Pulsar MicroFlow-i User manual

MICROFLOW-
INSTRUCTION MANUAL

MICRO FLOW-(FIRST EDITION REV 5)
May 2019
Part Number M-MFi-S-001-5P
COPYRIGHT
© Pulsar Process Measurement Limited, 2017 - 2019. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language
in any form without the written permission of Pulsar Process Measurement Limited.
WARRANTY AND LIABILITY
Pulsar Process Measurement Limited guarantee for a period of 2 years from the date of delivery that it
will either exchange or repair any part of this product returned to Pulsar Process Measurement Limited
if it is found to be defective in material or workmanship, subject to the defect not being due to unfair
wear and tear, misuse, modification or alteration, accident, misapplication or negligence.
DISCLAIMER
Pulsar Process Measurement Limited neither gives nor implies any process guarantee for this product
and shall have no liability in respect of any loss, injury or damage whatsoever arising out of the
application or use of any product or circuit described herein.
Every effort has been made to ensure accuracy of this documentation, but Pulsar Process Measurement
Limited cannot be held liable for any errors.
Pulsar Process Measurement Limited operates a policy of constant development and improvement and
reserves the right to amend technical details as necessary.
The MicroFlow-i shown on the cover of this manual is used for illustrative purposes only and may not
be representative of the actual MicroFlow-i supplied.
TECHNICAL ENQUIRIES
Please contact Pulsar Process Measurement Limited for technical support.
COMMENTS AND SUGGESTIONS
If you have any comments or suggestions about this product, then please contact:
Pulsar Process Measurement Limited
Pulsar Process Measurement Inc.
Cardinal Building
Enigma Commercial Centre
Sandy’s Road
Malvern
Worcestershire
WR14 1JJ
United Kingdom
PO Box 5177
Niceville
FL 32578-5177
USA
Tel: + 44 (0) 1684 891371
Fax: + 44 (0) 1684 575985
Tel: + 1 850 279 4882
Fax: + 1 850 279 4886
Web Site: https://www.pulsar-pm.com
e-mail: [e-mail] (general
information)
e-mail: support@ pulsar-pm.com (product
support)
Web Site: https://www.pulsar-pm.com
e-mail: [e-mail] (general
information)
e-mail: support.usa@ pulsar-pm.com (product
support)
Pulsar® is a registered trademark of Pulsar Process Measurement Ltd in the UK, USA and China.

Contents
Chapter 1 Start Here… ....................................................................................................................... 1
About this Manual...........................................................................................................................................1
About theMicroFlow-i ...................................................................................................................................2
Benefits............................................................................................................................................................3
Functional Description....................................................................................................................................4
Product Specification.......................................................................................................................................5
EU Declaration of Conformity.......................................................................................................................6
Chapter 2 Installation.......................................................................................................................... 7
Unpacking........................................................................................................................................................7
Power Supply Requirements...........................................................................................................................7
Cable Requirements ........................................................................................................................................7
Information specific to Hazardous Area Installation.....................................................................................8
Limitations on use....................................................................................................................................8
Hazardous Area Specific Power Supply and barrier Requirements......................................................9
Location.........................................................................................................................................................11
Mounting........................................................................................................................................................11
Angled Mounting Bracket.....................................................................................................................12
MicroFlow-i sensor...............................................................................................................................14
Mounting sensor to a bracket................................................................................................................15
Terminal Connection Details........................................................................................................................18
Chapter 3 Locating the MicroFlow-i sensor...................................................................................... 19
LocatingtheMicroFlow-i.....................................................................................................................19
Installing the Sensor...............................................................................................................................22
Preparation for Operation..............................................................................................................................23
General Maintenance.....................................................................................................................................23
Sensor Maintenance......................................................................................................................................24
Chapter 4 Understanding how the MicroFlow-i operates.................................................................. 27
MicroFlow-i HART compatible...................................................................................................................27
4 –20 mADevice..........................................................................................................................................27
Chapter 5 MicroFlow-i HART PC.................................................................................................... 29
Software installation......................................................................................................................................29
Connecting to MicroFlow-i HART PC........................................................................................................30
FlowTab........................................................................................................................................................32
Configuration Tab.........................................................................................................................................33
Parameter Get/Set..................................................................................................................................33
MicroFlow-i Manual Setting.................................................................................................................34
4 –20mA Trim......................................................................................................................................35
Trace Tab.......................................................................................................................................................36
Comport.........................................................................................................................................................38
Language........................................................................................................................................................38
Tools menu....................................................................................................................................................38
Info.................................................................................................................................................................39
Exit.................................................................................................................................................................39
Chapter 6 Parameter Listing and Descriptions.................................................................................. 40
Parameter Access...........................................................................................................................................40
Device Information Parameters....................................................................................................................40
Processing Parameters...................................................................................................................................41
MicroFlow-i Firmware Upgrade..................................................................................................................44
MicroFlow-i HARTFirmware Upgrade......................................................................................................46
Chapter 7 Troubleshooting ............................................................................................................... 48
Chapter 8 Parameter record .............................................................................................................. 49
Chapter 9 Disposal............................................................................................................................ 50

