Pulsar PS602425 User manual

1
PS602425
PS 24V/2,5A enclosed switch mode power supply
Edition: 1 from 05.12.2011
Supercedes edition: …………
EN
Fe tures of the power supply unit:
• universal AC input voltage range 85÷264V
• high efficiency 1%
• LED optical signalisation
• protections:
• SCP short-circuit protection
• overvoltage OVP
• overvoltage protection (AC input)
• overload (OLP)
1. Technic l description.
1.1. Gener l description.
The power supply unit is intended for the feeding of alarm system equipments, which require 24V DC supply
voltage and current load I=2,5A. The design enables simple changing of the output voltage, within the range of 24V÷2 V
DC, using a potentiometer. The power supply unit is protected against short-circuit, overload and overvoltage.
1.2.Technic l p r meters.
Supply voltage 5 ÷ 264 V AC, 120 ÷ 370 V DC
Current consumption 0,6A@230VAC max.
Supply power 60W max.
Efficiency 1%
Output voltage 24V DC
Output current 2,5A
Output current t
AMB
<30°C 2,5 A - see graph 1.
Output current t
AMB
=40°C 1, A - see graph 1.
Voltage adjustment range 24 V ÷ 2 V DC
Ripple voltage 150mV p-p max.
Short-circuit protection SCP electronic, automatic recovery
Overload protection OLP 105-150% of power supply, automatic recovery
Overvoltage protection OVP U>115% ÷ 135% of the output, isolation
of the output voltage, automatic recovery
Optical signalisation green LED – presence of DC voltage
Operation conditions 2-nd enviromental class, temperature: -10
o
C÷40
o
C
relative humidity 20%...90%, without condensation
Dimensions (LxWxH) 159 x 97 x 3 [mm]
Net/gross weight 0,4 kg / 0,51kg
Protection class PN-EN 60950-1:2007 I (first) – requires a protective conductor (PE)
Connectors power-supply:Φ0,63-2,50 (AWG 22-10)
outputs : Φ0,63-2,50 (AWG 22-10)
Electrical strength of insulation:
- between input (network) circuit and output circuits of
power-supply (I/PO/P)
- between input circuit and PE protection circuit (I/P-
FG)
- between output circuit and PE protection circuit
(O/P-FG)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
Insulation resistance:
- between input circuit and output or protection circuit 100 MΩ, 500V/DC
Storage temperature -20ºC...+60ºC
Vibrations and impulse waves during transport according to PN- 3/T-42106

2
1.3. Output current vs temper ture.
Graph 1.
Allowable output current from the power supply
depending on ambient temperature.
2. Inst ll tion.
2.1 Requirements.
The power supply shall be mounted by the qualified installer having appropriate (required and necessary for a
given country) permissions and qualifications for connecting (operating) low-voltage installations. The unit shall be
mounted in closed rooms, according to the environment class II, of the normal air humidity (RH=90% max. without
condensation) and the temperature within the range from -10°C to +40°C.
The power supply shall be mounted in a close casing (a cubicle, a terminal device) and in order to fulfill LVD and
EMC requirements the rules for power-supply, encasing and shielding shall be observed according to application.
Due to the power supply design, the PE wire h s to be connected to the corresponding connector of the
supply unit. Oper tion without proper grounding of the power supply is not llowed!
2.2. Inst ll tion procedure.
1. Prior to installation of the power supply unit, make sure that power leads have been disconnected from the
230VAC mains.
2. Install the unit in the previously selected place.
3. Connect the 230VAC power leads. Connect the PE cable (yellow-green) to an appropriate terminal on the
power supply unit (marked with ).
The circuit of the shock protection sh ll be performed with p rticul r c re, i.e. the yellow nd green
protection wire of the power c ble sh ll be connected from one side to the termin l m rked by the
symbol of in the c sing of the power-supply. Oper tion of the power-supply without the properly
m de nd fully oper tion l circuit of the shock protection is
UNACCEPTABLE!
It c n result in f ilure of devices nd electric shock.
4. Connect load/loads to proper output connectors of the power supply (positive end is marked as +V,
negative end as -V).
5. Upon the completion of tests and trial activation, close the housing, cabinet etc.
2.3. Description of termin l.
Elements/connectors [Fig.1]
Description
L, N, L-N - input voltage connectors 230 V AC,
– protective conductor connector
-V Power supply output (0V)
+V Power supply output (+24V)
LED1 LED signals the presence of voltage at the unit’s
output
Fig.1. Description of terminal.
ADJ Potentiometer - output voltage adjust

3
2.4. Dimensions nd fitting of the PS602425 power supply.
Fig.2. Dimensions of power supply.
3. M inten nce.
All maintenance procedures can be performed after the disconnection of the power supply from the electrical grid.
The power supply does not require any special maintenance procedures, but in the case of significant dust accumulation,
dusting using compressed air is recommended.

4
WEEE designation
The waste electric and electronic equipment worn out may not be disposed of together
with standard household waste. According to the WEEE directive, applicable in the EU,
the separate neutralization methods should be used for electric and electronic
equipment.
Puls r K.Bogusz Sp.j.
Siedlec 150, 32-744 Łapczyca, Poland
Tel. (+4 ) 14-610-19-40, Fax. (+4 ) 14-610-19-50
e-mail:
[email protected] , [email protected]
http:// www.pulsar.pl
