Pulsar DC/DC48125 User manual

1
DC/DC48125
v.1.0
DC/DC 48V/1,25A Step up DC/DC converter
EN**
Edition: 2 from 15.01.2016
Supercedes the edition: 1 from 26.08.2015
The module’s features:
The step up DC/DC converter
Example of use: increasing voltage from 12V to 48V DC
The input voltage range: 9,5÷28V DC
The output voltage range: 48V DC
The maximum load current 1,25A (60W)
The PSU technical output indicating converter failure
triggered by:
Short-circuit of the output
Output overload
Protections:
Short-circuit protection SCP
Overload protection OLP
High efficiency: 97%
Optical LED indication
Warranty –2 years from the production date
Mounting:
Mounting strip with adhesive tape
Mounting screws
Example of use of the DC/DC48125 step up converter.
Schematic diagram of the converter operation.

2
1. Technical description
The DC/DC 48V/1,25A (DC/DC48125) step up converter increasing the input voltage from the range between 9,5V÷28V DC to
the voltage range of 48V DC at the output. The maximum load current is Imax=1,25A (Pmax = 60W). The module does not feature
galvanic isolation between input/output (IN-AUX) and operates on common "ground" (0V) potential (IN- and AUX- terminals are
galvanically connected = common terminal).
1.1. Block diagram (Fig.1).
Fig.1. Block diagram of the converter’s module.
1.2. Description of components and connectors (Fig. 2, Table 1, Table 2).
Table 1.
No.
[fig.2]
Component’s description
[1]
IN LED light -red
[2]
Power connector of the DC/DC module
[3]
AUX LED light - green
[4]
The DC/DC module’s connector (power supply and PSU)
[5]
PSU LED light - red
[6]
Mounting strip
Table 2.
[2], [4]
Description of module’s connectors
+IN
- IN
DC supply input
(9,5V÷28V DC, power consumption from the power source)
+AUX
- AUX
DC supply output
(+AUX= +U, -AUX=GND)
PSU
Technical output of failure (OC type): OLP/SCP activation (short-circuit or overload
protection)
Failure status: hi-Z (high impedance), normal status: L (0V, GND)
Fig.2. The converter module’s view.

3
1.3. Technical parameters:
- Electrical parameters (Table 3)
- Mechanical parameters (Table 4)
Table 3.
The input voltage range (power supply)
9,5V÷28V DC
The output voltage range
48V DC +/- 1V
P module power
60W max.
Energy efficiency
91%÷ 97%
Ripple voltage
100mV p-p
Output current
1,25A max.
Current consumption by module systems
25 mA max.
Short-circuit protection SCP and overload OLP
110-150% of the module’s power, manual restart (the failure
requires disconnection of the DC output circuit)
Technical outputs
- PSU output indicating failure –overload or short-
circuit in the AUX output
- OC type, 50mA max. Failure status: hi-Z state (high
impedance), normal status: L level (0V)
Optical indication
- IN LED indicating DC power status
- AUX LED indicating DC supply status at the output
- PSU LED indicating failure - overload or short-
circuit in the AUX output
- red, normal status: is lit continuously
- green, normal status: is lit continuously
- red, normal status: does not lit, failure: is lit continuously
Operating conditions
II environmental class, -10°C ÷40°C, ensure air flow around
the unit for convection cooling
Declarations, Warranties
CE, 2 years from the production date
Table 4.
Dimensions
L=130, W=43, H=45 [+/- 2mm]
Mounting
tape or mounting screw x 2
Terminals
Ф0,41÷1,63 (AWG 26-14)
Net/gross weight
0,11/0,16 kg
2. Installation.
2.1. Requirements.
The DC/DC converter is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required
for a given country) for step up installations. The module should be mounted in confined spaces with normal relative humidity
(RH=90% maximum, no condensation) and temperature range from -10°C up to +40°C. The module should operate in vertical position
in order to provide free and convectional air flow.
The module's load balance should be done prior to installation. During normal operation, the total current of the receivers
should not exceed I=1,25A (while the power drawn from the module should not exceed Pmax=60W).
Proper operation of the module requires adequate current capacity of the power source; the power supply capacity should be
calculated using the formula below: PIN = 1,15 x PAUX
(PIN = 1,15 x IAUX x UAUX)
Example:
The converter will supply the receivers with a capacity of PAUX = 48W drawing a total current of IAUX = 1A at the voltage
UAUX = 48V. The minimum power supply capacity must therefore amount to: PIN = 1,15 x 1A x 48V = 55,2W.
The device should be mounted in a metal enclosure (cabinet). The rules for power supply, enclosures and shielding - according to
application - must be observed in order to meet the requirements of LVD and EMC directives.

4
2.2. Installation procedure.
1. Mount the enclosure (cabinet, etc.) and lead cables through cable glands.
2. Mount the DC/DC converter with adhesive tape or mounting screws.
3. Supply DC voltage to the + IN, -IN terminals with correct polarization.
4. Connect the receivers’ cables to the +AUX, -AUX connectors of the terminal block on the module’s board.
5. Connect the device cables (alarm control panel, indicator, LED light, etc.) to the PSU technical output if necessary.
6. Switch on the DC voltage (the red IN LED should be permanently illuminated, the AUX green LED should be permanently
illuminated).
7. Once the tests and operation control are performed, close the enclosure, cabinet, etc.
3. Converter 's module operation indication.
3.1. Technical output.
The converter is equipped with three diodes indicating operation status: IN, AUX, and PSU.
IN- red LED: during normal status (DC power supply) it is lit continuously. No DC supply is indicated by switching off the IN LED.
AUX- green LED: indicates DC supply status at the module’s output. During normal status, it is lit continuously, in case of short
circuit or overload the AUX led is off.
PSU- red LED: indicates module’s overload. During normal status, it is off, in case of short circuit or overload the LED lights
continuously.
3.2. Technical output.
The converter is fitted with one technical output indicating failure of the DC / DC module.
PSU- OLP/SCP (overload/short-circuit) output: - OC type output indicating overload/short-circuit of the module’s output.
During normal operation, the output is shorted to the AUX - (0V). In case of failure, the module disconnects the output and it is in the hi-
Z (high impedance) state during failure.
4. Maintenance and operation.
4.1. Converter overload.
The AUX output is protected with the PTC polymer fuse. If the load current exceeds Imax (110% ÷ 150% @ 25ºC of the
converter capacity), the output voltage will be automatically disconnected, which will be signaled by switching off the green AUX LED,
switching on the red PSU LED and a change in the status of the technical output. Voltage restoration requires disconnecting the output
load for approx. 1 min.
4.2. Maintenance.
All maintenance procedures can be performed after disconnecting the converter from the power network. The converter does
not require any specific maintenance; however, its interior should be cleaned with compressed air if used in dusty conditions.
WEEE LABEL
Waste electrical and electronic equipment must not be disposed of with normal household waste.
According to the European Union WEEE Directive, waste electrical and electronic equipment should be
disposed of separately from normal household waste.
