy to find the information you need. Look at
the descriptions that follow to find where to go from here.
Understanding the Basics
If you do not regularly use bar code labels to configure (program)
scanners, it will be very helpful to read the introductory portions of this
manual prior to beginning your programming session. In addition to the
information that follows, information of specific interest to you is titled:
— Integrating Peripherals with Host Systems
— Changing Interfaces
— Customizing Your Scanner Operation
— Programming Overview
— What is Programming Mode?
— How to Program Using Bar codes
— The Programming Session
— Scanner Response When in Programming Mode
— If You Make A Mistake
— Where to Go From Here
Integrating Peripherals With Host Systems
It's important to understand that the scanner must contain software and
hardware that supports a specific interface in order to use that interface.
The following pages describe interface hardware and list software inter-
face groups available on current models.
Optimally, you'll want details about how your scanner was configured at
the factory before attempting to customize any settings. If you don't have
that information, contact your dealer for factory configuration information.
After determining the changes and/or additions you desire, locate the
programming labels and follow the related instructions in this manual to
adjust the scanner. Once you've completed these steps, you can begin
scanning.

2 QuickScan 6000/6000 Plus Programming Guide
Changing Interfaces
To change a scanner's interface…
Hardware
If necessary, replace the scanner's interface cable to match the new host
terminal's connection requirements. To disconnect the cable from the
scanner, insert a .050” hex driver or bent paper clip into the CABLE RE-
LEASE hole, and press down to unlock the cable connector. Reference
Figure 1.
NOTE
We recommend that you disconnect power before plugging/
unplugging cables to avoid any possibility of equipment damage.
Figure 1. Disconnecting the Interface Cable`
Interface
Connector
Paper Clip
Cable Release
Software
1. Verify that your scanner supports the desired interface1. The list
on the following page indicates interfaces available at the time of
this writing. Your scanner comes equipped from the factory with
the ability to connect and communicate with at least two major
interface types. For example, OCIA/RS-232 and Keyboard Wedge/
Wand Emulation are two common pairings. Contact your nearest
PSC service depot if you don't know your scanner's interface
group, or need to have the scanner altered to change to another
I/F group.
1 Contact your dealer if your desired interface is not listed. Interface group definitions are
subject to change without notice.

R44-1540 3
OCIA
• PSC OCIA
• NCR 8-Bit OCIA
• SNI OCIA
• NCR 9-Bit OCIA
RS-232
• PSC RS-232
• SNI RS-232
IBM
• IBM 4683/84, 4693/94 Port 5B
• 4682/92 Port E
• IBM 4683/84, 4693/94 Port 9A, 9B, 9C, 9E
Wand Emulation
Keyboard Wedge
• I/F Type A — PC/XT w/foreign keyboard
• I/F Type B — AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 &
95 w/foreign keyboard
• I/F Type C — PS/2 25 and 30 w/foreign keyboard
• I/F Type D — PC/XT w/US keyboard
• I/F Type E — AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 &
95 w/US keyboard
• I/F Type F — PS/2 25 and 30 w/US keyboard
• I/F Type G — IBM 3xxx w/122 keyboard (QuickScan 6000 Plus ONLY)
• I/F Type H — IBM 3xxx w/102 keyboard (QuickScan 6000 Plus ONLY)
• I/F Type I — PS/55 5530T w/104 keyboard (QuickScan 6000 Plus ONLY)
• I/F Type J NEC 9801 (QuickScan 6000 Plus ONLY)
2. Turn to the appropriate page in this manual and enable the
desired interface or interface sub-type by scanning its pro-
gramming bar code. These interface/interface sub-type
selection bar codes are located at the beginning of each of
these sections of the manual: IBM, OCIA, Wand Emulation,
RS-232, and Keyboard Wedge. This will enable the software
for the new interface and disable the 'old' interface software.
Once enabled, the new interface becomes the default inter-
face that is active whenever power is applied to the scanner.
3. Scan a bar code to verify that the scanner communicates
correctly with the host system. Some sample bar codes are
provided on the last pages of this manual. If any changes to
the scanner's factory settings are needed, use the instructions
titled, Customizing Your Scanner Operation.

