PUK TECH EVO MINI 01 User manual

ASSEMBLY AND OPERATING INSTRUCTIONS:
TECH EVO MINI 01
-Power consumption : 5.5W
-Voltage :220-240V 50-60Hz
-Color Temperature : 000K— 4000K
-Lens Type : 12°- 0°-45°
-Insulation class: I
-IP protection: IP65
-Gross weight: 2kg
Made in Italy
COD. 402601
COD. 402602
COD. 402603
COD. 402604
COD. 402601
-replace the damaged protective glass
-glass features: plane float glass - safety tempered
-getting rid of as urban waste forbidden
-separate collection is mandatory when the product is at the
end of its life
--Class I fitting electric gruonding is needed
-Complete protection from dust and water jets
IP65
NB: These assembly instructions must be given to end users for correct maintenance and so that they know how to change the bulb.
The a liance must not be tam ered with or transformed and it must be installed and used as su lied and in com liance with the
National Rules on Installations. Any non-com liant installations will invalidate all forms of guarantee. The com any cannot be held
res onsible for damage caused by incorrect assembly.
IK 09
COD. 402602
TECH EVO MINI 02
-Power consumption : 11W
-Voltage :220-240V 50-60Hz
-Color Temperature : 000K— 4000K
-Lens Type : 12°- 0°-45°
-Insulation class: I
-IP protection: IP65
-Gross weight: 2kg
COD. 402603
COD. 402604
TECH EVO MEDIUM 01
-Power consumption : 15W
-Voltage :220-240V 50-60Hz
-Color Temperature : 000K— 4000K
-Lens Type : 14°- 5°-55°
-Insulation class: I
-IP protection: IP65
-Gross weight: .5kg
TECH EVO MEDIUM 02
-Power co Ensumption : 0W
-Voltage :220-240V 50-60Hz
-Color Temperature : 000K— 4000K
-Lens Type : 14°- 5°-55°
-Insulation class: I
-IP protection: IP65
-Gross weight: .5kg

Recommendations
1) verify that the equipment used to connect our devices to enjoy
all the guarantees required under uropean law;
2) use the cables, connectors and quality materials for electrical wiring;
3) Products with IP65/68 degree make the wiring / connections with accessories
provide the same degree IP of the selected product (available in the catalog);
4) In the case of installations outside is not recommended to install the power supplies in the
formwork and / or in the junction box without adequate protection
Choice of installation location
The unit should be positioned so that when in use is not subject to direct radiation from the sun or other heat sources . High tempera-
tures reduce the life and efficiency of the components or the L D module .
Relam ing and maintenance:
-it is essential to do a frequent cleaning of the glass and of the outer surface of the fixture to avoid build up of mud and dirtiness
resulting in dangerous overheating due to uncorrect light and heat dissipation. Clean carefully the glass screen removing limestone
deposits by means of a scraper.
.The re lacement must be done by a qualified electrician.
INSTALLATION:
-SWITCH-OFF THE POWER SUPPLY BEFORE CARRYING OUT ANY MAINTENANCE OPERATION
- 1 Remove the fixing plate by unscrewing the 2 grubscrews using the tool included in the package
- 2 Prepare holes in the wall using plugs type “fischer” in correspondance to the feeding point
- 3 Place the fixing plate to the wall by tighten the fixing plugs screws
- 4 Make the electrical connection to the terminal
- 5 Place the luminaire by tighten four fixing screws using the tool included in the package
THE WARRANTY IS FALLING IN THE FOLLOWING CASES:
1) Malfunctions due to improper use of the product, modifications, repairs inadeguate, negligence on the part of the installer / electri-
cian, failure to assembly instructions and / or data plate;
2) Installations in plants not comply with the general safety;
3) Damage caused by natural causes such as lightning, fire or flooding;
4) Damage caused by wiring / connections with IP degree lower than the selected product.
5) Damage occurring during shipment of the product. In these cases the damage will be to charge and notify the carrier;
6) The warranty covers only the integrity of the product and NOT any costs of removal of the same;
FIXING PLAT
COD. 402601-2
FIXING PLAT
COD. 402603-4