Page 1
Chapter 1 Start Here…
Congratulations on your purchase of a Pulsar MicroFlow-i. This quality system
has been developed over many years and represents the latest in high technology
flow monitoring.
It has been designed to give you years of trouble free performance, and a few
minutes spent reading this operating manual will ensure that your installation is as
simple as possible.
About this Manual
It is important that this manual is referred to for correct installation and
operation.
There are various parts of the manual that offer additional help or information as
shown.
Tips
TIP
At various parts of this manual
you may find tips to help you.
Additional Information
Additional Information
At various parts of the manual, you will find sections
like this that explain specific things in more detail.
References
See also text in Bold as these may be references to other parts of this or another
manual.
Drawings
It should be noted that drawings or pictures shown in this manual may not be to
scale.

Page 2
About the MicroFlow-i
The MicroFlow-i is a 2-wire loop-powered non-contacting velocity sensor,
with hazardous area approval. The sensor provides reliable flow velocity
measurements using short pulses of micro-waves, which are transmitted by an
enclosed antenna. When reflected off a moving surface, the signal experiences
a shift in frequency characteristics. The reflected signal is captured by the on-
board microprocessor via the antenna, and analysed to determine the velocity.
The MicroFlow-i’s compact and versatile design makes it easy to install and
ideal for confined spaces. Housed in a robust enclosure coupled with a fully
encapsulated microwave antenna, it provides an effective fit-and-forget flow
velocity solution.
Perfect for remote monitoring or when there is no mains power available, due
to its low power consumption. To access flow velocity data, use Pulsar’s
MicroFlow-i HART PC or HART protocol.
Overall the device has outstanding stability, accuracy and repeatability.

Page 3
Benefits
Combined with the ease of programming there are many other benefits to using
the MicroFlow-i, these are listed below:
•Non-contact velocity measurement.
•Loop powered and ideal for remote monitoring.
•Low-power consumption.
•Hazardous area approval (Ex ia) for Zone 0.
•‘See through’ capability for enclosed plastic pipes and concrete (not
reinforced) channels.
•Suitable for abrasive and aggressive materials.
•Resilient to liquid vapour, wind or temperature.
•No minimum liquid level required for measurement
•Maintenance free.
•No interruption to operational flow.
•Can be installed in addition to existing in process contact measuring
devices.
•Easily setup using MicroFlow-i HART PC.
•The sensor is capable of monitoring flow of very shallow liquid,
mitigating the constraint associated with in-liquid techniques.

Page 4
Functional Description
Based upon state-of-the-art micro-wave sensing technology, the MicroFlow-i
integrates Pulsar’s innovative and award winning DSP (Digital Signal Processing)
platform, offering you a cost effective solution with excellent reliability and
performance.
The Pulsar MicroFlow-i has been designed to provide maintenance free
performance. The MicroFlow-i i is also intrinsically safe (Ex ia) for Zone 0.
The MicroFlow-i can be mounted via a rear 1” BSP to M20 thread adapter
(supplied with unit). The MicroFlow-i is loop powered and gives a 4 to 20mA
output which is proportional to the flow velocity. A ‘fault condition’ alarm will
give out a reading of either 3.8mA or 22mA.
The 2 wire sensor can either be used in digital HART mode or as 4-20mA loop
powered device. The MicroFlow-i loop powered version can be set up using a
HART modem with either proprietary HART software such as Pact ware or Pulsar
MicroFlow-i HART PC software.
Boot up time from power up to stable reading: cold boot 8.5 seconds, warm boot
4 seconds (if within 12 hours from last start up).
