Pulsar SWB-60 User manual

USER MANUAL
EN
Edition: 1 from 24.09.2020
Supersedes the edition:
SWB-60
Buffer power supply system for PoE switches,
52VDC/7Ah/60W

www.pulsar.pl SWB series
2
Features:
Supply voltage ~200 - 240 V
High efficiency (82%)
Battery charging and maintenance control
Deep discharge battery protection
Battery charging current: 1 A / 2 A, jumper electable
Metal enclosure –color white RAL9003
Removable universal mounting plate
Optical indication
Protections:
SCP short circuit protection
OLP overload protection
OVP overvoltage protection
surge protection
antisabotage protection: unwanted enclosure
opening
against reverse polarity connection
Warranty –2 years from production date
TABLE OF CONTENTS:
1. Technical description.
1.1. General description
1.2. Block diagram
1.3. Description of PSU components and connectors
1.4. Specifications
2. Installation.
2.1. Requirements
2.2. Installation procedure
3. Maintenance
1. Technical description.
1.1. General description.
Buffer power supply system for PoE switches. SWB-60 is designed for uninterrupted power supply of PoE
switches with 52 V DC. It was designed based on high energy efficiency switching power supply module placed in metal
enclosure (color RAL 9003). DC / DC converter used to increase voltage allows to reduce costs of system by limiting
batteries to 1 pc. Enclosure has a place for 7Ah / 12 V (SLA) battery and is equipped with a tamper switch signaling
opening the door (front panel). Device is equipped with removable universal mounting plate, which allows to mount PoE
switches with dimensions up to 230x110x45 (WxHxD) [mm].
For example Pulsar’s models: S64, SG64, SFG64, SFG64F1, S108, SG108.
Device can operate in one of two configurations:
1. PoE output power 60 W + 1 A battery charging
2. PoE output power 60 W + 2 A battery charging
1.2. Block diagram (Fig.1).
Fig.1. Block diagram of PSU.

www.pulsar.pl SWB series
3
Mounting plate
W2xH2
1.3. Description of PSU components and connectors.
Table 1. View of PSU (see Fig. 3).
Element no.
Description
[1]
PSU module
[2]
Mounting holes
[3]
Screws for locking mounting plate
[4]
Cable bushing
[5]
TAMPER; microswitch of antisabotage protection (NC)
[6]
Switch power cable terminated with a DC 2.1/5.5 plug
[7]
BAT +, BAT - battery output + BAT red, - BAT black
[8]
Selection jumper for charging current
Ibat =1,0 A
Ibat =2,0 A
Description: jumper installed, jumper removed
Fig.3. View of PSU.
1.4. Specifications:
- electrical parameters (tab. 3)
- mechanical parameters (tab. 4)
- operation safety (tab. 5)
- operating parameters (tab. 6)

