Pulsar RAC24P User manual

RAC24P
v.1.0
RAC 24VAC/8x1A/PTC
RACK mounted power supply for up to 8 cameras with galvanic
isolation.
EN
Edition: 1 from 28.01.2016
Supercedes the edition: ------

www.pulsar.pl RAC24P RACK POWER CCTV
2
Cechy zasilacza:
•power output 8x1A/24V AC for powering
analog cameras (Σ Ι =8A max.)
•8 independent, galvanically separated outputs
protected by PTC 1A polymer fuses
•supply voltage 230V AC
•LED optical indication LED: AC, TEMP,
ALARM, AUX1 ÷ AUX8
•acoustic indication of failure
•control of voltage presence at the
AUX1 ÷ AUX8 outputs
•the ALARM technical output of collective failure
– relay type, activated by:
•230V AC power loss
•activation of the output fuse in the camera
power supply circuit
•too high temperature of the PSU (>70°C)
•protections:
•SCP short-circuit protection
•transformer overheat protection OHP
•overvoltage protection
•overload protection OLP
•forced cooling (fan)
•warranty – 2 year from the production date
Sample application of the RACK power supply unit.
CONTENTS:
1. Technical description.
1.1. General description
1.2. Block diagram
1.3. Description of PSU components and connectors
1.4. Specifications
2. Installation.
2.1. Requirements
2.2. Installation procedure
3. Operating status indication.
3.1. LED indication
3.2. Technical output
3.3. Acoustic indication
4. Operation and use.
4.1. Overload or short circuit of the PSU output
4.2. Maintenance
1. Technical description.
1.1. General description.
The RAC24P power supply unit is designer for supplying up to 8 analog cameras requiring voltage of 24V
AC and the total current capacity of 8A. The PSU has 8 independent, galvanically separated outputs protected by
PTC 1A polymer fuses. The power supply is fitted with the ALARM output of collective failure. In case of failure,
relay contacts are switched automatically (the corresponding led goes on). The power supply is located in an
enclosure adapted for mounting in standard RACK 19” cabinets.

www.pulsar.pl RAC24P RACK POWER CCTV
3
1.2. Block diagram.
Fig.1. The block diagram of the PSU.
1.3. Description of PSU components and connectors.
Table 1. Components of the front panel of the power supply.
Element no.
[Fig. 2] Description
AC OK – green LED, indicating the presence of 230V voltage
TEMP – red LED, indicating too high temperature of the power supply (>70°C)
Green LED AUX1 ÷ AUX8 – voltage indication at the AUX outputs
LED ALARM – red LED failure indication
AUX1 ÷ AUX8 – independently protected outputs
ALARM – technical output of collective failure – relay
BUZZER, micro switch, turning ON / OFF of acoustic indication
switch in the top position, indication ON
switch in the down position, indication OFF
230V AC INPUT, power socket 230V AC, power cable 1,5m included
F
MAINS
,fuse in the supply circuit 230V AC, T 6,3A/250V
Fig. 2. The front power of the power supply unit.

www.pulsar.pl RAC24P RACK POWER CCTV
4
Fig.3. The view of the PSU.
1.4.Specifications.
- electrical parameters (tab.2)
- mechanical parameters (tab.3)
- operation safety (tab.4)
- operating parameters (tab.5)
Electrical parameters (tab. 2).
Mains supply 195÷253V AC
Current up to 1A@230V AC max.
Supply power S 192VA max.
Output voltage 24V AC (+/-15%)
Output current 8 x 1 A (Σ
ΣΣ
Σ I = 8A) max. @24V AC
Short-circuit protection SCP 8 x PTC 1A, polymer fuse
Overload protection OLP 8 x PTC 1A, polymer fuse
Surge protection varistors
Overheat protection OHP internal transformer
Optical indication of operation: LED: AC, TEMP, ALARM, AUX1÷AUX8
Acoustic operation indication: Piezoelectric indicator ~75dB/0,3m
The ALARM technical output of collective failure Relay type: 1A@ 30VDC/50VAC
The F
MAINS
fuse in the 230V power supply circuit T 6,3A
Mechanical parameters (tab. 3).
Enclosure dimensions W=19”, H=2U; 482 x 88 x 223 mm (WxHxD)
Fixation four-point butt mounting to RACK profiles – the set include 4 M6 screws + cage nuts
Net weight 8,10kg / 8,50kg
Enclosure Steel plate RAL 9005, black
Connectors 230V AC input: the IEC C14 socket with a fuse, power cable 1,5m
(included)
Outputs: ALARM, AUX1÷AUX8: Φ0,5-2,1 (AWG 24-12) 0,5-1,5mm
2
Notes Forced cooling (fan).

