PulseAudio PA-TXMIX User manual

vanco1.com | 800.626.6445
DIGITAL/ANALOG AUDIO
TRANSMITTER
PART NUMBER PA-TXMIX

2
1. Do not install or place this unit
in a built-in cabinet, or other
confined space without adequate
ventilation.
2. To prevent risk of electrical shock
or fire hazard, due to overheating
do not obstruct unit’s ventilation
openings.
3. Do not install near any source of
heat, including other units that
may produce heat.
4. Do not place unit near flames.
5. Only clean unit with a dry cloth.
6. Unplug unit during lightning
storms or when not used for an
extended period of time.
7. Protect the power cord from being
walked on or pinched, particularly
at the plugs.
8. Use unit only with accessories
specified by the manufacturer.
9. Refer all servicing to qualified
personnel.
WARNING
THIS PRODUCT IS 100% INSPECTED AND TESTED IN THE
UNITED STATES TO VERIFY PERFORMANCE PARAMETERS.
Thank you for purchasing this product. For optimum
performance and safety, please read these instructions
carefully before connecting, operating or adjusting this
product. Please keep this manual for future reference.
DEAR CUSTOMER

3
The PulseAudio PA-TXMIX analog audio mixing transmitter is an optional
add on unit for the PA-EXMIX analog audio mixing extender over Cat5e/6.
Have more than 2 sources needing to be mixed? No problem as an additional
PA-TXMIX can be used and cascaded over a single Cat5e/6 for even larger
solutions!
DIGITAL/ANALOG AUDIO EXTENDER
Part # PA-TXMIX
• Add additional sources when used with PA-EXMIX
• Extends balanced XLR and 3.5 mm stereo audio over a single Cat5e/6 up
to 300m/984 ft
• Features Power over Cable (PoC), allowing the extender set to be
powered with a single power supply, powered on the receiver end
• Mixing built in with an easy to use dial to mix between the XLR and stereo
AUX inputs
• Mic input (XLR) and AUX input with balanced level control
• Supports two types of microphones, Dynamic and Condenser
• 12V Phantom power option
• dimensions: 5” x 2.9” x 1.6”
FEATURES
PACKAGE CONTENTS
• PA-TXMIX Transmitter
• Mounting screws
• Product Manual

4
PANEL DESCRIPTIONS
6
5
4
3
2
TRANSMITTER
1
1. Power LED: Illuminates when there is power connected on the receiver unit
2. Phantom Power LED: Indicates if Phantom Power is on
3. MIC IN: Balanced XLR microphone input
4. Mixing Dial: Mixes audio from MIC IN and AUX IN inputs. All the way left
is 100% MIC/XLR, 100% to the right is 100% AUX IN, in the middle is 50/50
mix of MIC/XLR and AUX IN audio
5. AUX IN: 3.5mm stereo audio input
6. CAT5 Out: Connect a single Cat5e/6 cable from the transmitting unit to the
receiving unit, or to an additional PA-TXMIX transmitter (sold separately)
7. CAT5 In: Connects from an additional PA-TXMIX transmitter (sold
separately) to cascade for connecting additional sources
8. Power Switch:
a. OFF turns o power and function to the unit
b. POWER turns power on
c. Phan. PWR enables Phantom Power for the XLR port
7
8

5
CONNECT AND OPERATE
CASCADING
1. Connect audio source(s) to each transmitter via XLR and/or 3.5mm stereo
cable to the appropriate connections
2. Connect the XLR and/or 3.5mm audio outputs from the receiver to an
amplifier or active speaker
3. Connect a single Cat5e/6 cable from the CAT5 OUT port of the first
transmitter to the CAT5 IN of the second transmitter
4. Connect a single Ca5e/6 cable from to the CAT5 OUT port of the second
transmitter, to the CAT5 IN port of the receiver
5. Connect power to the receiver
6. Adjust the mixing dial according and test
SOURCE SOURCE
PA-TXMIX PA-EXMIX SET (SOLD SEPARATELY)
AMPLIFIER
CAT5E CABLE
CAT5E CABLE
MIC
MIC

