Pure-Pro M800-DIRECT FLOW User manual

PRO
P
URE
DRINKING WATE R SYSTEM
REVERSE OSMOSIS SYSTEM
15
PURE-PRO REVERSE OSMOSIS SYSTEM
Type ofproduct
Date of purchase
Name Tel
Address
PRO
P
URE
DRINKING WATE R SYSTEM
USER'S MANUAL
01 Introduction ofM800-Direct Flow
02 What isreverse osmosis
03 Components &Selected filters
04 Cartridge filters
05 The parts of M800-DirectFlow
06 Tubingconnection diagram
07 Installation diagram
08 Change filters
09 Change membrane
10 Operation regulation
12 FAQ
14 Maintenance checkinglist
15 Memo
Thank you verymuch for selectingPure-Pro WaterCorp.
In order to bring the best use of your system, please read
the user's manual carefully before installation and follow
the regulations.
Memo
M800-Direct Flow
M800-Direct Flow
M800-Direct Flow Reverse Osmosis Water Systems

01
PURE-PRO REVERSE OSMOSIS SYSTEM
14
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Introduction of M800-Direct Flow
¨M800-Direct Flow-Unlimited direct flow of fresh water
PurePro M800-Direct Flow system is a modern kitchen appliance that has been
carefully designed with health consciousness, efficiency, high performance and
convenience in mind. PurePro M800- Direct Flow are the world's most elegant
design water filtersystem. Output 1.2liters per minutes. No Tank Required.
PurePro M800-Direct Flow RO system uses reverse osmosis (RO) technology -
which is recognizedas the mosteffective at significantly reducing alarge number
of contaminants that may be in your water - no other home water treatment
system offers you as muchprotection and reliability.
Maintenance checking list
Production: 400 GPD/ 1512 LPD
With a boosterpump (optional):
Input inAC 110Volt, 220Volt or 240Volt (50 /60Hz)
Operation pressure: 10- 80 psi
Dimensions: (cm) 29(L) x 41(H) x 18(W)
Weight: 10 kg - system
Date
Filters
1st stage 2nd stage 3rd stage 4th stage 5th stage Other items
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems
¨Features
No need ofwater storage tank
Easy-open lid foreasily cartridge filtersreplaced
Use inline filterdesign makes filterchanges fast, cleanand easy
Electronic solenoid valve
Flow restrictor,stainless steel checkvalve
European designer faucet
Feed water connector, deliver valve& drain saddlevalve
Quick-connect fitting foreasy installation
Completely assembled &water leaking testing
100% factory testedand sterilized readyfor installation
¨Specifications

Reverse osmosis was originally designed to make sea water drinkable for the
navy. It is ideal for anyone on a low sodium diet. An R.O. membrane has a pore
size much smaller than bacteria virus, or the cryptosporidium parasite. When
functioning properly itwill remove allmicroorganisms from tapwater and produce
sterile water. Reverse osmosis is the reversal of the natural flow of osmosis. In a
water purification system, the goal is not to dilute the salt solution, but to
separate the pure water from the salt and other contaminants. When the natural
osmotic flow isreversed, water fromthe salt solutionis forced topass through the
membrane in the opposite direction by application of pressure-thus the term
REVERSE OSMOSIS. Through this process, we are able to produce pure water
by screening outthe salts andother contaminants.
13
PURE-PRO REVERSE OSMOSIS SYSTEM
02
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
What is reverse osmosis
Reverse Osmosis
Pressure
Membrane
Water flow
FAQ
Q: How will the Pure-Proseries water affect mixed beverages?
Because reverse osmosis removes invisible contaminants that mask flavor, it
allows the natural taste of your beverages to come through. You will be able to
use less coffee and still get the full flavor. Concentrated beverages like orange
juice will taste tangier. You will probably be drinking a lot more water as well,
since many people drink soda, Kool-Aid, concentrated juices, and beer as an
alternative to bad-tasting tap water. Also, Pure-Pro eliminates most of the lime
build up on drip coffee makers, preventing the need for frequent cleaning. No
longer will you find thewhite scum on the insideof pans after boiling water.
Q: How much water doesthe Pure-Pro system produce ?
Under ideal conditions, the RE1812-200 TFC membrane is rated at 400gallons
of production per day (400gpd at 80psi). Under the average conditions, the
consumer can expect 70-95 gallons of product water per day. But that's still a lot
of water for the averagehousehold's drinking and cooking requirements.
Q: Don't people need mineralsremoved from the water ?
Most of the minerals that we receive are from the foods we eat. Only a very
small percentage comes from thewater we drink.
Q: What is the maintenanceschedule for the Pure-Pro System?
The three pre-filter cartridges should be changed every 6 months. The 5 micron
sediment cartridge filter is the first one; the second is a carbon cartridge filter,
and the third one is a 1 micron sediment filters. (some systems comes with the
Extruded carbon filter.) Failure to change the cartridge every 6 months may
cause chlorine to destroy themembrane.
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems

