PureAiro DSC 120ES User manual

Installation & Operations Manual
Additionall Features
Engineered for low temperature operation and the air flow
issues that crawl spaces present.
Ducting options for divided spaces.
Remote Control equiped.
Heavy-Duty Condensate Pump.
Quick connector to Pump(the pump can be taken out freely
just full out the quick connector).
PUREAIRO
DSC 120ES
PureAiro solutions inc.
Add: Berlin, Germany.
Tel: [phone]
E-mail: [email protected]

TABLE OF
CONTENTS
01
We at PureAiro are have dedicated our lives to helping you combat high
humidity levels, the DSC 120ES unit is one of the best dehumidifiers in the
market today. With a power capacity of extracting over 100 L,you are guaranteed
a long-term fix to all your humidity issues.
The DSC 120ES is the perfect dehumidifier for your crawl space, basement
or whole house, where most humidity issues are experienced. Equipped with
a powerful condensate pump and a pipe, all the extracted water is pumped
out of the house and poured out away the house.
PRODUCT INTRODUCE
Impotant Notes
Warranty Registration
Specifications
How it Works
Installation Requirement
Installation
Key Functions
Indicator Lights
Remote Control
Operating Instructions
Unit Diagram
Maintenance
Dehumidifier Storage
Troubleshooting
Warranty Information
02
02
02
03
03
03
04
05
05
60
07
08
10
11
12
00
PureAiro DSC 120ES

02 03
PureAiro DSC 120ES
INSTALLATION
Place dehumidifier on a level surface.
Do not place unit directly on vapor barrier. For example, use blocks or pavers to create a
level surface.
1
2Set up the drain line
Plug dehumidifier into grounded 15 amp circuit.
Remove the compression nut and slide it over the end of the hose to be attached to unit.
WARRANTY REGISTRATION
SPECIFICATIONS
Your dehumidifer comes with an extensive warranty.
For future reference, write down the model, serial number, and date of purchase for your
dehumidifier. This information is necessary for seeking assistance in the future and can be
found on the data label on the side of the unit.
Fdca adtora qestors cncemin your diridte. cnatyor
local nsaller or call PureAiro at [phone]
Model Number:
Serial Number: Date Of Purchase:
IMPORTANT NOTES
PureAiro DSC 120C
3
Do not use the dehumidifier in standing water. If there is a chance that the dehumidifier
has been flooded, unplug the unit, remove the cover, and allow it to dry completely before
proceeding.
Do not insert objects or your fingers into the inlet or discharge.
Your dehumidifier should only be repaired by a qualified technician.
Unless otherwise noted, all maintenance should be done with the unit powered off.
Always connect your dehumidifier using a grounded electrical connection(as required for
all electrical appliances). The use of non-grounded wiring will void the warranty.
Do not use water to clean the exterior of the dehumidifier. To clean unit,unplug from
power, then use a damp cloth to wipe the exterior.
Do not stand on dehumidifier or place objects on it.
Do not use with extension cord or plug adapter.
Airflow : 350 m³/H
Operating Temp. Range: 3-40℃
Operating Relative Humidity Range: 36%-90%
COP: 3.5 L/kWh
Refrigerant: R410A
Amperage Usage: 6 Amps
Power Supply: 230V / 50Hz / Single Phase
Outlet Requirement: 15 Amp
Sound Level: 60 dBa
Dimensions L x W x H: 600 x 360 x 430mm
If unit has been turned or flipped so that the compressor did not remain upright, place the
unit on a level surface and wait a minimum of 2 hours before proceeding.
Slide the side of hose with compression nut over the insert on the compression fitting
completely.
Tighten compression nut.
INSTALLATION REQUIREMENTS
The area where the dehumidifier is located should be sealed with a vapor barrier.
If the unit is installed in a crawl space, all vents should be sealed.
For proper ventilation, neither the inlet or discharge should be positioned against a wall.
