Pur Line DESAIR-12 User manual

(EN)
DEHUMIDIFIER
Pur Line
DESAIR-12
User manual
WinEurope - FRANCE
Web : www.purline.com
Read and keep this manual for future reference.
Please read those instructions carefully before operating the unit.

NOTE: If this unit is dropped, the warranty is not valid.
IMPORTANT
- Leave the appliance to stand for two hours before connection to the
mains supply after transport or when it has been titled (e.g. during
cleaning).
- Before connecting the appliance, please check if the voltage
indicated at the type plate (rear side of appliance) corresponds to
mains voltage in your home.
- Connect the appliance to an earth wall socket only.
- Never pour or spray water over the appliance.
- Do not remove the mains plug from the wall socket while the
appliance is switched on.
- When moving the appliance: first switch off, then unplug and empty
the water tank.
- Allow a free space of 20 cm around the appliance.
- Do not insert any object into the air inlet or outlet openings.
- Do not place the dehumidifier near a heating source (esp. a radiator)
or indirect sunlight. Ensure that the appliance does not become hot.
- Empty the water tank regularly. (In extreme conditions the water tank
may be full after a few hours operation.)
- Clean the air inlet filter if it becomes contaminated : the appliance is
most effective when the filter is clean.
- Please do not expect the air dehumidifier to be effective when too
many doors or windows are opened or when something in the room is
producing a lot of humidity.
- The air dehumidifier will come into effect immediately. However, the
reduction of humidity may hardly be measurable during the first few
days.
- If the mains cord of this appliance is damaged, it must only be
replaced by a qualified electrician.

CONTROL PANEL
1.Humidity control switch
2.Operation pilot
3.Defrost pilot
4.Tank full pilot
5.Speed control (Low, High)

PUTTING INTO OPERATION
Place the air dehumidifier on a flat and even floor. Allow 20 cm (8”) free
space around the appliance. Select a place away from a heat source and
not in direct sunlight, preferably close to an earth wall socket Connect the
air dehumidifier to earth wall socket. Then turn the humidity control switch
clockwise to desired humidity and the air dehumidifier starts running.
Note: If the pilot fails to illuminate, please check if the water tank is not
correctly seated, pull out the water tank gently and put it back again firmly.
EMPTYING THE WATER TANK
Empty the water tank regularly. When full, the air dehumidifier switches off
automatically and tank full pilot comes on.
Hold the handle of the water tank .
Lift slightly and pull out carefully .
Empty the water tank.
Put the water tank back.
The air dehumidifier can drain water continuously with 11 mm diameter
drainage hose.
Do not move the appliance if the water tank is removed.
REPLACEMENT AND MAINTANCE OF AIR FILTER
Check the air filter regularly. Clean as soon as it has become dirty.
If the air passage through the filter is blocked, the air humidifier cannot
function properly.
Hold the air filter by the handles and pull outward.
For easy cleaning of filter screen, use a vacuum cleaner or rinse lightly
with water (no chemicals).
Do not forget to re-install the filter after cleaning.
To ensure best performance clean air filter every 1-2 weeks.

CLEANING THE APPLIANCE
Switch off (humidity control switch ) and remove the mains plug from the
socket.
Empty the water tank.
Clean the air dehumidifier with a damp cloth, if required with some liquid
detergent. Do not use scourers ,abrasives, acetone, gasoline petrol etc.
Leave the appliance to stand for one hour before connecting to the mains
supply, if it has been titled or knocked against during cleaning.
AUTOMATIC SWITCH-OFF
When the humidity control switch is turned on the air dehumidifier will
continually monitor the humidity level in the room. As soon as the humidity
level falls below the selected level the compressor will automatically switch
off. The compressor will automatically switch on again when the humidity
exceeds the selected level.
For optimum safety, the appliance will also switch off automatically.
1If the water tank is full (approx. 3.5 liters.)
2If the water tank is removed
HOW THE AIR DEHUMIDIFIERS WORKS
The fan draws the humid air first through the air inlet filter and then through
the metal radiator. This radiator is cooled by a compressor. The water
condensates and drips into the water tank .The dried air is expelled into the
room. The air dehumidifier can automatically maintain the relative humidity
at a pre-selected level in rooms up to 100 cubic meters.
The appliance is able to extract up to 14 liters of water per day
(30 C /86 F, relative humidity = 80% ).
The air filter removes and collects airborne dust.
Whilst in operation, the appliance produces some heat which may raise the
room temperature by 1~2 C (or approx. 3 F)
HOW THE AUTO DEFROST WORKS
When the temperature is under 12 C, the evaporator will start to frost and
affect the dehumidifying result. This unit will defrost automatically once
each hour, and the defrost pilot indicator will light up.
HOW TO USE CONTINUOUS DRAINAGE
To use continuous drainage remove the rubber cap from the continuous
drainage port located on the back of the unit. Transfer the rubber cap to the
tank drainage outlet and replace the water tank. Finally attach an 11mm I/D
PVC hose to the continuous drainage port ensuring the hose is directed
downwards, allowing water to flow by gravity to an external drain.

This appliance is not intended for use by persons (including children) with
reduced physical,sensory or mental capabilities, or lack of experience and
knowledge, unless they have beengiven supervision or instruction
concerning use of the appliance by a person responsible fortheir safety.
Children should be supervised to ensure that they do not play with the
appliance.
Warranty :
The warranty is valid for 1 year for a « manufacturing fault ».
To benefit from the warranty, please return the device to your dealer with POSTAGE
PAID along with the document of purchase proof specifying the date of purchase.
Removal of used domestic appliances
European directive 2002/96/EC on the Electric and Electronic Equipment Waste
requires that domestic appliances not be thrown out together with the rest of
municipal waste. Used devices must be collected separately in order to optimize
recuperation and recycling rates of the materials that make them up and so reduce
the impact on human health and the environment.
The symbol of the crossed out garbage can appears on all the products to remind
the obligations regarding separated collection.
Consumers must contact local authorities or resellers regarding the procedure to
follow for the device's removal.
