Pulsarlube E series User manual

Remove contaminants around
the lube point.
Remove the grease nipple and install
appropriate adaptors.
To position the window properly, align the
on the housing cap with the on the body.
When the selected dispensing period of
the Pulsarlube E has completed, remove
the lubricator from the application.
Using a hand tool such as a flat-head
screwdriver, detach the PCB from the unit.
Remove the batteries.Firmly push the Mode Selector into the slot
of the desired period.
Unscrew the screws to remove the battery
cover.
Installation/Disposal GuidelinesProduct Details
Turn the housing cap counterclockwise
and unscrew the cap.
Remove the protector.
Housing
Cap
Battery Cover
Battery
Piston
PCB
Base
Lubricant
Reservoir
Protector
Mode
Selector
Connecting
Thread (1/4" PT)
16
Note the installation date and the scheduled date of
lube cycle completion on the label of the Pulsarlube E.
The Pulsarlube E is an eco-friendly product that can
be disposed of separately. Turn the housing cap
counterclockwise to disassemble the product for
proper disposal.
Pull out the red Mode Selector from the
default OFF position.
2
Dispose of remaining plastic components
complying with local regulations for recycling.
Warning
Do not cut, puncture, or reuse lubricator.
Note
3
4
5
9
7
8
12
10
11 14
13
If the product is installed at a 45°
or 90° angle, please use an angle
adapter with a diameter greater than
or equal to 1/4".
For remote installation using an 8mm
O.D. tubing, keep the maximum
distance at 1m (3ft) or less.
High backpressure can cause a delay
in dispensing (must be under 5 bar).
Mounting Installations
Ensure a clear passage using a manual
grease gun.
Note1
Remove any hardened grease
by purging the lube point with a manual grease gun.
Note2
The grease in the equipment and the grease
contained in the unit should be the same or compatible.
Note
Please note there is a delay before the actual dispensing
starts. It may take up to 1~3 weeks for enough gas to be formed
depending on the dispensing setting & installation condition.

Mounting Methods
Pulsarlube E Standard Lubricants
Note OEM filling is available upon request under special terms and conditions. Please
contact your local distributor for more information.
Rev.02
The World Leader of Automatic Lubrication
Product Certifications
Certifications
The Pulsarlube E is designed for single
point lubrication only. Direct mount is
always preferable. For applications not
allowing any direct mounts, remotely mount
the unit using appropriate accessories and
keep the distance from the lube point as
short as possible.
For remote installation using a tube, use an
8mm O.D. (5/16") tubing pre-filled with the
same or compatible grease as the grease
contained in the unit.
Warning
Locations: Intrinsically Safe, SÉCURITÉ INTRINSÈQUE,Exia
Potential electrostatic charging hazard; clean only with a damp cloth
Do not change, replace, or charge battery cells
Temp Code T4: -25°C ≤ TA≤ +55°C
Substitution of components may impair Intrisic Safety: AVERTISSEMENT:
LA SUBSTITUTION DE COMPOSANTS PEUT COMPROMETTRE LA SÉCURITÉ INTRINSÈQUE
If ignitable gasses are present, touch only with an insulating object or while wearing an electrostatic grounding device
To prevent ignition of flammable or combustible atmospheres, read, understand, and adhere to manufacturer’s live
maintenance procedure.
Warning
Shelf life and Product Warranty The shelf life of the Pulsarlube E unit is 1 year from the date
of production. Product warranty is limited to original defects in material and workmanship and
will not cover any collateral damage due to mishandling, abuse and/or any other inappropriate
use of this product. Warranty period is 1 year from the date of purchase.
Dispensing Volume
60ml 120ml 240ml
1 month 2.00ml/day 4.00ml/day 8.00ml/day
3 month 0.67ml/day 1.33ml/day 2.66ml/day
6 month 0.33ml/day 0.67ml/day 1.33ml/day
9 month 0.22ml/day 0.44ml/day 0.89ml/day
12 month 0.17ml/day 0.33ml/day 0.67ml/day
Dispensing Volume Chart
Note
Dispensing volumes (ml/day) are calculated assuming the lubricator is operating at
1 atm (14.7 psi), 20˚C. Output volume may vary with ambient temperature changes,
atmospheric pressure changes, consistency of lubricant, or any resistance or
backpressure existing at the lube point (bearing or passage).
User Manual
Series
(60ml /120ml /240ml)
Dispensing
Period
This product is a disposible unit. Please replace with a new unit once set dispending period has completed.
Grease Grease Type Description
Excellent extreme pressure lubricant containing
solid lubricants
Superior high speed (over 3,000 rpm)
or high DN lubricant
NSF H1 registered food grade lubricant
High oxidation stability lubricant
Multipurpose lubricant fortified with extreme
pressure additives and MoS
Synthetic lubricant for extreme low temp
applications (below 15˚C)
High vibration-resistance lubricant
High performance multipurpose lubricant
Multi Purpose with MoS
Low Temperature
High Temperature
H1 Food Grade
High Speed
Heavy Duty
Multi PurposePL1
PL2
PL3
PL4
PL5
PL6
PL7
PL10 Electric Motor Bearing
Class I, Div. I, Group A, B, C, D
Class II, Div. I, Group E, F, G
22
Pulsarlube USA, Inc.
TEL:[phone] FAX :[phone] www.pulsarlube.com / [email protected]
1480 Howard Street, Elk Grove Village, IL 60007, USA
