Pulsar P-TRPV1 User manual
P-TRPV1
v1.1
P-TRPV1 -set of passive HD video and power transmitters
Edition: 2 from 05.06.2019
Supercedes the edition: 1 from 01.06.2017 EN
1. Technical description.
The P-TRPV1 is a set of passive devices used for HD video and power transmission using a twisted pair cable.
The video signal is transmitted using one twisted pair, while the power is supplied using two twisted pair cables. The set of
devices matches the impedance of the coaxial cable (75Ω) to the impedance of the symmetrical cable (100Ω).
In order to achieve the best transmission quality and interference immunity, use UTP cable cat. 5 (or higher). Make sure the
cable is properly prepared when making the connection. The RJ45 terminal crimp diagram is shown in Figure 1 presented
below:
Caution! An improperly made cable may cause damage to the camera.
The P-TRPV1 modules are terminated with two types of connectors:
a) the BNC plug (HD-CVI / HD-TVI / AHD video transmission),
b) JACK 2,1 / 5,5 power socket (camera power supply).
The module is equipped with LED (located indoor the RJ45 connector). Red LED indicating the supply voltage.
Fig.1. The RJ45-RJ45 (T-568B) wiring diagram.
The use of the P-TRPV1 set significantly reduces the CCTV system installation time. To install the cameras, simply crimp the
RJ45 connectors (making a straight RJ45-RJ45 cable) and connect the appropriate video and power terminals.
EN
2. Technical parameters.
The video signal
1,0 Vp-p, 75Ω
Video transmission range (UTP 5e or higher)
HDCVI
720p
450m
1080p
250m
3 / 4 / 8 Mpx
180m
HD-TVI
720p
230m
1080p
230m
3 / 4 / 5 / 8 Mpx
200m
AHD
720p
320m
1080p
200m
3 / 4 / 5 / 8 Mpx
200m
CVBS
960H
450m
Video bandwidth
0 ... 50 MHz ( -3 dB )
Impedance of the coaxial connector / connector type
75Ω / BNC plug (on the cable 100mm)
Impedance of the unbalanced connector / connector
type
100Ω / RJ45 socket
Attenuation (loop-through)
-0,5dB / 5MHz
CMRR
60dB / 5MHz
The maximum permissible input voltage
12-15 V DC
The maximum permissible current
1 A (for 12 V)
Operation temperature
-10 °C ÷ 55 °C
Storage temperature
- 40 °C ÷ 60 °C
Permissible relative humidity
<95%
Dimensions
22 × 10 × 40mm (with cable - 180mm length)
Net / gross weight
0,075kg
Declarations, warranty
CE, one year from the production date
3. Examples of application set P- TRPV1.
Fig. 2. Video and power transmission using twisted pair.
Pulsar sp. j.
Siedlec 150, 32-744 Łapczyca, Poland
Tel. (+48) 14-610-19-40, Fax. (+48) 14-610-19-50
http:// www.pulsar.pl, www.zasilacze.pl