www.pulsar.pl SWB series
4
Table 2. Specifications.
Power supply
~ 200 –240 V; 1 A; 50/60 Hz
Inrush current
40 A
Efficiency
82%
PoE supply
52 V DC; 60 W
Ripple voltage
100 mV p-p max.
Battery charging voltage
11-13,8 V DC
Battery charging current
1 A / 2 A jumper selectable
Short circuit protection (SCP)
electronic, automatic recovery
Overload protection (OLP)
105 –150% of power supply, automatic recovery
Surge protection
varistors
Current consumption by PSU
during battery-assisted operation
about 40 mA
LED optical indication output
LED AC - presence of AC voltage
LED DC - presence of DC voltage in the output of the PSU
LED CHARGE - battery charging process
Connectors
Power input: Φ0,63-2,50 (AWG 22-10)
PoE power supply output: DC plug 2.1/5.5
BAT output: battery wires 6,3F –45cm, angle muffs ML062 (hole 5,2 mm)
Operating conditions
Temperature -10°C ÷ 40°C,
Relative humidity 5%-90% without condensation
Dimensions
W=300, H=300, D+D1=105+8 [+/- 2mm]
W1=305, H1=305 [+/- 2mm]
W2=230, H2=110, D2=45 [+/- 2mm]
Enclosure
Steel sheet, DC01 0,7mm color RAL 9003
Closing
Cheese head screw x 2 (at the front, lock assembly possible)
Notes
Enclosure does not adjoin assembly surface so that cables can be led.
Additional equipment
Mounting screws (x4)
Net / gross weight
2,75 / 2,88 [kg]
Declaration
CE
Table 3. Operation safety.
Protection class EN 62368-1
I (first)
Degree of Protection EN 60529
IP20
Electrical strength of insulation:
- between input input and output circuits of the PSU
- between input circuit and protection circuit
- between output circuit and protection circuit
2500 V AC min.
1500 V AC min.
500 V AC min.
Insulation resistance:
- between input circuit and output or protection circuit
100 MΩ, 500 V DC
Table 4. Operating parameters.
Environmental Class
II
Operating temperature
-10ºC...+40ºC
Storage temperature
-20ºC...+60ºC
Relative humidity
20%...90%, without condensation
Vibrations during operation
unacceptable
Impulse waves during operation
unacceptable
Direct insulation
unacceptable
Vibrations and impulse waves during transport
Wg PN-83/T-42106
2. Installation.
2.1 Requirements.
Device is to be mounted by a qualified installer, holding relevant permits and licenses (applicable and required
for a given country) for ~230 V in and low-voltage installations. The unit should be mounted in confined spaces, in
accordance with the II environmental class, with normal relative humidity (RH=90% maximum, without condensing) and
temperature from -10°C to 40°C.
As power supply is designed for a continuous operation and is not equipped with a power-switch, therefore, an
appropriate overload protection in power supply circuit should be provided. Moreover, user should be informed how to
disconnect power supply unit from mains supply (most frequently through separating and assigning an appropriate fuse in
the fuse-box).

www.pulsar.pl SWB series
5
2.2 Installation procedure.
CAUTION!
Before installation, cut off voltage in 230 V power-supply circuit. To switch power off, use an
external switch, in which distance between contacts of all poles in disconnection state is not
less than 3mm.
It is required to install an installation switch with a nominal current of min. 3 A in the power supply
circuits outside the power supply unit.
1. Mount the device in a selected location and connect the wires.
2. Remove mounting plate by unscrewing screws, then release plate from hooks (slide up and slightly pull).
3. Connect the power cables (~230 V) to L-N clips of the PSU. Connect the ground wire to the clip marked by the
earth symbol . Use a three-core cable (with a yellow and green protection wire) to make the connection.
Lead the cables to the appropriate clips through the insulating bushing of the PSU..
Shock protection circuit shall be done with a particular care: yellow and green wire coat
of power cable should be connected to terminal marked with the grounding symbol on PSU
enclosure. Operation of PSU without the properly made and fully operational shock protection
circuit is UNACCEPTABLE! It can cause damage to equipment or an electric shock.
4. Connect battery in correct polarity.
5. Make the selection is done with use of the IBAT jumpers (see: tab.1)
6. Screw switch to mounting plate.
7. Connect switch using cable terminated with a DC 2.1/5.5 plug.
8. Mount inside enclosure.
9. Connect the power 230 V
10. After installing and checking proper working, the enclosure can be closed.
3. Maintenance.
Any and all maintenance operations may be performed following the disconnection of the PSU module from the
power supply network. The PSU does not require performing any specific maintenance measures, however, in the case
of significant dust rate, its interior is recommended to be cleaned with compressed air. In the case of a fuse replacement,
use a replacement of the same parameters.
WEEE LABEL
Waste electrical and electronic equipment must not be disposed of with normal household waste.
According to the European Union WEEE Directive, waste electrical and electronic equipment
should be disposed of separately from normal household waste.
CAUTION! The power supply unit is adapted for cooperation with the sealed lead-acid batteries (SLA). After the operation period they must
not be thrown but recycled according to the applicable law.
Pulsar sp. j.
Siedlec 150, 32-744 Łapczyca, Poland
Tel. [phone], Fax. [phone]
E-mail: [e-mail], [email protected]
http:// www.pulsar.pl, www.zasilacze.pl