The inlet needs a minimum of 12" clearance and the discharge requires a minimum of
36" clearance.
For the best air diffusion, install the unit so that a side panel faces the wall.
PureAiro dehumidifiers are only intended for operation when the unit is upright and level
with the feet on the ground.
HOW IT WORKS
PureAiro dehumidifiers use an integrated humidistat to monitor theconditioned space.
When the relative humidity goes above the selected setpoint, the dehumidifier will energize.
Air is then drawn across an evaporator coil, which is cooler than the dew point of air. This
means moisture will condense out of the air. The air is then reheated through the condenser
coil and distributed back into the room.
Capacity @ 30℃/80%RH: 100 L/Day
Capacity @ 27℃/60%RH: 60 L/Day

04 05
PureAiro DSC 120ES
Manual Drain Button
If you need to store or move your dehumidifier, press the “Drain” button to remove water
from the integral pump’s reservoir.
4
INDICATOR LIGHTS
Humidity Display Screen
The display screen has two functions:
1
2Power Indicator Light
Continuous Mode/ Auto Defrost Light
This light indicates that the unit is properly powered on and ready to operate.
3
1. When the unit is powered on, it shows the humidity of the space
2. When setting the desired humidity level, the screen will show the set point.
Always make sure the unit is “off” prior to performing any service, unless otherwise
indicated.
If the humidity is above the setpoint, the light will be solid green and the machine will
operate.
After a brief delay, it will revert to current humidity of the space.
If the humidity is below the setpoint, the unit will be in standby mode and the light will be
flashing.
When the light illuminates green, it indicates that the dehumidifier is set to continuous
operation mode.
When the light illuminates red, it means the unit is in auto defrost mode and clearing the
evaporator coils of any ice buildup.
Compressor Light
4
When the light illuminates red, it indicates the compressor has been initiated but is
currently warming up.
Once the light switches to green, it means the compressor is currently in working status.
REMOTE CONTROL INSTRUCTIONS
PureAiro Dehumidifiers can be controlled using an optional remote accessory. The remote
connects to your dehumidifier via a 25’ CAT 5 cable, with the integrated sensor giving you
multiple options for monitoring surrounding conditions.
Example #1- Install the dehumidifier in the laundry room and duct it into the living room.
Mount the remote in the living room and use the remote sensor.
Example #2- Install the dehumidifier in your crawl space with the remote mounted in your
garage.
KEY FUNCTIONS
Power Key
Use this button to turn the dehumidifier on and off.
1
Press once to turn machine on. You will hear two beeps and the light will illuminate green
(solid or flashing depending on mode).
Press the power button a second time and you will hear one beep as the machine shuts
down. Note that there is a 1 minute fan delay.
Arrow Buttons
Use the up and down arrow buttons to set the desired humidity setpoint on the display
screen.
2
The setpoint can be any number between 36%-90%. When the indoor humidity is higher
than the setpoint, the unit will operate.
Press the power button a second time and you will hear one beep as the machine shuts
down. Note that there is a 1 minute fan delay.
Keep in mind that the displayed humidity levels are approximate ( +/-5%)
Continuous Mode
To set the unit to run continuously regardless of humidity, simply use the down arrow key
to set the humidity below 36%.
3
The continuous light will illuminate green and the display will show “CO”.
To switch back to normal humidistat operation, use the arrow keys to move the setpoint
above 36%.

06 07
PureAiro DSC 120ES
OPERATING INSTRUCTIONS
Press the power key to turn the machine on.
START THE MACHINE
Use the up and down arrow keys to adjust your desired setpoint (typically 50-55%).
ADJUST THE SETTINGS
Press the power key again and the machine will stop. Note the fan will continue to operate
for 1 minute after the unit has turned off.
DO NOT DISCONNECT THE POWER CORD TO FORCE THE UNIT TO STOP.