4 QuickScan 6000/6000 Plus Programming Guide
Customizing Your Scanner Operation
When enabling a new interface, it may be necessary to modify the
original factory settings to match your specific host system's communica-
tion and symbology requirements. Check with your system administrator
to identify your host system's specific interface requirements to ensure
that they match the new interface you've selected. Also, the scanner's
operational features, such as speaker volume, can be customized to match
your unique requirements.
1. Use the labels in this manual to modify the standard configu-
ration to match your specific interface requirements or user
preference.
NOTE
Ensure that your planned modifications are compatible with the
current interface. For example, baud rate selections are only valid
in the RS-232 interface. The scanner will sound an error tone (six
rapid beeps) when scanning programming labels for features
invalid to the current interface.
2. Enable any additional symbologies as required and exit
Programming Mode.
3. Scan a regular bar code label and verify that the scanner and
host communicate correctly.
4. You have completed the factory settings change procedure.
If you experience difficulties, have questions or require additional infor-
mation, contact your local distributor using the listings located on the
back cover of this guide.

R44-1540 5
Programming Overview
This section describes how to set the scanner's programmable features.
These features can be configured using the bar code labels contained in
this manual or by using commands sent from the host. Refer to Appendix
A, Additional Information, for host programming details. If you program
the scanner using these bar codes, the scanner stores the changes until
reprogrammed.
What Is Programming Mode?
To change the scanner's programmed settings, it is necessary to place the
scanner in Programming Mode using the special SET label. This ensures
that the scanner only recognizes the special programming labels con-
tained in this programming guide.
How To Program Using Bar Codes
The following pages contain special bar code labels that are used to
change or enable the scanner's programmable options. All programming
sessions follow this order, unless otherwise instructed:
1. Scan the SET label at the top of the page. The scanner will
emit a 'good read' beep, indicating it has read the label.
2. Scan the feature label(s) for the programmable options
you wish to enable. With few exceptions1, the scanner will
emit a triple beep each time you scan a valid programming
label. (Note that not all features are available for all inter-
faces and that the scanner will sound an error tone when
scanning programming labels for features invalid to the
current interface.)
3. Scan the END label at the bottom of the page to complete
the programming session and exit Programming Mode. The
scanner will sound one 'good read' beep upon exiting
Programming Mode.
4. Maintain a good record of all changes made to ensure that
you know if the original factory settings have been changed.
1 Some features, such as Minimum Label Length or Label ID, require you to select the length
by scanning a series of single-digit bar codes. A single 'good read' beep is sounded when
scanning these single digits in Programming Mode. Only the final required digit in the
sequence will produce a triple beep when scanned, indicating a successfully programmed
feature.

6 QuickScan 6000/6000 Plus Programming Guide
The Programming Session
It is possible to program multiple features during a single programming
session (a programming session is defined as the period of time between
scanning the “set” label and scanning the “end” label). However, it is
recommended that sessions be limited to one feature, as it can be difficult
to discover where an error has been made, should you make a mistake in
the programming sequence. Additionally, it can be confusing to deter-
mine which features may or may not have been successfully set following
such a session.
The scanner will not exit Programming Mode unless the END label is
scanned. Disconnecting power during Programming Mode, before
scanning the END label, will cause the scanner to forget any programming
labels scanned during the current programming session and will cause the
scanner to return to its previous settings.
Scanner Response When In Programming Mode
As discussed earlier, Programming Mode is entered by scanning a SET
label. The green LED will flash continuously at 1Hz duty cycle while the
scanner is in Programming Mode. As long as it is in Programming Mode,
the scanner will not decode regular bar code labels and will only enable
features supported by the currently active interface.
Scanning regular (non-programming) bar code labels — the
scanner will reject the label, sounding an error tone (six rapid
beeps).
Scanning a valid programming label —
a. If the feature is supported by the active interface, the
scanner will sound three beeps.
b. If incorrect programming has been entered, the error tone
will be sounded (six rapid beeps). Additionally, when
programming a feature requiring you to scan single digits
to set a multi-digit number, such as Minimum Label
Length or Label ID, scanning the END label before
completing all input will result in an error tone and cause
the scanner to exit Programming Mode. Under these
circumstances, the current feature you were trying to set
is thrown out; any previous labels scanned during the
session will take effect.

