PUPPYOO R35 User manual

Intelligent Robot Vacuum Cleaner
Aspirateur Robot Intelligent
R35
Thank you for choosing PUPPYOO vacuum cleaner.
Please read the user guide carefully before use.
Merci d’avoir choisi l’aspirateur PUPPYOO.
Veuillez lire attentivement le mode d’emploi avant de l’utiliser.

Thank you for you choosing R35 series robot vacuum cleaner, should you have any
question on this product, please contact us by phone
Merci d’avoir choisi l’aspirateur robot série R35 si vous avez des questions sur ce
produit, veuillez nous contacter par téléphone
86-10-5741 7619

IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, or injury:
When using an electrical appliance, basic precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING (THISAPPLIANCE), Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
1. Do not use outdoors or on wet surfaces
2. Do not allow to be used as a toy. Close attention is necessary when used by or near
children, pets or plants.
3. Use only as described in this manual. Use only manufacturer’s recommended
attachments
4. Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, return it to a service center.
5. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run appliance over cord. Keep cord away from
heated surfaces.
6. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
7. Do not handle charger, including charger plug, and charger terminals with wet hands
8. Do not put any object into openings. Do not use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce air flow.
9. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving
parts.
10. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in
areas where they may be present.
11. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot
ashes.
12. Do not use without dust container.
13. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to battery pack, picking up or carrying the appliance. Carrying the appliance with your
finger on the switch or energizing appliance that have the switch on invites accidents.
14. Risk Of Injury. Brush May Start Unexpectedly. Remove The Brush Before Cleaning or
Servicing.
15. Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
16. Use appliances only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
17. When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together may cause burns or a fire.
18. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
19. Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of
injury.

SAVE THESE INSTRUCTIONS
20. Do not expose a battery pack or appliance to fire or excessive temperature. Exposure to
fire or temperature above 130°C may cause explosion.
21. Follow all charging instructions and do not charge the battery pack or appliance outside
of the temperature range specified in the instructions. Charging improperly or at
temperatures outside of the specified range may damage the battery and increase the risk
of fire.
22. Have servicing performed by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the product is maintained.
23. Do not modify or attempt to repair the appliance or the battery pack except as indicated
in the instructions for use and care.
24. Place the cords from other appliances out of the area to be cleaned.
25. Do not operate the vacuum in a room where an infant or child is sleeping.
26. Do not operate the vacuum in an area where there are lit candles or fragile objects on
the floor to be cleaned.
27. Do not operate the vacuum in a room that has lit candles on furniture that the vacuum
may accidentally hit or bump into.
28. Do not allow children to sit on the vacuum.
29. Do not use the vacuum on a wet surface.
Household use only.

