PURE Jongo A2 User manual

FRANÇAIS
FR
ESPAÑOL
ENGLISH
A2

EN
Get Connected
Download the free Pure Connect app to
immerse yourself in music.
Download the free Pure Connect app on your iOS or Android
device, and connect your Jongo to a world of music.
Pure Connect lets you stream your own music collection,
gives you access to over 20,000 live radio stations from
around the world, podcasts and a library of over 200,000
on‑demand programs.
from the
Apple App Store
from
Google Play

Setting up your first Jongo?
• Connect Jongo to your hi‑fi or microsystem.
• Insert the connector of the AC power adapter into
the socket on the rear of Jongo and plug in to the AC
power supply.
• If you have already set up your first Jongo, jump to
step
7
.
When the Power light turns solid
green, press the Wi-Fi button
on the base of Jongo.
Wait a few seconds for the
Power light to flash amber.
4000696
Conforms to UL
Std. 60065
Certified to CSA Std.
C22.2 No. 60065
This device complies
with Par t 15 of the FC C
Rules . Operat ion is
subje ct to the fol lowing
two con ditions: (1) This
device m ay not caus e
harmf ul inter feren ce, and
(2) this d evice mus t
accep t any inter feren ce
received, including
inter ferenc e that may
cause u ndesir ed
operation.
FCC ID: X280068
IC: 8864A-0068 Designed and engineered in the UK
Assembled in China
WiFi
Model A240

EN
Search for Jongo
• On your mobile device search for available Wi‑Fi networks.
• Your Jongo will be listed as a network.
• Connect to this network.

A
B
C
D

EN
Add Jongo to your wireless network
The Jongo Setup page should open automatically on
your device. If not, open your internet browser and enter
myjongo in the address bar.
If you want to rename your Jongo, type in the new name
and tap Change name.
Select your wireless network.
Enter your network password if required and tap Connect.
!
Once you tap Connect the light will pulse and
then turn solid green to show that your Jongo is
connected.
If the connection fails, the light will flash
red. Don’t worry, this probably means
you mistyped your Wi‑Fi password.
Just go back to step 2 and try again.
If the problem persists visit support.pure.com/us
A
C
D
B

EN
Analogue audio
Connect to 3.5mm input of any audio product, or to analogue
inputs on an amplifier, receiver, TV or monitor.
Digital coaxial out
Connect to digital coaxial (S/PDIF) input on an amplifier or
receiver.
Digital optical out
Connect to digital optical (S/PDIF) input on an amplifier or
receiver.
A
B
C
Choosing your audio connection
Line out Digital optical out
Digital coaxial out
R
L
5.5V DC
Jongo
A2
A
B
C

Jongo A2 Safety Instructions
1. Read these instructions – All the safety and operating instructions should be read before this product
is operated.
2. Keep these instructions – The safety and operating instructions should be retained for future
reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Unplug the apparatus during lightning storms or when unused for long periods of time.
11. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power‑supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
12. WARNING Please refer to the information on the bottom exterior of the enclosure for electrical and
safety information before installing or operating the apparatus.
13. WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with
liquids, such as vases, shall not be placed on apparatus.
14. WARNING: The direct plug‑in adapter is used as disconnect device, the disconnect device shall
remain readily operable.
15. Use only power supplies listed in the user instructions (with model no. KSAA0550100W1UV‑1,
manufactured by Pure).
16. This equipment is a Class II or double insulated electrical appliance. It has been designed in
such a way that it does not require a safety connection to electrical earth.

