Pulsar SFG10F8 User manual

1
SFG10F8
v1.0
Optical switch SFG10F8 (8xSFP, 2xRJ45)
PL
Edition: 1 from 17.01.2020
Supercedes the edition: ----------- EN
Features:
10 ports optical switch:
8 SFP ports 10/100/1000Mb/s
2 ports 10/100/1000Mb/s RJ45
Supports auto-learning and auto-aging of MAC
addresses (8K size)
Built-in switch mode power supply
PSD12020 12 V DC
Additional mounting elements
LED indication
warranty –2 year from the production date
Example of use.
1. Technical description
1.1.General description.
SFG10F8 is 10-port optical switch designed for data transmission over Ethernet via fiber optics and UTP cables. Cat
5e. Switch has 8 SFP sockets (marked SFP1 ÷ SFP8), which after using SFP modules (GBICs) enable fiber optic transmission.
G1 and G2 ports are used to connect further network devices through RJ45 socket. The LEDs at the front panel indicate the
operation status (description in the table below).
Connectivity via fiber optics cables allows for fast and stable data transmission over long distances, resistant to
electromagnetic interference and adverse environmental conditions. It also enables easy expansion of network in future.

2
1.2 Block diagram.
Fig. 1. Block diagram.
1.3. Description of components and connectors.
Table 1. (see Fig.2)
Element no.
(Fig. 2)
Description
[1]
2 x RJ45 ports
[2]
8 x SFP ports (1÷8)
[3]
DC power supply socket
[4]
Additional mounting elements
Fig. 2. The enclosure view.

3
1.4. Technical parameters.
Table 2.
Ports
10 10/100/1000Mb/s ports (8 x SFP + 2 x RJ45)
with connection speed auto-negotiation and MDI/MDIX Auto Cross
Protocols, Standards
IEEE802.3i, 802.3u, 802.3x CSMA/CD, TCP/IP
Bandwidth
16Gbps
Transmission method
Store-and-Forward
Optical indication of operation
Switch power supply;
Link/Act;
Power supply
~100-240 V; 50/60 Hz; 0,3 A
switched mode power supply PSD12020 12 V DC / 2 A / 24 W max.
Operating conditions
temperature -10°C ÷ 40°C,
relative humidity 5 % - 90 %, no condensation
Dimensions
W=221, H=29, D=115 [+/- 2mm]
Additional equipment
surface mounting sheets
Net/gross weight
0,9 / 1,1kg
Protection class
EN 60950-1:2007
II (second)
Storage temperatur
-20 ºC÷60 ºC
Declarations
CE
2. Installation
2.1. Requirements
The unit should be mounted in confined spaces, in accordance with the 2nd environmental class, with normal relative
humidity (RH=90% maximum, without condensation) and temperature from -10°C to +40°C. Ensure the free flow of air around
the unit. The PSU shall work in a vertical position that guarantees sufficient convectional air-flow through ventilating holes of the
enclosure.
The device is designed for a continuous operation and is not equipped with a power-switch. Therefore, an appropriate
overload protection in the power supply circuit should be provided. The electrical system shall be made in accordance with
applicable standards and regulations.
2.2. Installation procedure
1. Install GBIC’s to SFP sockets.
2. Connect switch to the PSD12020 12 V DC power supply unit desktop type.
3. Connect the power supply to the 230 V socket.
4. Connect devices to G1, G2 ports.
5. Check the optical indication of the switch operation (see Table 3).

4
Connection schemes.
3. Operation indication.
Table 3. Operation indication
OPTICAL INDICATION OF THE SWITCH's POWER SUPPLY
GREEN LED LIGHT (Power)
Indication of the switch's
power supply
OFF –no power supply of the switch
ON –power supply on, normal operation
OPTICAL INDICATION AT THE SFP PORTS (1÷8)
GREEN LED LIGHT (SFP)
The connection status of LAN
devices and data transmission
OFF- no connection
ON - the device is connected
Blinking –data transmission
OPTICAL INDICATION AT THE UP LINK PORTS
GREEN LED LIGHT
OFF- no connection/ the device is connected 10/100 Mb/s
ON –the device is connected 1000 Mb/s
YELLOW LED LIGHT (LINK)
The connection status of LAN
devices and data transmission
OFF- no connection
ON - the device is connected 10/100/1000Mb/s
Blinking –data transmission

5