IMPORTANTES MESURES DE SÉCURITÉ
AVERTISSEMENT.
Pour réduire les risques d’incendie, de choc électrique ou de blessure:
L’utilisation d’un appareil électrique demande certaines précautions:
LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER (CETAPPAREIL), Le
non-respect des mises en garde et des instructions peut causer des chocs électriques, des
incendies et/ou des blessures graves.
1. Ne pas exposer à la pluie, Ranger à l’intérieur.
2. Ne pas permettre aux enfants de jouer avec l’appareil. Une attention particulière est
nécessaire lorsque l’appareil est utilize par des enfants ou à proximité de ces derniers.
3. N’utiliser que conformément à cette notice avec les accessories recommandés par le
fabricant.
4. Ne pas utiliser si le cordon ou la fiche est endommagé. Retourner l’appareil à un atelier
de reparation s’il ne fonctionne pas bien, s’il est tombé ou s’il a été endommagé, oublié à
l’extérieur ou immergé.
5. Ne pas tirer soulever ni trainer l’appareil par le cordon. Ne pas utiliser le cordon comme
une poignée, le coincer dans l’embrasure d’une porte ou l’appuyer contre des arêtes vives
ou des coins. Ne pas faire rouler l’appareil sur le cordon. Garder le cordonà l’écart des
surfaces chaudes.
6. Ne pas débrancher en tyrant sur le cordon. Tirer plutôt la fiche.
7. Ne pas manipuler le chargeur, y compris la prise du chargeur, et les bornes du chargeur
avec les mains mouillées
8. N’insérer aucun objet dans les ouvertures. Ne pas utiliser l’appareil lorsqu’une ouverture
est bloquée. S’assurer que de la poussière, de la peluche, des cheveux ou d’autres
matières ne réduisent pas le debit d’air.
9. Maintenir les cheveux, les vêtements amples, les doigts et toutes les parties du corps à
l’écart des ouvertures et des pieces mobiles.
10. Ne pas aspirer des liquids inflammables ou combustibles, comme de l’essence, et ne
pas faire fonctionner dans des endroits où peuvent se trouver de tells liquides.
11. Ne pas aspirer de matières en combustion ou qui dégagent de la fumée, comme des
cigarettes, des allumettes ou des cendres chaudes.
12. Ne pas utiliser l’appareil si le sac à poussière ou le filter n’est pas en place.
13. Emêcher une mise en marche accidentelle. S’assurer que l’interrupteur est à la position
arrêt avant de raccorder la batterie, de lever ou de déplacer l’appareil. Transporter
l’appareil en gardant un doigt sur l’interrupteur, ou mettre sous tension un appareil dont
l’interrupteur est à la position marche peut causer un accident.
14. Risqué de blessure. La brosse peut commencer de manière inattendue. Enlevez la
brosse avant le nettoyage ou l'entretien.
15. Recharger uniquement avec le chargeur prescrit par le fabricant. Un chargeur
convenant à un type de batterie peut présenter un risque d’incendie lorsqu’il est utilisé
avec une autre batterie.
16. Utiliser uniquement les batteries recommandées pour l’appareil. L’utilisation d’autres
types de batteries peut présenter un risque de blessure ou d’incendie.
1. Do not use outdoors or on wet surfaces
2. Do not allow to be used as a toy. Close attention is necessary when used by or near
children, pets or plants.
3. Use only as described in this manual. Use only manufacturer’s recommended
attachments
4. Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water, return it to a service center.
5. Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord
around sharp edges or corners. Do not run appliance over cord. Keep cord away from
heated surfaces.
6. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
7. Do not handle charger, including charger plug, and charger terminals with wet hands
8. Do not put any object into openings. Do not use with any opening blocked; keep free of
dust, lint, hair, and anything that may reduce air flow.
9. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving
parts.
10. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in
areas where they may be present.
11. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot
ashes.
12. Do not use without dust container.
13. Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to battery pack, picking up or carrying the appliance. Carrying the appliance with your
finger on the switch or energizing appliance that have the switch on invites accidents.
14. Risk Of Injury. Brush May Start Unexpectedly. Remove The Brush Before Cleaning or
Servicing.
15. Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
16. Use appliances only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
17. When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together may cause burns or a fire.
18. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
19. Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of
injury.

CONSERVER CES INSTRUCTIONS
17. Lorsque l’appareil n’est pas utilisé, tenir la batterie loin d’objets métalliques comme
des trombones, des pièces de monnaie, des clés, des clous, des vis ou autres petits objets
qui pourraient établir une liaison entre les bornes. Un courtcircuit des bornes des batteries
peut causer des brûlures ou un incendie.
18. En condition d’usage abusif, du liquide peut s’échapper de la batterie ; éviter tout
contact avec ce liquide. En cas de contact accidentel, rincer abondamment avec de l’eau.
En cas de contact avec les yeux, consulter également un médecin. Le liquide projeté peut
causer des irritations ou des brûlures.
19. Ne pas utiliser une batterie ou un appareil endommagé ou qui a été modifié. Des
batteries endommagées ou modifies peuvent avoir un comportement imprévisible
pouvant causer un incendie, une explosion ou un risque de blessure.
20. Ne pas exposer une batterie ou un appareil à la flamme ou à des températures
excessives. L’exposition à une flamme ou à des températures supérieures à 130 °C peut
causer une explosion.
21. Respecter toutes les instructions de chargement et ne pas charger la batterie ou
l’appareil à des températures qui ne sont pas incluses dans la gamme de températures
indiquées dans la notice d’instructions. Un chargement mal effctué.
22. Confier les réparations à une personne qualifiée qui utilisera uniquement des pièces
de remplacement identiques. Cette façon de faire garantira la sécurité du produit.
23. Ne pas modifier ni tenter de réparer l’appareil ou la batterie sauf comme il est indiqué
dans les instructions d’utilisation et d’entretien.
24. Éloigner les cordons d’autres appareils de la zone à nettoyer.
25. Ne pas utiliser l’aspirateur dans une pièce où un nourrisson ou un enfant dort.
26. Ne pas utiliser l’aspirateur dans un endroit où il ya des bougies allumées ou des objets
fragiles sur le plancher à nettoyer.
27. Ne pas utiliser l’aspirateur dans une pièce où il ya des bougies allumées sur les
meubles que l’aspirateur peut heurter ou se cogner accidentellement.
28. Ne pas laisser les enfants s’assoir sur l’aspirateur.
29. Ne pas utiliser l’aspirateur sur une surface mouillée.
Usage Domestique seulement