EN
Approvals
CE marked. Hereby, Pure, declares that this Band II LPD device is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/EC. The
Declaration of Conformity may be consulted at: http://www.pure.com/R&TTE‑DoC.
Australian C‑Tick N1600 and Electrical Safety.
Acknowledgement of License Agreements
Portions of the code used in Jongo A2 are subject to the GPL, LPGL, BSD, and other open source
licenses. For more details please refer to: http://www.pure.com/licensing
Warranty information
Imagination Technologies Limited warrants to the end user that this product will be free from defects
in materials and workmanship in the course of normal use for a period of two years from the date
of purchase. This guarantee covers breakdowns due to manufacturing or design faults; it does not
apply in cases such as accidental damage, however caused, wear and tear, negligence, adjustment,
modification or repair not authorised by us. Should you have a problem with your unit please contact
your supplier or contact Pure Support at: http://support.pure.com/us.
Disclaimer
Imagination Technologies Limited makes no representation or warranties with respect to the
content of this document and specifically disclaims any implied warranties of merchantability or
fitness for any particular purpose. Further, Imagination Technologies Limited reserves the right to
revise this publication and to make changes in it from time to time without obligation of Imagination
Technologies Limited to notify any person or organization of such revisions or changes.
Trademarks
Jongo, Pure, the Pure logo, Imagination Technologies and the Imagination Technologies logo are
trademarks or registered trademarks of Imagination Technologies Limited.
Copyright
Copyright © 2013 Imagination Technologies Limited. All rights reserved. No part of this publication
may be copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated
into any human or computer language, in any form or by any means, electronic, mechanical,
magnetic, manual or otherwise, or disclosed to third parties without the express written
permission of Imagination Technologies Limited. Version 1 August 2013.

FCC NOTICE TO A USER IN THE UNITED STATES
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a
separation distance of at least 20 cm from all persons.

EN
IC NOTICE TO A USER IN CANADA
Since digital circuitry may cause interference to other radio or television tuners nearby, switch this
unit off when not in use or move it away from the affected radio/television tuner.
NOTE: This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus as set out in the Radio Interference Regulations of Industry Canada. These
limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television operation (which
can be determined by turning the equipment off), the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.

After selecting the content that you want to listen to, the
player bar will appear at the bottom of the screen.
Open the Pure Connect App and select the
music you want to listen to.
You can choose from Pure Music*, live radio, on‑demand
content, ambient sounds and the music stored on your device.
*Pure Music is only available in certain countries. Please see http://www.pure.com/availability/
for details.
A
A

EN
Congratulations!
You’re all set up. Enjoy your music.
Start streaming!
To stream to your Jongo:
Tap
in the player bar to view a list of available Jongo
devices on your network.
Tap next to your Jongo.
A
B
A
B

Adding another Jongo to your network?
1. Switch on your new Jongo.
2. Press and hold the Wi-Fi button on any Jongo that is
already connected to your network until the Power light
pulses green.
3. Press and hold the Wi-Fi button on the base of the
new Jongo until the Power light pulses green.
After around 30 seconds, the Power lights on both Jongos
will light steady green to confirm that the new Jongo is
connected to your network.

EN
Need more help?
Watch our Jongo setup video at:
www.pure.com/jongo-setup-video
Download the full user guide at: support.pure.com/us

Using Bluetooth
1. Enable the Bluetooth option on your mobile device and
search for Bluetooth devices.
2. Pair.
If your device requires a key enter “0000”.

EN
Analogue audio
Connect to 3.5mm input of any audio product, or to analogue
inputs on an amplifier, receiver, TV or monitor.
Digital coaxial out
Connect to digital coaxial (S/PDIF) input on an amplifier or
receiver.
Digital optical out
Connect to digital optical (S/PDIF) input on an amplifier or
receiver.
A
B
C
Choosing your audio connection
Line out Digital optical out
Digital coaxial out
R
L
5.5V DC
Jongo
A2
A
B
C

Jongo A2 Safety Instructions
1. Read these instructions – All the safety and operating instructions should be read before this product
is operated.
2. Keep these instructions – The safety and operating instructions should be retained for future
reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Unplug the apparatus during lightning storms or when unused for long periods of time.
11. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power‑supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
12. WARNING Please refer to the information on the bottom exterior of the enclosure for electrical and
safety information before installing or operating the apparatus.
13. WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with
liquids, such as vases, shall not be placed on apparatus.
14. WARNING: The direct plug‑in adapter is used as disconnect device, the disconnect device shall
remain readily operable.
15. Use only power supplies listed in the user instructions (with model no. KSAA0550100W1UV‑1,
manufactured by Pure).
16. This equipment is a Class II or double insulated electrical appliance. It has been designed in
such a way that it does not require a safety connection to electrical earth.