R44-1540 7
If You Make a Mistake...
If, during a programming session, you find that you are unsure of the
scanner's settings or wish to reset the scanner's configuration, use the
Return to Factory Settings label on this page to return the scanner's
configuration to the factory settings. Scanning this label will also reset
any changes made during previous programming sessions.
Return to Factory Settings
Scan this label to return the scanner to the default settings configured at
the factory for your scanner’s original interface specifications. This label
is typically used to return the scanner to a “known” operating state when
the present programming status is not known, faulty, or suspect.
WARNING
Use this label with caution, since it will disable ALL features that
may have been programmed since the scanner’s installation.
If you don't have a record of your site/system's original configuration, you
may need to call your nearest PSC service depot for assistance to return
the scanner to normal function. Please be prepared to provide informa-
tion about the store/chain, location, POS system and other pertinent
information about the scanner being repaired.

8 QuickScan 6000/6000 Plus Programming Guide
Where To Go From Here
Programming is easy and straightforward if you follow these steps:
1. If you are changing interfaces, first connect the scanner to the
new host using the new interface cable. Scan the interface
enable bar code label1.
2. Scan any feature labels that are unique to the interface you
are currently programming. These interface specific program-
ming labels immediately follow each interface selection label.
3. Turn to the Symbology section if you are going to change
any bar code symbologies or modify any symbology related
features.
4. Turn to the General Features section of this guide if you wish
to change or modify any of the scanner's other features.
Once the necessary changes have been made, and you have scanned the
END label, you are ready to scan.
1This step is not necessary for QuickScan 6000 Plus scanners, unless you require a specific
interface sub-type such as SNI OCIA or IBM sub-type 4682/92 Port E. Interface software is
automatically selected when the QuickScan 6000 Plus hardware connection (via a new
interface cable) is made.

R44-1540 9
IBM 4683/84 • 4693/94 Port 5B Interface Selection
Scan this label to enable the IBM 468x Port 5B interface.
IBM 4683/84 • 4693/94 Port 5B Settings
Data Format: Send As Code 39 — converts bar code data (UPC/EAN,
add-ons, Code 93, Codabar, MSI/Plessey and Code 128) into Code 39
format before sending the data to the host.
These settings are for IBM 4683/84 • 4693/94 Port 5B interface ONLY.
Limit Command Set — is an option that causes the scanner to ignore
'enable scanner' and 'disable scanner' commands sent from the host.
Transmit Unsolicited Status
1
— when enabled, this option causes the
scanner to transmit a status message to the host upon receipt of an "SNRM".
SET ----------------------------------------------
SEND AS CODE 39 ----------------
DON'TSEND AS CODE 39 --------
ENABLE LIMIT COMMAND SET -----
DISABLE LIMIT COMMAND SET -----
TRANSMIT UNSOLICITED STATUS ---
DON'TTRANSMIT UNSOLICITED STATUS ---
END ----------------------------------------------
1 For this IBM interface, the setting for Unsolicited Status is normally Enabled.
D
ATA
F
ORMAT

10 QuickScan 6000/6000 Plus Programming Guide
IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E I/F Selection
Scan this label to enable the IBM 468x/9x Port 9x interface.
IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E Settings
Data Format: Send As Code 39 — converts bar code data (UPC/EAN,
add-ons, Code 93, Codabar, MSI/Plessey and Code 128) into Code 39
format before sending the data to the host.
These settings are for IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E inter-
face ONLY.
Limit Command Set — is an option that causes the scanner to ignore
'enable scanner' and 'disable scanner' commands sent from the host.
Transmit Unsolicited Status1 — when enabled, this option causes the
scanner to transmit a status message to the host upon receipt of an
"SNRM".
SET ----------------------------------------------
SEND AS CODE 39 ----------------
DON'TSEND AS CODE 39 --------
ENABLE LIMIT COMMAND SET -----
DISABLE LIMIT COMMAND SET -----
TRANSMIT UNSOLICITED STATUS ---
DON'TTRANSMIT UNSOLICITED STATUS ---
END ----------------------------------------------
1 For this IBM interface, the setting for Unsolicited Status is normally Disabled.
D
ATA
F
ORMAT