FCC/IC COMPLIANCE / TM / WARRANTY
This device complies with Part 15 of the FCC Rules / Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To satisfy FCC&IC RF exposure requirements, a separation distance of 20cm or more should
be maintained between the antenna of this device and persons during device operation.
To ensure compliance, operations at closer than this distance is not recommended.
Les antennes installées doivent être situées de facon à ce que la population ne puisse
y être exposée à une distance de moin de 20 cm. Installer les antennes de facon à ce
que le personnel ne puisse approcher à 20 cm ou moins de la position centrale de l’
antenne.

Contents
1. Safety Instruction
1.1 Notice for use
1.2 Mattersneedattention
1.3 Battery
1.4 Usage range
2. Product
2.1 Main body and components
2.2 Parts name
3. Product assembly
3.1 Adapter and charging stand combination
3.2 Installing the charging stand
3.3 Installing a dust box or water tank
3.4 Using the wet drag function
4. Using product
4.1 Buttons and indicators
4.2 Main body use
4.3 APP Operating mode
5. APP operation guide
5.1 Register and login
5.2 Add device
5.3 Operation page
5.4 More function
6. Product maintenance
6.1 Battery storage
6.2 Clean charging electrode slice
6.3 Clean dust container
6.4 Clean main brush
6.5 Clean side brush
6.6 Clean wheels
6.7 Clean sensors
7. Trouble shooting
8. Parameters
02
02
02
03
03
04
04
05
06
06
06
07
08
09
09
10
10
11
12
13
15
16
17
17
17
17
18
19
19
19
20
21

Contenu
1. Instruction de sécurité
1.1 Avis d'utilisation
1.2 Les questions ont besoin d'attention
1.3 Batterie
1.4 Plage d'utilisation
2. Produit
2.1 Corps principal et composants
2.2 Nom des pièces
3. Assemblage du produit
3.1 Combinaison de l'adaptateur et du support de charge
3.2 Installation du support de charge
3.3 Installation d'une boîte à poussière ou d'un réservoir d'eau
3.4 Utilisation de la fonction de traînée humide
4. Utilisation du produit
4.1 Boutons et indicateurs
4.2 Utilisation du corps principal
4.3 Mode de fonctionnement APP
5. Guide d'utilisation APP
5.1 S'inscrire et se connecter
5.2 Ajouter un appareil
5.3 Page d'opération
5.4 Plus de fonction
6. Maintenance du produit
6.1 Stockage de la batterie
6.2 Nettoyer la tranche d'électrode de charge
6.3 Nettoyer le bac à poussière
6.4 Nettoyer la brosse principale
6.5 Nettoyer la brosse latérale
6.6 Nettoyer les roues
6.7 Nettoyer les capteurs
7. Dépannage
8. Paramètres
23
23
23
24
24
25
25
26
27
27
27
28
29
30
30
31
31
32
33
34
36
37
38
38
38
38
39
40
40
40
41
41

01
Do not use to absorb sharp
objects, such as glass sheets,
nails, etc., to avoid damage
to the product.
Unplug the power cord for
a long time without using
the charging stand.
This product can only be
used indoors.
Prevent damage to the
machine by inhaling water,
oil or other liquids.
The charging stand is placed on a flat, wall-mounted area to prevent product
functionality from being affected.
Do not use in a wet or
flammable, explosive or
corrosive environment.
When the product is working,
removing the charging stand
will cause the machine to fail
to recharge normally.
Please remove the damaged
material before use.
Disassemble the scattered
wires on the ground before
use to prevent the machine
from working.
WARNING
1) This appliance should not be operated by children under 8 years old or people
who is physically or mentally disabled or lack of relevant experience and
knowledge, unless under the guidance and supervision of people who could be
responsible for the user’s safety.
2) Prohibit children from playing bags of the appliance, or it may cause suffocation.
Notice：Children safety