STOP THE MACHINE
The PureAiro DSC 120ES has an integrated condensate pump. During normal operation,the
DSC 120ES will automatically drain as required.
WATER DRAINAGE
1
2
3
4
NOTE: The symbols indicated below only show when the remote is powered on.
Press the on/off button and the machine will
start running (one beep). Press the button
again to the turn the machine off.
Use the Up and Down arrow buttons to adjust
the humidity level.
ON/OFF (POWER)BUTTON
UP BUTTON▲ / DOWN BUTTON
Use the Mode button to switch between
dehumidification and a ducted application.
MODE
The symbol on the display board indicates
the sensor on the remote control is being
utilized.
The symbol on the display board indicates the sensor on the dehumidifier is being utilized.
TEMPERATURE
Press the temperature button to display the current temperature on the screen.
1
2
3M
4
DRA IN PUMP
MODE
LCD M ONITOR
CONTINUOUSTEMPERATURE
DOW N BUTTONUP BU TTON
ON/OFF
Press this button to switch the unit into continuous mode. “CONT.” will appear on the display
screen.
Use this button if the unit will not be used for an extended period of time.
This button will remove water from the pump reservoir.
CONTINUOUS
DRAIN PUMP
5
6
UNIT DIAGRAM
Front View
HANDLE
SIDE PANEL
CONTROL PANEL
PRE-FILTER
Back View
REMOTE CONTROL
DRAIN HOSE
CONNECTION
AUXILIARY TERMINALS
VENTILATION FAN PORT
(OPTIONAL)
POWER CORD
DISCHARGE GRILLE

08 09
PureAiro DSC 120ES
MAINTENANCE
Always unplug the unit before doing any maintenance.
WARNING
CLEANING THE MACHINE BODY
COIL MAINTENANCE
Use a soft, damp cloth to clean the exterior of unit. Do not use any soap or solvents.
Unplug the unit.
For PreFilter:
ELECTRICAL ACCESS
1.
2.
3.
**For more detailed instructions, visit www.PureAiro.com**
Once per year, clean the coils with an approved coil cleaner. The coil cleaner should be a
self-rinsing, foaming, cleaner, such as WEB® Coil Cleaner.
CLEANING THE FILTER
a. Remove prefilter from inlet of machine.
b. Vacuum or wash with warm water (no soap).
For MERV-10/HEPA/Carbon Filters:
a. Replace as necessary- we recommend checking the filters at least 1x/year
Unscrew the 13 screws on the side panel.
Remove the 2 screws on the control board cover.
PUMP MAINTENANCE
Your PureAiro DSC 120ES is equipped with an integral condensate pump designed to
pump water from the dehumidifier out to the desired drain.
The pump requires routine maintenance that is not covered by the warranty.
Preventative maintenance is necessary to prevent issues from dirt and slime that may
accumulate in the drain system. This includes the drain pan, hose to the condensate
pump,pump reservoir, pump head assembly, and discharge tubing.
1
2
3
4
Remove the 9 screws on the side panel and set
panel aside.
Remove the screw holding the pump in place.
Undo the 3 pump electrical quick connects and 1 drain quick connect.
Insert a flat head screwdriver into the notch on the side of the pump. This will allow you
to gently lift the pump off its reservoir (the reservoir remains attached to the unit).
REMOVING THE PUMP
BASIC PUMP CLEANING
Complete about once per year, depending on environment
Remove filter(s) from inlet of unit to access drain tray. Press the drain button to drain
the reservoir.
Disconnect power to the dehumidifier.
Mix a 453.6g solution of bleach (30 ml bleach + 443.6 ml water) OR vinegar (118.3 ml
white vinegar + 354.9 ml water).
Pour the cleaning solution into the drain tray at the base of the coils.
If any cleaning solution gets on the coils, flush with water.
Allow solution to soak for 15 minutes.
Reconnect the dehumidifier to power.
