Model: FMR1
Fixture Module - Relay
Installation Guide and
Owner’s Manual
CONFIGURATION
Once your FMR1 is installed it can be configured either
manually or with the UPStart Setup Software.
Manual configuration can be used to add your FMR1 device
into a UPB network and link it to controller buttons. Refer to
the Keypad Controller’s Manual Configuration Guide
available on the PulseWorx website (www.PulseWorx.com)
for more details.
Although the factory default operation of the FMR1 is useful
in many situations, it is highly recommended that your device
be configured with UPStart Setup Software so that you can
take advantage of its many configurable features.
PCS has developed a Powerline Interface Module (PIM) and
free UPB Setup Tool software (UPStart) to help you configure
all of your PulseWorx Lighting System devices. User’s Guides
are available on the PulseWorx web site:
www.PulseWorx.com to explain how to configure your
system.
SETUP Mode
When configuring a UPB system, it will be necessary to place
the FMR1 in SETUP mode. To do this, press the Program
Button (see illustration) five times rapidly using a non-
metallic toothpick. The Status LED will continuously blink
Blue when the device is in SETUP mode. To exit SETUP mode,
press the Program Button once or wait five minutes for it to
time out.
OPERATION
The Fixture Module operates according to commands sent by
one or more UPB controllers. The FMR1 can accept powerline
commands from any UPB-compatible transmitter such as
PulseWorx Keypad Controllers, Timed Event Controllers, Wall
Switches, Interface Modules, approved Third-Party
Controllers and touch screens. The FMR1 can be a member of
up to 16 scenes with the capability to store a pre-set relay
state (on, off, or blink) for each scene.
AUTO-OFF Timer
New for Generation 2 is the ability to set a maximum on time.
If you forget to shut the fixture off yourself the fixture module
will do it for you automatically. The FMR1 can be configured
to inform the rest of the network when it has automatically
turned the appliance off. This allows the FMR1 to remotely
control other devices or update feedback indicators such as
LEDs.
TEST Mode
A manual test feature allows the device to be turned ON and OFF
locally. To enable the TEST mode press and hold the Program
Button on the FMR1 for at least three seconds. The Status
LED will blink Magenta to indicate TEST mode. The fixture can
now be turned ON and OFF by single-tapping the Program
Button. Press and hold the Program Button again for at least
three seconds to exit from TEST mode.
Factory Default Settings
To restore the following default settings put the FMR1 into
SETUP mode and then press the Program Button ten times
rapidly. The Status LED will blink red to indicate that factory
defaults have been restored. Press the Program Button twice
more to stop the blinking.
Network ID: 255
Unit ID: 61
Network Password: 1234
Receive Components: Link #1 = ON
Link #2 = OFF
Link #8 = Blink @ .5 sec
TYPICAL USES
The FMR1 is perfect for controlling 120VAC non-dimming loads
such as:
•Fans,
•Pumps,
•Low voltage transformers,
•Coffee makers,
•Christmas lights.
LIMITED WARRANTY
Seller warrants this product, if used in accordance with all
applicable instructions, to be free from original defects in
materials and workmanship for a period of five years from the
date of purchase. Refer to the warranty information on the
PulseWorx website (www.PulseWorx.com) for exact details.