1. Safety Instruction
1.1 Notice for use
1.2 Mattersneedattention
Before use, please read the safety precautions below carefully.
* Please ready all the instructions before using this appliance.
* In order toensureproperoperation,pleasekeepthismanualappropriately.
* If you want to give this appliance to a third party, please include this manual along with
the appliance.
* Any operation that does not comply with this manual may result in serious personal.
injury or damage to the appliance itself.
This appliance can only work with the adaptor, battery
and charge station together with the parcel which
committed to this appliance, otherwise it may cause
damage to the machine or electric shock or fire.
Please do not use this appliance if the machine or
accessories get broken. Please contact with our after-sales
service when you meet problem.
Please remove the plug from the socket before
maintenance.
Please do not touch the plug or the appliance with wet
hands, or it may lead to electric shock.
Please contact with our customer service if the cable got
broken to avoid danger.
Do not use this appliance in the absence of a fence to
avoid accidental fall of the robot.
Please don’t replace non-original battery by yourself.
Do not get clothes or any part of your body (hair, finger,
etc.) involved in the brush or wheel of the appliance, or it
may cause danger.
Don’t put the appliances close to fire, inflammable,
explosive or corrosive materials.
Please contact with our customer service to get e-edition
manual if your manual got lost.
02

1) This product is limited to use the battery equipped by the manufacture.
2) Please remove the battery before dispose the appliance.
3) Please contact with our after sale service if you want to replace the battery. Do not use
any other charger to recharge the battery pack.
4) If the battery got leakage, do not let the liquid get into the skin or clothes, clean it with
dry cloth immediately, and put it back to recycle bin, do not throw it away.
5) Please dispose the waste battery of the appliance properly. Batteries contain hazardous
substances that are hazardous to the environment. Please follow your local environmental
regulations and place it on the required recycling sites.
Please use the robot in the above ground environment, otherwise it will not be able to
achieve the effect and may even damage the robot.
1.3 Battery
1.4 Usable range
Wood Floor Tile Short Hair Carpet
03

2. Product
2.1 Main body and components
Warm tip
Dust cup, filter screen net, and battery are already installed in the main body.
Main Unit
Charge Station x1 Adaptor x1
Mop x1
Pallet x1
Cleaning Brushx1
Side brush x2
screw driver x1
Dust cup x1
04
Certificate
of
Approval
User
Manual

Main body
button
Transparent
window
Upper flip
Front
Anti-collision
Cross country
walking wheel
Floating brush
cover buckle *2
Wet water
seepage hole
Water tank
buckle *2
Charging slice*2
Anti- drop
sensors*3
Wall sensor Infrared anti-
collision sensors
Retour and
recharge
WIFI indicator
Start/pause
button
Floating brush
Battery cover
Front wheel
2.2 Parts name
05

Power indicator
Signal transmitting area
Charging contactor
Dust container
Filter bracket HEPA filter net
1. Open the bottom plate of the charging stand.
2. Insert the adapter cylindrical plug into the DC
connector inside the charging stand.
3. Depending on the distance, the excess line "8"
is wrapped around the bobbin as shown.
4. Cover the gusset, place the charging stand
against the wall and place the adapter into the
power outlet.
1. Place the cradle on a flat surface
that is perpendicular to the wall. 1.5
meters ahead.There must be no
obstacles within 0.5 meters of the left
and right. Press firmly on the cradle
to make it more securely attached to
the floor.
Please avoid direct sunlight charging
stand
3.1 Adapter and charging stand
3.2 Installing the charging stand
3 Product installation
06

