Pulsar DCDC15H User manual

1
DCDC15H
12V/1,5A/62MM DC/DC converter
Edition: 3 from 03,09.2013
Supersedes edition 2 from 22.07.2013
EN
Features:
•Power output 1,5A/12VDC
•DC power supply range 18÷40V DC
•Maximum current load 1,5A
•high efficiency 86%
•IP 67 enclosure
•protections:
•overload protection OLP
•overheating protection OHP
•warranty – 2 year from the production date
1. Technical description.
1.1. General description.
The DCDC converter is used for powering devices that require stabilized voltage of 12V DC. The maximum
current load is 1.5 A (Pmax= 18W).This module does not have galvanic insulation between the input and output
(IN-AUX), and operates on a common ground potential. The unit is protected against short circuit, overload and
overheating.
1.2. Specifications.
Supply voltage 18 ÷40V DC
Supply power 18W max.
Efficiency 86%
Current consumption by PSU systems 5mA max.
Output voltage 12V DC
Output current 1,5 A
Output current t
AMB
<30°C 1,5 A - refer to graph 1.
Output current t
AMB
=40°C 1,05 A - refer to graph 1.
Ripple voltage 100mV p-p max.
Overload protection OLP 110% ÷ 150% (@25ºC) of converter Power – current limitation
with the PTC, manual restart (failure requires disconnection of
the DC output circuit)
IP protection class IP67
Operation conditions temperature -10
o
C÷40
o
C
relative humidity 20%...90%
Dimensions (LxWxH) 58 x 58 x 28 [mm]
Net/gross weight 0,16kg / 0,19kg
Protection class PN-EN 60950-1:2007 II (second)
Length of DC input cable 0,3m
Length of DC output cable 0,5m + plug DC5,5/2,1 female
Storage temperature -20ºC...+60ºC
Graph 1.
Relation between output current and ambient
temperature.
Fig.1. Mechanical view and dimensions of the converter.

2
1.3. Accessories.
For the converters are available accessories - cable adapter. For details –visit www.pulsar.pl.
2. Installation.
2.1. Requirements.
The converter shall be mounted by the qualified installer having appropriate (required and necessary for a given
country) permissions and qualifications for connecting (operating) low-voltage installations. The unit should be mounted in
confined spaces, in accordance with the 2nd environmental class, with normal relative humidity (RH=90% maximum,
without condensation) and temperature from -10°C to +40°C.
In order to meet the LVD and EMC requirements, the rules concerning: supply, development and shielding ought
to be followed - accordingly to the application.
2.2. Installation procedure.
1. Fit the converter inside the device.
2. Connect the converter input cables to the DC voltage source, according to polarity.
3. Connect the converter output cables to the load.
4. After the performance of test and function checks, close the case, cabinet, etc.
3. Maintenance.
Any and all maintenance operations may be performed following the disconnection of the converter from the
power network. The converter does not require any specific maintenance procedures, however, in the case of significant
level of dust, it should be cleaned with the compressed air.
WEEE designation
The waste electric and electronic equipment worn out may not be disposed of together
with standard household waste. According to the WEEE directive, applicable in the EU,
the separate neutralization methods should be used for electric and electronic
equipment.
Pulsar K.Bogusz Sp.j.
Siedlec 150, 32-744 Łapczyca, Poland
Tel. [phone], Fax. [phone]
e-mail: [email protected], sal[email protected]l
http:// www.pulsar.pl
THE GENERAL WARRANTY CONDITIONS
1. Pulsar K. Bogusz, Particular Partnership (the manufacturer) provides a two-year uality warranty for devices counted from the device’s production date.
2. The warranty includes free repair or replace for a functional e uivalent (the selection is performed by the manufacturer) of a non-operational device due to reasons
dependent on the manufacturer, including production and material defects, as far as defects are notified within the warranty period (item 1).
3. The e uipment subject to warranty shall be provided to the point, where it has been purchased or directly to the place of business.
4. The complete devices are subject to warranty, and the sort of defect shall be described in written in a correctly fulfilled claim notification.
5. If a claim is accepted, the manufacturer is obliged to perform warranty repairs as soon as possible, but no later than 14 working days since the device is provided to the
service of the manufacturer.
6. The repair period specified in item 5 can be extended, if there are no technical opportunities to perform the repair or the e uipment is conditionally accepted by the
service due to non-compliance of the warranty conditions by the person lodging a claim.
7. All service actions related to warranty are performed exclusively at the service of the manufacturer.
8. The warranty does not include the following defects of the device due to:
- manufacturer-independent reasons,
- mechanical defects,
- improper storage and transport,
- operation contrary to the instruction manual or purpose of the device,
- emergencies, including atmospheric discharges, failures of the power network, fire, flood, effect of high temperature and chemical agents,
- improper installation and configuration (contrary to the instruction manual)
9. The loss of rights resulting from the warranty always occurs, if it is confirmed that construction changes have been performed or repairs have not been performed at the
service of the manufacturer, or if serial numbers or warranty labels of the device are somehow replaced or damaged.
10. The responsibility of the manufacturer towards the purchaser is limited to the value of the device determined according to the wholesale price from the purchase day
suggested by the manufacturer.
11. The manufacturer does not bear any responsibility for damages resulting from failure, faulty operation or inability to use the device, particularly if it results from non-
compliance with advices and re uirements included in the instruction manual or contrary to purpose of the device.