Fill the reservoir with water (473.2-946.4 ml) and flush/cycle the pump at least 2x.
If the drain line is still filled with debris, repeat process. If drain line still does not
appear clean, move on to Advanced Cleaning.
1
2
3
4
5
6
7
8
ADVANCED PUMP CLEANING
Complete as needed
Press the drain button to drain the water from the reservoir (a wet-dry vacuum or towels
can be used to remove any remaining water).
Unplug the dehumidifier and remove the cover so you have access to the pump.
Remove the pump head from the reservoir by unscrewing the screw.
Wipe reservoir clean with a paper towel.
Reassemble pump.
1
2
3
4

10 11
PureAiro DSC 120ES
TROUBLESHOOTING
SYMPTOM CAUSE SOLUTION
Verify that both ends of the
power cord are plugged in
Poor Connection
Display is
Blank
Clean the filter
Clear the blockage
Filter is Dirty
No Airflow
Error Code: E1
Increase the room temperature
so it is within operating range
(above 3℃). If error still
displays, check sensor.
Error Code: E4
Decrease the room temperature
so it is within operating range
(below 40℃). If error still
displays, check the sensor
Contact Your Installer for
Assistance
Error Code: LO
Power Outage Reset power
Air Inlet or Outlet
is Blocked
Check to ensure that the sensor
wire is connected at both ends.
if no issues a re visible, the
sensor may be faulty.
Verify that the pump is properly
installed and functioning. If so,
unplug the unit for two minutes,
then restart.
Error Code: HI
E5 Error Code
Humidity Sensor or
Communication Error
Problem with Pump
Room Temperature is
below 3℃
Room Temperature is
above 40℃
Refrigerant Leak
5
6
7
8
9
Mix a 454g solution of bleach (30 ml bleach + 443.6 ml water) OR vinegar (118.3 ml white
vinegar + 354.9 ml water).
Pour the cleaning solution into the drain tray at the base of the coils.
If any cleaning solution gets on the coils, flush with water.
Allow solution to soak for 15 minutes.
Reconnect the dehumidifier to power.
Fill the reservoir with water (473.2-946.4 ml) and flush/cycle the pump at least 2x.
DEHUMIDIFIER STORAGE
If the unit will be stored for an extended period of time, complete the
following steps:
1. Turn off the unit and allow it to dry.
2. Complete steps 1-3 in Advanced Pump Cleaning to clean out the pump reservoir.
3. Wrap and secure the power cord.
4. Cover the filter mesh.
5. Store in a clean, dry space.
DUCTED APPLICATIONS
Ducting the dehumidifier allows the unit to be in one room while conditioning an adjacent
room. Both the inlet/return grille and the supply grille are designed for 254mm flex ducting.
DUCTING INSTALLATION NOTES
Be sure to secure the ducting with tie wrap.
Maximum total length of duct run = 10’
Inlet and outlet duct adapters are optional accessories
DUCT ADAPTER INSTALLATION
Screw in the 4 screws on each duct adapter.
FLEX DUCT INSTALLATION
Slide ducting over adapter and secure with tie wrap or clamps Pump Alarm- E4 Error Code
**UNIT WILL NOT FUNCTION UNTIL ERROR CODE IS CLEARED.
If E4 (pump alarm) is shown on the display, complete the following steps:
1
2
3
4
Reset the unit by unplugging the power cord and then reconnecting it.
Manually check to see if the pump is operational by pressing the drain button. Check if
the pump energizes and de-energizes properly. Additionally, check to see if any water
purged from the system.
If you haven’t cleaned the system recently, check the discharge line for an
obstruction,then clean as described in the Maintenance section.
Replace the hose and/or pump, if maintenance alone isn’t sufficient.

