Pulse Shower Spas AquaRain User manual

AquaRain Shower System
Model #1019-BN & 1019-CH
Owner's Manual
AQUARAIN

2
AquaRain Parts Legend
1. Shower Head
2. Screen Washer
3. AquaRain Body
4. Escutcheon
5. Set Screw
6. Slide Bar
7. Slide Bar Mounts .......... (2)
8. Screw 3.375" ................. (2)
9. Mount Covers................. (2)
10. Wall Anchors ................. (2)
11. Tapered Nylon Sleeve
12. Soap Dish
13. Handshower
14. Rubber Washer
15. Handshower Hose
5
4
2
3
1
14
15
12
13
11
10
10
9
9
8
8
7
7
6

3
Installation Instructions
Thank you for choosing the AquaRain Shower System by PULSE ShowerSpas!
Assembly and installation of the AquaRain Shower System is
designed to be quick and easy. If you have installation questions
or performance problems, call PULSE Customer Service toll free
at 888-785-7320 or visit www.pulseshowerspas.com.
Please read instructions carefully, become familiar with all parts,
installation procedures and tools required. Follow steps in order
presented to help avoid mistakes.
FOR NEW CONSTRUCTION OR
COMPLETE REMODEL
•
A hot/cold mixing valve is required (NOT INCLUDED)
TOOLS REQUIRED
Drill (preferably cordless), (1/4") 6mm masonry/tile drill bit,
Phillips screwdriver, pipe wrench.
ASSEMBLY
1. Remove existing shower head and shower arm.
 2. WrapthreadsofshowerpipewithTeontapeand/orpipe
sealant to ensure no leaks. (Diagram A)
3. Slide escutcheon over threaded shower pipe. (Diagram B)
4. Insertthreadedpipeintofemalewallttingandtighten
securely. Use diverter body to tighten by hand or use a pipe
wrench on inlet pipe closest to wall. (Diagram C)
CAUTION — DO NOT USE SHOWER ARM TO TIGHTEN
5. While gently pushing up on connection between shower
arm and top tee to ensure AquaRain is level, slide escutch-
eon against wall. (Diagram E) Secure set screw. (Diagram F)
CAUTION — DO NOT OVER-TIGHTEN SET SCREW
6. Insert rubber washer in shower head and secure shower
head to shower arm.
7. Hold Adjustable Slide Bar (6) in desired mounting location.
Evaluate range of adjustment and potential interference of
handshower hose (15) (Diagram G).
8. Mark wall for two mounting holes. Before drilling ensure no
live plumbing can be damaged.
9. Slowly drill 1/4” (6mm) wide by 1” (25mm) deep holes 22
5/8 inch (575mm) apart. Make sure holes are plumb.
IMPORTANT: Supplied anchors are for solid surface only
i.e.tile,marbleetc.Ifmountingtoholloworberglasswall,
adierentanchor/screwandholesizemayberequired.
10. Insertwallanchors(10)untilushwithwall.Slidetop
mount (7) over slide bar (Diagram H) and secure with screw
(8) (Diagram I). Slide plastic soap dish (12) (Diagram J) onto
slide bar followed by narrow end of tapered nylon sleeve
(11) (Diagram K). Align tab on soap dish with slot on sleeve
andpushsoapdishdownuntilush.(DiagramL)
11. Slide lower mount (7) over slide bar and secure screw (8).
12. Press covers (9) into mounts (7) (Diagram M).
13. Place washer (14) in hex head of hose (15) and connect to
diverter outlet. Place washer (14) in tapered end of hose
and connect handshower (13). Place hand shower into
holder.

2019-Rev.A
Usage
Diverter control switches from the shower head and hand
shower functionality.
Turn face of hand shower to switch settings.
Adjust the hand shower position by loosening the hand shower
hanger and sliding up or down.
Alwaysturncoldwateronrsttohelppreventanyaccidental
burning or scalding; especially for children and elderly.
DO NOT use any part of the AquaRain Shower System as a
support device.
Care and Maintenance
To keep your ShowerSpa looking new, wipe down after each
use with a soft cotton cloth.
Protect your ShowerSpa from hard water stains and mineral
deposits by periodically using an auto spray wax.
Clean using mild liquid soap and a non-abrasive sponge or
cloth. Rinse with clean water.
Do Not Use Any Kind Of
Chemicals Or Abrasives!
Lifetime Limited Warranty
1. Defects Covered; Warranty Period. Pulse Shower Spas, Inc.
(“Pulse”) warrants to the original consumer purchaser who
purchases this shower spa (the “Product”) for use in his or
her own home, that the Product will be free from defects in
material and manufacturing workmanship for as long as the
original consumer purchaser owns that same home. For all
other purchasers (including, but not limited to purchasers for
industrial, commercial and business use), the above warranty
will apply for a period of 5 years from the original date
of purchase.
2. Remedy. If the Product does not conform to the above
warranty, Pulse, at its option, will repair or replace the
Product, free of charge, or refund your purchase price. For
warranty claims, please visit www.pulseshowerspas.com/
index.php/warranty. Pulse may require that you return the
Product to Pulse, shipping prepaid, in which case Pulse will
provideyouwithareturnmaterialsauthorizationnumber
(RMA). Pulse may also require that you provide evidence of
the date you purchased the Product. Pulse will ship a new or
repaired Product to you, at the expense of Pulse, or refund
your purchase price. Service labor performed by you or others
in connection with the removal or replacement of the Product
will not be reimbursed by Pulse.
3. Exclusions. Pulse shall not be responsible for failure of
the Product, and the above warranties will not apply, if the
Product fails as a result of improper installation, improper
use,modicationsorrepairsbyanyoneotherthanPulse,or
accident or abuse (including damage during shipment).
4. Warranty on Repairs and Replacements. For consumer
purchasers who purchased the Product for home use, repaired
or replacement Products will continue to be covered under
this warranty for as long as he or she owns that same home.
For other purchasers, repaired or replacement Products will
be covered for the balance of the original warranty period.
5. No Other Warranties; Limitation of Liability. OTHER
THAN THE LIFETIME LIMITED WARRANTY STATED ABOVE,
PULSE DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, TO THE EXTENT PERMITTED BY APPLICABLE
LAW. THE REMEDIES STATED ABOVE ARE YOUR SOLE
REMEDIES IN CONNECTION WITH THIS WARRANTY. IN NO
EVENT WILL PULSE BE LIABLE TO YOU FOR ANY DAMAGES,
WHETHER DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL, INCLUDING BUT NOT LIMITED TO LOST
PROFITS OR BUSINESS INTERRUPTION, ARISING OUT OF
OR RELATING TO THE PRODUCT OR ITS USE, WHETHER
UNDER A CONTRACT, WARRANTY, TORT, OR ANY OTHER
CAUSE OF ACTION, EVEN IF PULSE HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. NOTWITHSTANDING
THE TERM OF ANY LIMITED OR IMPLIED WARRANTY, OR
IN THE EVENT THAT ANY LIMITED WARRANTY FAILS OF
ITS ESSENTIAL PURPOSE, IN NO EVENT WILL PULSE’S
ENTIRE LIABILITY EXCEED THE PURCHASE PRICE OF THE
PRODUCT. SOME STATES AND PROVINCES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS LIMITED
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU
MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE AND PROVINCE TO PROVINCE.