www.pulsar.pl RAC24P RACK POWER CCTV
5
Operation safety (tab.4).
Protection class PN-EN 60950-1:2007 I (first)
Protection grade PN-EN 60529: 2002 (U) IP20
Electrical strength of insulation:
- between input and output circuits of the PSU (I/P-O/P)
- between input circuit and PE protection circuit (I/P-FG)
- between output circuit and PE protection circuit (O/P-FG)
3000 V/AC min.
1500 V/AC min.
500 V/AC min.
Insulation resistance:
- between input circuit and output or protection circuit 100 MΩ, 500V/DC
Operating parameters (tab.5).
Environmental class II
Operating temperature -10ºC...+45ºC
Storage temperature -20ºC...+60ºC
Relative humidity 20%...90%, without condensation
Vibrations during operation unacceptable
Impulse waves during operation unacceptable
Direct insulation unacceptable
Vibrations and impulse waves during transport According to PN-83/T-42106
2. Installation.
2.1. Requirements.
The PSU RACK shall be mounted by a qualified installer with appropriate permissions and qualifications for
230V/AC installations and low-voltage installations (required and necessary for a given country). The device shall
be mounted in confined spaces, according to the environment class II, with normal air humidity (RH=90% max.
without condensation) and the temperature from -10°C do +45°C.
During normal operation the total current consumption of the receivers cannot exceed I=8A.
As the PSU is designed for a continuous operation and is not equipped with a power-switch, therefore an
appropriate overload protection shall be guaranteed in the power supply circuit. Moreover, the user shall be
informed about the method of unplugging (usually through assigning an appropriate fuse in the fuse-box). The
electrical system shall follow valid standards and regulations.
2.2. Installation procedure.
1. Before installation, cut off the voltage in the 230V power-supply circuit.
2. Mount the power supply in a RACK 19" cabinet as shown below:
- Mount M6 cage nuts
- Secure the enclosure with 4xM6 screws
3. Connect the receivers’ cables to the terminals AUX1...AUX8.
4. If needed, the following technical connections can be made:
- ALARM – technical output of collective failure
5. Connect the ~230V AC power cord with the IEC C13 plug (included) to the 230V AC power supply and turn on
the power (~230V).
6. Check the PSU operation indicator.

www.pulsar.pl RAC24P RACK POWER CCTV
6
3. Operating status indication.
3.1. LED indication.
The PSU has 11 LED lights at the front panel:
GREEN LED:
•on – the PSU is supplied with 230V AC
•off – no 230V AC supply
RED LED:
•on – failure
•off – no failure
RED LED:
•ON – too high temperature of the power supply (>70°C)
•OFF – standard temperature of the power supply
GREEN LED:
•on – DC voltage in the AUX1…AUX8 output
•off – no DC voltage in the AUX1…AUX8 output
3.2. Technical output.
The power supply is fitted with the ALARM output of collective failure (relay type). A collective failure can
be triggered by the following events:
- 230V AC mains power failure
- Activation of the PTC polymer fuse in the camera power supply circuits
- Too high temperature of the power supply (>70°C)
Fig. 4. Electrical diagram of the ALARM collective output of failure.
CAUTION! In Fig.4 the set of contacts shows a potential-free status of the relay, which
corresponds to power supply failure.

www.pulsar.pl RAC24P RACK POWER CCTV
7
3.3. Acoustic indication.
A collective failure is indicated by the piezoelectric indicator, 1 beep every second. The acoustic indication
can be turned off by changing the ON / OFF position of the switch .
switch in the up position, indication ON
switch in the down position, indication OFF
4. Operation and use.
4.1. Overload or short circuit of the PSU output.
The AUX1 ÷ AUX8 power supply outputs are protected against short-circuit with PTC 1A polymer fuses. In
the case of fuse activation, disconnect the load from the power supply output for approximately 1 minute.
4.2. Maintenance.
Any and all maintenance operations may be performed following the disconnection of the PSU from the
power supply network. The PSU does not require performing any specific maintenance measures. In case of fuse
replacement, use a replacement of the same parameters.

www.pulsar.pl RAC24P RACK POWER CCTV
8
WEEE LABEL
Waste electrical and electronic equipment must not be disposed of with normal household
waste. Accordin to the European Union WEEE Directive, waste electrical and electronic
equipment should be disposed of separately from normal household waste .
GENERAL WARRANTY CONDITIONS
1. Pulsar (manufacturer) grants a two-year quality warranty for the equipment, starting from the production date.
2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (selected y the
manufacturer) if the malfunction is due to the manufacturer. It includes manufacturing or material defects, provided that
such defects have een reported within the warranty period (point.1).
3. The equipment su jected to warranty should e rought to the place of purchase or directly to the main office of the
manufacturer.
4. The warranty applies to complete equipment, accompanied y a properly filled warranty claim with a description of the
defect.
5. Should the claim e accepted, the manufacturer is o liged to provide warranty repairs, at the earliest convenience,
however not later that within 14 days from the delivery to the service centre of the manufacturer.
6. The repair period mentioned in point 5 may e prolonged, if there are no technical possi ilities to carry out the repairs,
or if the equipment has een conditionally accepted, due to the reaking warranty terms y the claimant.
7. All the services are carried out at the service centre of the manufacturer, exclusively.
8. The warranty does not cover the defects of the equipment, resulting from:
- reasons eyond the manufacturer's control,
- mechanical damage,
- improper storage and transport,
- use that violates the operation manual or equipment’s intended use
- fortuitous events, including lightning discharges, power failures, fire, flood, high temperatures and chemical agents,
- improper installation and configuration (failure to follow instruction).
9. The warranty is void in case of construction changes and repairs carried out y any unauthorized service center or in
case of damage or modifications to warranty stickers and serial num ers.
10. The lia ility of the manufacturer towards the uyer is limited to the value of the equipment determined according to
the wholesale prices suggested y the manufacturer on the day of purchase.
11. The manufacturer takes no responsi ility for the defects that result from the damaging, malfunctioning or ina ility to
operate the equipment especially when resulting from failure to comply with the recommendations and requirements
contained in the manual.
Pulsar
Siedlec 150, 32-744 Łapczyca, Polska
Tel. [phone], Fax. [phone]
e-mail: [e-mail], sal[email protected]
http:// www.pulsar.pl, www.zasilacze.pl
