PulseWorx KPLC7 User manual

Model KPLC7
Keypad Load Controller
Installation Guide and
Owner’s Manual
The Inventors Of:
19201 Parthenia St. Suite J
Northridge, CA 91324
P: 818.701.9831 F: 818.701.1506
[e-mail]
www.pcslighting.com
FUNCTION
The KPLC7 PRC Load Controller together with the RM-0-10V
receiving module allows for changing the illumination level of
a 10-10V controlled LED fixture. It can also transmit and
receive UPB® (Universal Powerline Bus) digital commands over
the existing power wiring to remotely turn on, off, and dim
other UPB load control devices. No additional wiring is
required and no radio frequency signals are used for
communication.
In the default configuration, the buttons do not transmit UPB
commands but only control the LED fixture attached to the
RM-0-10V receiving module. The buttons can be changed to
transmit using the UPB configuration program UPStart.
Models
The KPLC7 can be mounted in any wall box that contains
neutral, line, load and ground wires. Available colors are
White, Black, and Light Almond.
Engraved Buttons
The KPLC7 has white backlit buttons engraved with the
designations of: Scene 1, Scene 2, Scene 3, Scene 4, Off, and
an Up Arrow and Down Arrow. Custom Engraved buttons
(model CEB) are available enabling you to tailor each button
for its particular use. Consult your dealer or our website
(www.pcslighting.com) for CEB ordering information.
MPORTANT SAFETY INSTRUCTIONS
When using electrical products, basic safety precautions
should always be followed, including the following:
1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
2. Keep away from water. If the product comes in contact with
water or other liquid, turn off the circuit breaker and unplug
the product immediately.
3. Never use products that have been dropped or damaged.
4. Do not use this product outdoors.
5. Do not use this product for other than its intended purpose.
Do not cover this product with any material when in use.
6. SAVE THESE INSTRUCTIONS.
INSTALLATION
To install the KPLC7 module in a wallbox follow these instructions:
1. Before installing the KPLC7 into a wall box, ensure that
power to the wall box has been disconnected by removing
the fuse or turning the circuit breaker off. Installing
products while the power is on may expose you to
dangerous voltage and may damage the product.
2. Remove any existing wall plate and device from the wall box.
3. Use wire nuts to securely connect the KPLC7’s white wire to
the “Neutral” wire, the KPLC7’s black wire to the “Line” wire
and the red wire to the “Load” wire (see illustration below).
4. Fit the KPLC7 into the wall box and secure with mounting
screws. Install the wall plate.
5. Install the RM-0-10V receiving module as shown in the
wiring diagram.
6. Restore power at the circuit breaker.

Model KPLC7
Keypad Load Controller
Installation Guide and
Owner’s Manual
The Inventors Of:
19201 Parthenia St. Suite J
Northridge, CA 91324
P: 818.701.9831 F: 818.701.1506
[e-mail]
www.pcslighting.com
CONFIGURATION
Once your KPLC7 is installed it can be configured either
manually or with UPStart Configuration Software Refer to the
Keypad Controller’s Manual Configuration Guide available on
the PCS website for further details on Manual configuration to
add your KPL device into a UPB network and link it to various
load control devices.
Although the factory default operation of the KPLC7 is very
useful in many situations, it is recommended that you program
your KPLC7 with a Powerline Interface Module (PIM) and
UPStart Configuration Software to take advantage of its many
configurable features. User Guides are available on our
website, if you need further assistance on how to configure
your system.
SETUP Mode
When configuring a UPB system, it will be necessary to place
the KPLC7 into SETUP mode. To enter Setup Mode,
simultaneously press and hold the right side of the top button
(Scene 1) and the left side of the bottom button (Down Arrow)
buttons for 3 seconds.
All the LED indicators blink once the device is in SETUP mode.
To exit SETUP mode, again simultaneously press and hold the
same buttons for 3 seconds or wait five minutes for time out.
Controlling additional PulseWorx devices
The KPLC7, in addition to controlling the LED fixture attached
to the RM-0-10V receiving module, it can be configured to
work with other PulseWorx® Lighting System devices. To do
this you must use the UPB Configuration Software UPStart and
enable the keypad pushbuttons to transmit.
OPERATION
Once installed and configured the KPLC7 will operate with the
stored configuration settings. Single-tap, double-tap, hold, or
release the pushbuttons will control the LED fixture. Unless
changed with UPStart, the default actions of the keypad
buttons are:
Button 1 Action:
100%
Button 2 Action:
50%
Button 3 Action:
15%
Button 4 Action:
5%
Button 5 Action:
OFF (0%)
UP Button Mode:
Increase light level
DN Button Mode:
Decrease light level
The final split button –right half decrease light level, left half
increase light level –work by holding the button down to start the
level change and release when the desired level is achieved.
Backlit Pushbuttons
Each of the pushbuttons has a LED behind it to provide back-
lighting and to indicate when loads or scenes are activated. By
default, the back-lighting is enabled and pressing a pushbutton
will cause it to illuminate brighter than the others.
Factory Default Settings
To restore the following default settings put the KPLC7 into SETUP
by simultaneously pressing and holding the top right of the top
button and the right of the bottom button for about 3 seconds.
The while in setup mode press and hold the second (Scene 2) and
the 5th button (scene 5) for about 3 seconds. The indicators will
light up to indicate that factory defaults have been restored.
Network ID:
255
Unit ID KPLC7:
80
Network Password:
1234
Receive Sensitivity:
High
Transmit Count:
Twice
IR Options:
N/A
LED Options:
Backlight enabled/ High
Button 1 Action:
100%
Button 2 Action:
50%
Button 3 Action:
15%
Button 4 Action:
5%
Button 5 Action:
OFF (0%)
UP Button Mode:
Increase light level
DN Button Mode:
Decrease light level
LIMITED WARRANTY
Seller warrants this product, if used in accordance with all
applicable instructions, to be free from original defects in
materials and workmanship for a period of five years from the
date of purchase. Refer to the warranty information on the PCS
website (www.pcslighting.com) for exact details.