03
PURE-PRO REVERSE OSMOSIS SYSTEM
12
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Components & Selected filters
¨Selected filters
¨Components
PRO
P
URE
DRINKING WATE R SYSTEM
Q: What is the guaranteeon the Pure-Pro system ?
The Pure-Pro System (excluding filters) is guaranteed for 1 year for material
and workmanship. All defective parts will be replaced free within the first year
under natural breakdown. The membrane has one year pro-ratedguarantee.
Q: What factors affect thequantity and the quality ofthe water production?
There are four major variablesto consider:
1.Pressure-The greater the water pressure, the better water quantity and
quality it produced. Water pressure of 60 PSI is ideal.
00
2.Temperature-76 F is the ideal water temperature for R.O. 40 F water will
0
cause the production of R.O. water to fall to half of that at 76 F. The maximum
0
water temperature recommended is 85 F.
3.Total Dissolved Solids (TDS)-The higher the amount of dissolved
contaminants in the water, the lower the quantity of water produced. A high
level of TOTAL DISSOLVED SOLIDS can be overcome with additional water
pressure.
4.Membrane-Different membranes have different characteristics. Some
produce more water than others; some have better contaminant rejection
capabilities; some have greater resistance to chemical abrasion for longer life.
Pure-Pro system includes RE1812-200 The Thin Film Composite (TFC)
membranes combine the best of these characteristics and are considered the
finest membrane in the world.
Q: Can the Pure-Pro systembe connected to an extrafaucet?
It only takes a 1/4" tee and tubing to run the water to a refrigerator or a extra
faucet. Some families run Pure-Prosystem to all of theirbathrooms.
Q: What does the Pure-Proseries drinking water taste like?
The taste of the Pure-Pro water depends on the amount of contaminants in the
tap water originally. If 95% of dissolved minerals and chemicals are removed,
the R.O. water may taste like distilled water (no minerals), bottled water (low
mineral), or natural spring water(moderate mineral content).
FAQ
Infra-red cartridge filter
T.D.S
UVC-LIGHTING
ULTRAVIOLETWATER STERILIZER
Mineral cartridge filter
UV water sterilizer
TDS meter
Infra-Red
Mineral
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems
Deliver-valve Water supplyconnector
Drain saddleTubing
Faucet
RO membrane x2

