Pulse Shower Spas Niagara 3030-WMTF-BN User manual

Niagara Wall Mounted Tub Filler
Model #3030-WMTF-BN, 3030-WMTF-CH, 3030-WMTF-MB, 3030-WMTF-ORB
PW-93030-80TFWBRN, PW-93030-80TFWCP,PW-93030-80TFWBM, PW-93030-80TFWBRZ
Owner's Manual

2
Wall Mounted Tub Filler
Please Read The Following Instructions
COMPLETELY Before Beginning!
Our goal is to ensure your installation goes smoothly and safely. Please read these
instructions carefully and follow recommendations for plumbing and mounting. After
reading instructions, if you determine you do not have the necessary skills and/or tools,
we recommend that a licensed plumbing contractor complete the installation.
If you encounter any problems during installation
PLEASE VISIT CUSTOMER SUPPORT AT
WWW.PULSESHOWERSPAS.COM
Before returning your wall mounted tub ller to the store
You Will Need The Following Tools
Soft pencil or felt pen to mark tile
Allen wrench
Safety glasses
Phillips screwdriver
Reciprocating saw w/metal cutting blade (Sawzall®)
Channel locks or adjustable wrench
Drill (Preferably cordless)
Plumber's Tape

Parts Legend
1. Handle
2. Set Screw
3. Set Screw Cover
4. Valve Cover
5. Cartridge Nut
6. Valve Cartridge
7. Tub Filler Body
8. Trim Mounting Plate
9. 3/4 NPT Nipple.......................2
10. Diverter Cartridge
11. Diverter Cartridge Nut
12. Diverter Handle
13. Diverter Handle Pin
14. Spout
15. Handshower
16. Washers......................................3
17. Hose
18. Handshower Holder
19. Glue
20. Nuts................................4
21. Screws............................4
22. Anchors..........................4
3

4
Installation Instructions
Behind
wall stud
6 in.
2.5” Step 1
Step 2
9”
Behind
wall stud
6 in.
2.5” Step 1
Step 2
9”
1
2
3
Make sure the water supply (hot/cold) line is 6 inches
apart from the center of each pipe.
Make sure you leave a 9 inch by 2.5 inch rectangular
opening on your nished wall.
Step 1: Add plumber's tape to nipple as shown (shorter
end of the thread).
Step 2: Screw both nipples into your plumbing
Screw nuts onto nipple until the end is ushed with
the wall.
Slide trim into place to gure out positioning
BEFORE YOU BEGIN
Measure the following to ensure
your tub ller will t properly.
4

5
Installation Instructions
Step 1: Mark trim holes on wall with a pencil. Use a
level to make sure everything is leveled.
Make sure you have 0.75 inches on nipple protruding
from wall
Drill holes onto wall
0.75”
Tile
Trim
Tile
Studs
0.75”
Tile
Trim
Tile
Studs
5 8
9
6
Add anchors and secure trim with the provided screws.
Make sure the nished side of the trim in facing outward
Used the nished nuts. Screw onto nipple at side rst
(against trim) and secure.
7

6
Installation Instructions
Add washers to both ends of hose. Connect hex head
end to swivel joint (6) and tapered end to handshow-
er. Place the tapered end of the hose into the hand-
shower holder
Finished product
Step 3
Step 1
Tape
Glue
Back of handheld holder
Step 2
11
1210
Slide washer onto tub ller connection and screw
onto nipples.
Step 3
Step 1
Tape
Glue
Back of handheld holder
Step 2

7
water ON
Hot Cold
180° Fold Away arm
OFF/Cold
ON/Hot
water ON
Hot Cold
180° Fold Away arm
OFF/Cold
ON/Hot
Turning tub ller ON, lift valve handle up.
TUB FILLER FUNCTIONS: HANDSHOWER FUNCTIONS:
While ON, turn handle to the left for HOT and right
for COLD.
Turn diverter handle to the right to turn on handshower,
and keep going for Hot water.
Fold arm away (left/right)
For handshower to be OFF the diverter handle should
be facing up. The closer to the OFF position, the colder
the water will be.
Installation Instructions
water ON
Hot Cold
180° Fold Away arm
OFF/Cold
ON/Hot
water ON
Hot Cold
180° Fold Away arm
OFF/Cold
ON/Hot
water ON
Hot Cold
180° Fold Away arm
OFF/Cold
ON/Hot
OPERATION:

PULSE ShowerSpas, Inc. | 297 Anna Street | Watsonville, CA 95076 | 831.724.7300
www.PulseShowerSpas.com
PM-AA-07
Usage
Diverter valve controls the tub ller and handshower.
Refer to drawings on "OPERATION" step.
Always turn cold water on rst to help prevent any
accidental burning or scalding; especially for children
and elderly.
DO NOT use any part of the tub ller as a support device.
REMEMBER: double check our website to see the most
up to date installation manual.
MANUFACTURER'S LIFETIME LIMITED WARRANTY
1. Defects Covered; Warranty Period: Pulse Shower Spas,
Inc. (“Pulse”) warrants to the original consumer purchaser
who purchases this shower spa (the “Product”) for use in
his or her own home, that the Product will be free from
defects in material and manufacturing workmanship for as
long as the original consumer purchaser owns that same
home. For all other purchasers (including, but not limited
to purchasers for industrial, commercial and business use),
the above warranty will apply for a period of 5 years from
the original date of purchase.
2. Remedy: If the Product does not conform to the above
warranty, Pulse, at its option, will repair or replace the
Product, free of charge, or refund your purchase price. For
warranty claims, please visit www.pulseshowerspas.com/
index.php/warranty. Pulse may require that you return the
Product to Pulse, shipping prepaid, in which case Pulse will
provide you with a return materials authorization number
(RMA). Pulse may also require that you provide evidence
of the date you purchased the Product. Pulse will ship a
new or repaired Product to you, at the expense of Pulse,
or refund your purchase price. Service labor performed
by you or others in connection with the removal or
replacement of the Product will not be reimbursed
by Pulse.
3. Exclusions: Pulse shall not be responsible for failure of
the Product, and the above warranties will not apply, if the
Product fails as a result of improper installation, improper
use, modications or repairs by anyone other than Pulse,
or accident or abuse (including damage during shipment).
4. Warranty on Repairs and Replacements: For consumer
purchasers who purchased the Product for home use,
repaired or replacement Products will continue to be
covered under this warranty for as long as he or she
owns that same home. For other purchasers, repaired or
replacement Products will be covered for the balance of
the original warranty period.
5. No Other Warranties; Limitation of Liability: OTHER
THAN THE LIFETIME LIMITED WARRANTY STATED
ABOVE, PULSE DISCLAIMS ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE, TO THE EXTENT PERMITTED
BY APPLICABLE LAW. THE REMEDIES STATED ABOVE
ARE YOUR SOLE REMEDIES IN CONNECTION WITH THIS
WARRANTY. IN NO EVENT WILL PULSE BE LIABLE TO
YOU FOR ANY DAMAGES, WHETHER DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL, INCLUDING
BUT NOT LIMITED TO LOST PROFITS OR BUSINESS
INTERRUPTION, ARISING OUT OF OR RELATING TO THE
PRODUCT OR ITS USE, WHETHER UNDER A CONTRACT,
WARRANTY, TORT, OR ANY OTHER CAUSE OF ACTION,
EVEN IF PULSE HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. NOTWITHSTANDING THE TERM
OF ANY LIMITED OR IMPLIED WARRANTY, OR IN THE
EVENT THAT ANY LIMITED WARRANTY FAILS OF ITS
ESSENTIAL PURPOSE, IN NO EVENT WILL PULSE’S
ENTIRE LIABILITY EXCEED THE PURCHASE PRICE OF
THE PRODUCT. SOME STATES AND PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE AND PROVINCE
TO PROVINCE.
Care and Maintenance
To keep your tub ller looking new, wipe down after each
use with a soft cotton cloth.
Protect your tub ller from hard water stains and mineral
deposits by periodically using an auto spray wax.
Clean using mild liquid soap and a non-abrasive sponge
or cloth. Rinse with clean water.
Do Not Use Any Kind Of
Chemicals Or Abrasives!