Wall sensor
WIFI indicator
Retour and recharge
2. Before use, be sure to remove the protective strip on the device's bumper to
ensure the normal use of the device.
3. Power on: Push the On/Key to “On” and press the Start/Pause button.
4. Use
Method 1: Press the button on the top cover
of the main unit to start, pause and recharge.
Method 2: Use the App to operate. For
instructions, see the “APP Operation Guide”
on the following page.
1. First insert the handles
into the dust box. 2. Put in a dust box or water tank. 3. Flatten the handle to ensure that the dust box
is stuck at both ends.
3.3 Install dust container or water tank
07
off
on

1.First fill the water tank to 90% and close the water inlet.
(Note: If the metal contact on one side of the water tank
is wet, please dry it and put it in the dust box.)
2. Put the water tank after the water injection into the dust
box, and ensure that the handles are flattened at both
ends.
3. Insert one end of the mop straight from the entrance of
the carriage and flatten the mop.
4. Push the pallet with the mop pasted from the rear of
the robot to the rear of the machine. When you hear the
click, the pallet is installed.
5. When removing the carriage, squeeze the two buckles
at the end of the carriage to remove it smoothly.
3.4 Use the wet drag function
1) After installing the water tank and mop, the sweeping machine will automatically
switch to wet drag mode. If you want to switch to the vacuum mode, you need to take
out the water tank, remove the carriage, and then put it into the dust box.
2) After the wet drag, please empty the water tank and wash and dry the mop.
Do not use the mop function on the carpet
Note
08

4. Using product
4.1 Buttons and indicators
1. When the machine is in standby state, the power light will
display “blue”, press the recharge button, and the machine
enters the recharge mode.
2. When the machine is in standby state, the power light will
display “blue”. Press and hold the recharge button to remind
the user to enter the WiFi distribution mode. The WIFI indicator
will flash. After the distribution is successful, the WIFI indicator
will be on.
3. When the machine is low, the machine's recharge button
light is red, and when the machine is charging on the cradle, the
machine's recharge lamp flashes blue.
When the machine is in standby state, the power light shows
“blue”, press the power button, and the machine enters the
automatic cleaning mode.
When the machine enters the distribution network, the indicator
light flashes. After the distribution network is successful, the
indicator light is always on.
Button Button description
Retour and recharge button
Start/pause button
WIFI Indicators
Start/pause button
WIFI indicator
Retour and recharge
09

4.2 Use of main body
Install the side brush and use a screwdriver to
load the side brush into the sweep.Screw the
corresponding position on the bottom of the
grounder.
1) Clean
Press on/off button after it turns on, and it will
begain to clean.
2) Stop
When the sweeper is cleaning or retour and
recharge, press the “on/off key ” and the main
body will stop.
When not in use for a long time, you can push the
key to push off, and then sweep the machine.
On/off button
1) Automatic retour and recharge, when the
cleaning is completed or the battery is low ,it will
search charge station and recharge automatically.
2) Manual retour and recharge , when the sweeper
is in the pause state, press the back charge button
on the top cover of the machine or the back
charge button in the APP, the sweeper will actively
look for the charging stand to charge.
1) Before use, be sure to remove the protective
strip on the device's bumper to ensure that the
device is in normal use.
2) Turn on the power and push the on/off button
located in the main unit to “ON”.
3) After the switch is turned on, there will be a
voice prompt. After the device is turned on, you
can operate it.
Start/pause
button
WIFI
indicator
Retour and
recharge
1. Side brush assembly 2. Turn on
3. Clean and stop
5.Turn off
4. Automatic or manual retour and recharge
There are more modes of operation on the APP side. See the APP User Guide in the
manual for details.
4.3 APP mode of operation
10
off
on

5. APP operation guide
The document will update because of APP update or other reasons, and can only be used
as a guidance, unless otherwise stated. Description, information and suggestions don’t
constitute any guarantee.
Attention
The Puppy App is a smart home app based on Android and iOS. This document mainly
guides the first-time user to operate the software, explaining the operation steps and
precautions of the software.
Summary
APP file name: PUPPYOO R3X
After downloading, follow the normal procedure to install the app
to find the corresponding indicator icon in the application.
Use environment
Mobile phone download APPios 10.0 or above or Android
8.0 or above mobile phone, search for APP in the APP Store
or Google Play to download and install. Or scan the QR
code to download:
Use environment
After the mobile phone opens the "PUPPYOO R3X" app, after registering and logging in,
follow the APP prompts to set up the sweeper and network settings.
11
