Pulse Shower Spas ErgoSlideBar 4001-SSP User manual

4001-SSP
SlideBar
Ergo
IMPORTANT INSTALLATION QUESTIONS
Check local code for proper placement
of ErgoSlideBar to meet requirement
such as ADA or ANSI 117.1 Consumer
Safety Requirements.
ERGOSLIDEBAR MUST BE MOUNTED
THROUGH SHOWER WALL AND
SCREWED DIRECTLY TO WOOD OR
METAL STUD.
Before returning your ErgoSlideBar to
the store or have any question about
installation or missing parts please
visit the CUSTOMER CARE area on our
website www.PulseShowerSpas.com.
INSTALLATION INSTRUCTIONS
TOOLS REQUIRED FOR INSTALLATION
Electric Drill
1/8” wood or metal drill bit
1/4” masonry drill bit
Tape measure
Screwdriver
Level
WARRANTY
Please visit
www.PulseShowerSpas.com for our
Manufacture’s Limited Warranty
information.

Toll Free: 888.785.7320
www.PulseShowerSpas.com
Position mounting anges and mark hole locations. Drill 1/8” pilot holes
through shower wall into wood or metal stud.
NOTE: If wall is tiled, drill through tile (only) with a 1/4” diameter masonry
or ceramic tile drill bit and then change to the 1/8” drill bit to complete.
HAND HELD HOLDER
INSTALLATION
SHOWER ARM MOUNT
INSTALLATION
Attach shower
arm mount to your
existing shower
arm using supplied
washer.
Shower arm NOT
INCLUDED.
PARTS INCLUDED
• L-type stainless steel rail
• 5 Function hand held
• 72” Shower hose
• Installation manual
• Shower arm mount with
hand held holder
Once the ErgoGrabBar is securely fastened to wall, align cover plate
locking tabs with slots in ange. Rotate TWIST-LOCK cover plate
counterclockwise approx. 1/4” turn to lock in place.
STEP 1
STEP 2
STEP 3
INSTALLATION
A
B
C
PRODUCT DIMENSIONS
DETAIL MOUNTING INSTALLATION
Install mounting screws through grab bar mounting bracket and directly
into wood/metal stud or bracing. Use masonry anchors if necessary.