R44-1540 11
IBM 4682/92 Port E Interface Selection
Scan this label to enable the IBM 468x/9x Port E interface.
IBM 4682/92 Port E Settings
Data Format: Send As Code 39 — converts bar code data (UPC/EAN,
add-ons, Code 93, Codabar, MSI/Plessey and Code 128) into Code 39
format before sending the data to the host.
These settings are for IBM 4682/92 Port E interface ONLY.
Limit Command Set — is an option that causes the scanner to ignore
'enable scanner' and 'disable scanner' commands sent from the host.
Transmit Unsolicited Status
1
— when enabled, this option causes the scanner
to transmit a status message to the host upon receipt of an "SNRM" .
SET ----------------------------------------------
SEND AS CODE 39 ----------------
DON'TSEND AS CODE 39 --------
ENABLE LIMIT COMMAND SET -----
DISABLE LIMIT COMMAND SET -----
TRANSMIT UNSOLICITED STATUS ---
DON'TTRANSMIT UNSOLICITED STATUS---
END ----------------------------------------------
1 For this IBM interface, the setting for Unsolicited Status is normally Disabled.
DATA FORMAT

12 QuickScan 6000/6000 Plus Programming Guide
PSC OCIA1Interface Selection
Scan this label to enable the PSC OCIA interface.
NCR OCIA Eight Bit (short format) Interface Selection
Scan this label to enable the NCR OCIA (short format) interface.
NCR OCIA Nine Bit (long format) Interface Selection
Scan this label to enable the NCR OCIA Nine Bit (long format) interface.
SNI OCIA Interface Selection
Scan this label to enable the SNI OCIA interface.
1 NOTE: In previous publications, this interface was termed, "SP OCIA".

R44-1540 13
OCIA Options
Use these labels to change the settings as desired. The following brief
descriptions explain each selection.
Beep if Not on File — when enabled requires the scanner to
beep when a label is scanned that is not on file.
Host Commands — when enabled allows the scanner to
accept commands directly from the host.
Intercharacter Delay — refers to a pause, if any, between
each character before being sent to the host. This time delay is
used to control the flow of data from the scanner, but it should
not be required for most applications. When enabled, OCIA
intercharacter delay is set at 70µs.
SET ----------------------------------------------
ENABLE -----------------------------
DISABLE-----------------------------
ENABLE -----------------------------
DISABLE-----------------------------
ENABLE -----------------------------
DISABLE-----------------------------
END ----------------------------------------------
HOST
COMMANDS
INTERCHARACTER
DELAY BEEP IF
NOT ON FILE

14 QuickScan 6000/6000 Plus Programming Guide
Wand Emulation Interface Selection
Scan this label to enable the Wand Emulation interface.
Wand Emulation Settings
SET ----------------------------------------------
SPACE LOW, BAR HIGH -----------
SPACE HIGH, BAR LOW -----------
LOW (660 µS) --------------------
HIGH (330 µS)--------------------
TRANSMIT IN NORMAL FORMAT-----
TRANSMIT IN C39 FORMAT --------
TRANSMIT IN C128 FORMAT ------
TRANSMIT IN C39 -----------------
POLARITY
SIGNAL SPEED
DATA FORMAT
FULL ASCII

R44-1540 15
LOW---------------------------------
HIGH --------------------------------
TRANSMIT PRE-NOISE -------------
DON'TTRANSMIT PRE-NOISE------
ENABLE -----------------------------
DISABLE-----------------------------
END ----------------------------------------------
Go to the sections titled Symbology Selection and General Features in the
back of this programming guide if you want to change any other settings
for this interface.
IDLE STATE
TRANSMIT ANOISE
PATTERN BEFORE
LABEL TRANSMISSION
TRANSMIT C128
FUNCTION CHAR'S

16 QuickScan 6000/6000 Plus Programming Guide
RS-232 Interface Selection
Scan this label to enable the standard RS-232 interface (PSC RS-232).
SNI RS-232 Interface Selection
Scan this label to enable the SNI RS-232 interface.
RS-232 Communication Parameters
This section contains the following RS-232 communication parameters in
the order listed:
• Baud Rate
• Data Bits
• Parity
• Stop Bit(s)
• Hardware Handshaking (CTS/RTS)
• Software Handshaking (Xon/Xoff)
• ACK/NAK Options
• Intercharacter Delay
Go to the sections titled Symbology Selection and General Features in the
back of this programming guide if you want to change any other settings
for this interface.