6
SAFETY AND NOTICE
The PA-TXMIX has been tested for conformance to safety regulations and
requirements, and has been certified for international use. However, like all
electronic equipment, the PA-TXMIX should be used with care. Please read
and follow the safety instructions to protect yourself from possible injury and
to minimize the risk of damage to the unit.
• Follow all instructions and warnings marked on this unit.
• Do not attempt to service this unit yourself, except where explained in this
manual.
• Provide proper ventilation and air circulation and do not use near water.
• Keep objects that might damage the device and assure that the placement of this
unit is on a stable surface.
• Use only the power adapter and power cords and connection cables designed for
this unit.
• Do not use liquid or aerosol cleaners to clean this unit.
• Always unplug the power to the device before cleaning
SPECIFICATIONS
Audio Inputs (TX) .............................................Balanced XLR, 3.5mm Stereo Jack
Audio Outputs (RX).........................................Balanced XLR, 3.5mm Stereo Jack
Distance................................................................Up to 984ft/300m over single Cate/6
Input Impedance ...............................................600 Ohms
Mic Gain ................................................................+40dB
Low Cut.................................................................-3dB @100Hz
Current Draw ......................................................70mA
Power Supply .....................................................+12VDC
Phantom Power .................................................12V
Dimensions ..........................................................5” x 2.9” x 1.6” (126mm x 73mm x
41mm)
Weight...................................................................0.65lbs (0.295kg)

7
TECHNICAL SUPPORT
In case of problems, please contact Vanco Technical Support by dialing
1-800-626-6445. You can also email technical support issues to techsupport@
vanco1.com. When calling, please have the Model Number, Serial Number
(axed to the bottom of the unit) and Invoice available for reference during
the call. Please read this Instruction Manual prior to calling or installing this
unit, since it will familiarize you with the capabilities of this product and its
proper installation. All active electronic products are 100% inspected and
tested to insure highest product quality and trouble-free installation and
operation. The testing process utilizes the types of high-definition sources and
displays typically installed for entertainment and home theatre applications.
For additional information please visit www.vanco1.com.
LIMITED WARRANTY
With the exceptions noted in the next paragraph, Vanco warrants to the
original purchaser that the equipment it manufactures or sells will be free from
defects in materials and workmanship for a period of two years from the date
of purchase. Should this product, in Vanco’s opinion, prove defective within
this warranty period, Vanco, at its option, will repair or replace this product
without charge. Any defective parts replaced become the property of Vanco.
This warranty does not apply to those products which have been damaged
due to accident, unauthorized alterations, improper repair, modifications,
inadequate maintenance and care, or use in any manner for which the product
was not originally intended. Items integrated into Vanco products that are
made by other manufacturers, notably computer hard drives and liquid
crystal display panels, are limited to the term of the warranty oered by the
respective manufacturers. Such specific warranties are available upon request
to Vanco. A surge protector, power conditioner unit, or an uninterruptible
power supply must be installed in the electrical circuit to protect against
power surges. If repairs are needed during the warranty period the purchaser
will be required to provide a sales receipt/sales invoice or other acceptable
proof of purchase to the seller of this equipment. The seller will then contact
Vanco regarding warranty repair or replacement.
LIABILITY STATEMENT
Every eort has been made to ensure that this product is free of defects. The
manufacturer of this product cannot be held liable for the use of this hardware
or any direct or indirect consequential damages arising from its use. It is
the responsibility of the user and installer of the hardware to check that it is
suitable for their requirements and that it is installed correctly. All rights are
reserved. No parts of this manual may be reproduced or transmitted by any
form or means electronic or mechanical, including photocopying, recording
or by any information storage or retrieval system without the written consent
of the publisher. Manufacturer reserves the right to revise any of its hardware
and software following its policy to modify and/or improve its products where
necessary or desirable. This statement does not aect the legal rights of the
user in any way.

506 Kingsland Drive Batavia, Illinois 60510
call: 800.626.6445 | fax: 630.879.9189
visit: www.vanco1.com
Vanco®International
A brand from Learn more at vanco1.com
