PUK GRAZER Series User manual

ASSEMBLY AND OPERATING INSTRUCTIONS:
GRAZER 9 500
-Power consumption : 9W
-Voltage : 24Vdc
-Color Temperature : 3000K - 4000K
-Beam angle : ° / 20° / 30° / 60° / 15x30° /
10x60°
-Lumen output : 700@3000K 720@4000k
-Insulation class: III
-IP protection: IP66
-Gross weight: 2kg
Made in Italy
COD 402701-02-03-04
COD. 402701
-replace the damaged protective glass
-getting rid of as urban waste forbidden
-separate collection is mandatory when the product is at the
end of its life
IP66
NB: These assembly instructions must be given to end users for correct maintenance and so that they know how to change the LED’
The appliance must not be tampered with or transformed and it must be installed and used as supplied and in compliance with the
National Rules on Installations. Any non-compliant installations will invalidate all forms of guarantee. The company cannot be held
responsible for damage caused by incorrect assembly.
-Do not open the device !! For the replacement of the LEDs or for any maintenance inside the appliance, contact the PUK Italia Group company.
COD. 402702
protection class III
products that can only be operated with protec-
ted extra-low voltage
IK08
The article is suitable for indoor and
outdoor use
Retain the instructions
-Electronic equipment sensitive to voltage surges.
The installation of a protective device against over-
voltages on the electrical system attenuates the
phenomena protecting apparatus from the risk of
damage.
Do not use high pressure cleaners
GRAZER 18 500
-Power consumption : 1 W
-Voltage : 24Vdc
-Color Temperature : 3000K - 4000K
-Beam angle : ° / 20° / 30° / 60° / 15x30° /
10x60°
-Lumen output : 1400@3000K 1440@4000k
-Insulation class: III
-IP protection: IP66
-Gross weight: 2kg
COD. 402703 GRAZER 18 1000
-Power consumption : 1 W
-Voltage : 24Vdc
-Color Temperature : 3000K - 4000K
-Beam angle : ° / 20° / 30° / 60° / 15x30° /
10x60°
-Lumen output : 1400@3000K 1440@4000k
-Insulation class: III
-IP protection: IP66
-Gross weight: 3kg

Recommendations
1) verify that the equipment used to connect our devices to enjoy all the guarantees required under European law;
2) use the cables, connectors and quality materials for electrical wiring;
3) Products with IP65/68 degree make the wiring / connections with accessoriesprovide the same degree IP of the selected product
(available in the catalog);
4) In the case of installations outside is not recommended to install the power supplies in theformwork and / or in the junction box
without adequate protection;
INSTALLATION
-SWITCH-OFF THE POWER SUPPLY BEFORE CARRYING OUT ANY MAINTENANCE OPERATIONS
1) Place the luminaire in the desired position
2) Fix the luminaire to the floor using plugs (fisher type)
2) For chained placement pull the luminaire directly next to the previous
3) For the leader cable using cod AC080 to be connected to a 24Vdc driver
4) In the last device close the connector with a cap suitable cod. AC081
External transformer is needed
220/240V 50-60H @ 24Vdc
COD. 402704 GRAZER 36 1000
-Power consumption : 36W
-Voltage : 24Vdc
-Color Temperature : 3000K - 4000K
-Beam angle : ° / 20° / 30° / 60° / 15x30° /
10x60°
-Lumen output : 2 20@3000K 2 0@4000k
-Insulation class: III
-IP protection: IP66
-Gross weight: 3kg
