PUK Flamingo Micro Planning guide

ASSEMBLY AND OPERATING INSTRUCTIONS:
FLAMINGO MICRO
-Power consumption : 2W
-Voltage : 24Vdc
-Color: 3000K 4000K
-Beam angle : 8° 20° 40°
- nsulation class:
- P protection: P66
-Gross weight: 1.7kg
Made in Italy
COD 101701
COD 101702
COD. 101701
-replace the damaged protective glass
-getting rid of as urban waste forbidden
-separate collection is mandatory when the product is at the
end of its life
IP66
NB: These assembly instructions must be given to end users for correct maintenance and so that they know how to change the LED’
The appliance must not be tampered with or transformed and it must be installed and used as supplied and in compliance with the
National Rules on Installations. Any non-compliant installations will invalidate all forms of guarantee. The company cannot be held
responsible for damage caused by incorrect assembly.
-Do not open the device !! For the replacement of the LEDs or for any maintenance inside the appliance, contact the PUK Italia Group company.
COD. 101702
protection class III
products that can only be operated with protec-
ted extra-low voltage
IK08
The article is suitable for indoor and
outdoor use
Retain the instructions
-Electronic equipment sensitive to voltage surges.
The installation of a protective device against over-
voltages on the electrical system attenuates the
phenomena protecting apparatus from the risk of
damage.
Do not use high pressure cleaners
FLAMINGO MINI
-Power consumption : 6W
-Voltage : 24Vdc
-Color: 3000K 4000K
-Beam angle : 4° 10° 28°
- nsulation class:
- P protection: P66
-Gross weight: 1.8kg
ACCESSORIES

Recommendations
1) verify that the equipment used to connect our devices to enjoy all the
guarantees required under European law;
2) use the cables, connectors and quality materials for electrical wiring;
3) Products with IP65/68 degree make the wiring / connections with accessoriesprovide the same degree IP of the selected product
(available in the catalog);
4) In the case of installations outside is not recommended to install the power supplies in theformwork and / or in the junction box
without adequate protection;
INSTALLATION
-SWITCH-OFF THE POWER SUPPLY BEFORE CARRYING OUT ANY MAINTENANCE OPERATIONS
1) Remove the fixing base from the luminaire using the tool include in the package
2) Drill holes directly to the feeding point and place plugs (fisher type) and install the fixing base
3) Make the adeguate electrical connection remembering that is a 24Vdc luminaire respecting the polarity of the cable.
4) Fix the luminaire to the base using the tool included in the package and tighten the four grub-screws
5) Make the desired regulation acting to the top head screw and then tighten the screw using a tool included in the package
6) To change the extension pipes uncrew the grub-screw on the top of the pipe and the base fixing nut
External transformer is needed
220/240V 50 60Hz @ 24Vdc
EXTENSION PIPES

WIRING DIAGRAM WITH PARALLEL CONNECTIONS
CLA III 24Vdc
BROWN WIRE + Positive
BLUE WIRE— Negative
ee the connector accesso-
ry instruction

nformation for users
stream. To prevent possible harm
to the environment or human health please separate this product from other waste streams to ensure that it can be
where you purchased this product.
I informazioni agli utenti
del prodotto.
D Richtlinie 2002/96/EU (Elektro- und Elektronik- Altgeräte - WEEE):
Benutzerinformationen
Zur Vermeidung einer mögli-
chen Beeinträchtigung der Umwelt oder der menschlichen Gesundheit darf dieses Produkt nicht in den Hausmüll gegeben
die zuständige Behörde oder das Geschäft, in dem ie dieses Produkt erworben
haben.
F Directive 2002/96/CE (Déchets d’èquipements èlectriques et èlectroniques - DEEE):
informations aux utilisateurs
l’administration locale ou le détaillant auprés duquel vous avez acheté ce produit.
E Directiva 2002/96/CE (Residuos de aparatos eléctricos y electrónicos - RAEE):
Información para el usuario
donde adquirió este producto
E Directive 2002/96/CE (Waste Electrical and Electronic Equipment - WEEE) information for users
en lokal myndighet elleder den återförsäljare som du köpte produkten från.
NL Richtlijn 2002/96/EG (Afgedankte Elektrische en Elektronische Apparaten - AEEA):
informatie voor de gebruikers
gemeente of de leverancier bij wie u dit product hebt gekocht.
AND OF THE COUNCIL OF 27 January 2003 on waste electrical and electronic equipment (WEEE) and legislation trasposing and imple
- menting it into the various national legal systems.