11
PURE-PRO REVERSE OSMOSIS SYSTEM
04
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Cartridge Filters
PRO
P
URE
DRINKING WATE R SYSTEM
Caution
0
1.Do not usehot water (over45 C)!
2.Do not freezethe machine!
3.Switch off electricity and water source if away for more than 5 days,
and drain outpure water.
Operation regulation
6 Months
2 Years
1 Year
Stage 1
Stage3
Stage 2
GAC Filter
Stage 4
TFC Membrane
Stage 5
Post Carbon Filter
Cartridge Filters Filter Description
6 Months
6 Months
This 5micron sediment filter is made of 100%
pure polypropylene fibers. High capacity filter
removes dusts, particlesand rusts.
It takes out 99% of the chlorine and organic
chemicals. It provides enhanced reduction of
taste, odor,and color.
It takes out 99% of the chlorine and organic
chemicals. It provides enhanced reduction of
taste, odor,and color.
Made in USA. High rejection TFCtype membrane
with the capacityof producing 200gallons per day.
This membrane removes the following hardwater
contaminants that may be present in your water:
lead, cooper,barium, chromium, mercury, sodium,
cadmium, fluoride, nitrite,nitrate, and selenium.
NSF approved. Thispost carbon filter is designed
to improve taste. It removes any residual
impurities and odorsfrom the tank and provides a
finer conditioning ofpure water.
5 Micron
Sediment Filter
Service Life
GAC Filter
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems
A. With everythingconnected, turn onthe water checkfor leaks.
B. Make sure the storage tank shut-off valve is "OFF". Open the sink
top faucet.
C. Within a few minutes (up to 15) the water will start to run from the
faucet slowly.
D. Let the water run for at least 30 minutes. This flushes the carbon
filters on firsttime use.
E. Begin initialflushing.
F.Close the sinktop faucet.The system isnow ready foruse.
G. Change filters regularly every 6 to 12 months and have the
membrane checked annually.

05
PURE-PRO REVERSE OSMOSIS SYSTEM
10
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Operation regulation
The parts of M800-Direct Flow
Front view
Side view
RO membrane housing x 2
Post carbon filter
Input water
Todrain out tube
To the tank
To the faucet
Transformer
ToRO system
2 Turn onwater source.
Pump
1st stage
3rd stage
2nd stage
Solenoid valve
High pressure protector
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems
3 Let the waterrun for atleast 30
minutes. This flushes the carbon
filters on firsttime use.
1 Plug in electricity.

Jaco
06
PURE-PRO REVERSE OSMOSIS SYSTEM
09
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Tubing connection diagram
Faucet
Drain
Input water
A
B
C
PRO
P
URE
DRINKING WATE R SYSTEM
PRO
P
URE
DRINKINGWATE RSYSTEM
4Loose the Jaco fitting anticlockwise. 5Remove the membranehousing
cap anticlockwise.
PRO
P
URE
DRINKINGWATERSYSTEM
6Remove the membrane by a pincer. 7Install the membrane by carefully
pushing the spigotend into the
socket at thefar end ofthe housing
until completely in.
Change membrane
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems
1 Unplug electricity.
ToRO system
2 Turn offwater source. CONNECTING THE COLORTUBING:
A. Connect theWHITE tubing tothe water supplyconnector.
B. Connect theBLUE tubing tothe sink topfaucet.
C. Connect theBLACK tubing tothe drain saddle.

Install European ceramicfaucet :
PURE-PRO REVERSE OSMOSIS SYSTEM
07 08
PURE-PRO REVERSE OSMOSIS SYSTEM
PRO
P
URE
DRINKING WATE R SYSTEM
Install drain saddle:
1.Remove the membrane housing cap.
2.Replace the membrane.
Assemble membrane :
Drill a 1/4"hole into
the drain pipe.
Mount drain
saddle aligning
holes.
Installation diagram
5 Turn onwater source andwater
tank, drain out1 Gallon ofwater
to purify replacement filters.
PRO
P
URE
DRINKING WATE R SYSTEM
Change filters
2Turn off water source.
ToRO system
3Loose the Jaco fitting anticlockwise.
Jaco
4Remove the usedfilters from clips
and replace withnew ones.
1 Unplug electricity.
M800-Direct Flow Reverse Osmosis Water Systems M800-Direct Flow Reverse Osmosis Water Systems
Input water :
ToRO system
Deliver valve
Tofaucet
Towater source pipe