LIMITED WARRANTY EXCLUSIONS
EXCLUSIONS:
DAMAGE DUE TO THE FOLL OWING IS NOT COVERED UNDER WARRANTY
ACTS OF NATURE- INCLUDING BUT NOT LIMITED TO:
FLOODING
FIRE
WATER DAMAGE
HURRICANE / STORM DAMAGE
IMPROPER USAGE- INCLUDING BUT NOT LIMITED TO:
POOL / SPA / TUB APPLICATIONS
MISUSE, ABUSE, OR TAMPERING WHETHER INTENTIONAL OR ACCIDENTAL
IMPROPER INSTALL ATION OR DESIGN
IMPROPER VOLTAGE
LACK OF NORMAL CARE
FAILURE TO FOLLOW INSTRUCTIONS
CORROSION
FREEZING
ANY ADDITIONAL COSTS DUE TO CHANGES IN LAWS OR BUILDING CODES
FREIGHT CHARGES
ANY COSTS DUE TO LOST PROFIT OR DELAY
DAMAGE TO PROPERTY
CAUSE BEYOND CONTROL
CONSUMABLE PARTS, INCLUDING BUT NOT LIMITED TO:
FILTERS
BATTERIES
POWER CORDS
VALVES
SWITCHES
RUBBER PARTS
DIRECT, INDIRECT, COLLATERAL OR INCONSEQUENTIAL DAMAGES OF ANY KIND
THE WARRANTIES AND LIABILITIES SET FORTH ARE IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED, IN LAW OR IN FACT, INCL UDING IMPL IED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE. PureAiro's total liability, regardless
of nature of claim shall not exceed original purchase price of the product if a product or component is
replaced while under warranty, the applicable warranty period shall not be extended beyond the original
warranty time period.
LIMITED WARRANTY
All warranty benefits apply to the original owner only. Warranty cannot be transferred or
assigned.
1 YEAR (FROM DATE OF PURCHASE): PureAiro warrants the dehumidifier will operate
free of defects in workmanship and materials. At it's discretion, PureAiro will repair or
replace any malfunctioning components, free of charge (excluding transportation costs)
3 YEARS (FROM DATE OF PURCHASE): PureAiro warrants the refrigeration circuit
(compressor, condenser and evaporator) will operate free of defects in material or
workmanship. At it's discretion, PureAiro will replace defective parts,including factory labor
or refrigerant. This does not include transportation.
5 YEARS (FROM DATE OF PURCHASE): PureAiro warrants the compressor, condenser,
and evaporator will operate free of any defects in material or workmanship. At it's
discretion, PureAiro will repair or replace the defective parts. This does not include labor,
transportation, or refrigerant.
CUSTOMER RESPONSIBILITIES: In order to take advantage of the warranty service, the
customer must do the following:
Customer must provide normal care and maintenance (including, but not limited to
cleaning filters, coils and pumps)
If customer cannot return unit to certified repair center, all costs associated with freight
shipment are borne by the customer. In addition, all duties related to freight shipments,
including but not limited to palletizing, wrapping, labeling,and pickup are associated with
customer.
If shipped, customer is responsible for all risk of loss or damage.
PUREAIRO WARRANTY STEPS:
Once receive the goods customers must log in www.pureairo.com to fill out the warranty
Registration form and submit to PureAiro company. We will receive your purchasing and
installation information and save it.
If no warranty registration is sent to us, warranty period will begin the day the shipment
left the warehouse. Please be sure to record serial # and date of installation. You will
need this information to receive the RA number.
If warranty service is necessary, customers must contact PureAiro Tech Support by
[e-mail] or local technical service phone to receive a Return Authorization
(RA number). Once an RA has been issued, customers should bring the unit to a certified
repair center. PureAiro wil arrange the shipping to bring the unit back to the Alorair
warehouse (at the expense of the customers) if customers are not available.
After the unit has been received by PureAiro (whether at a repair center or the
warehouse), PureAiro will have an initial inspection. If it is determined to be invalid
warranty claim (see exclusions below), customers have to pay for all associated repair
costs and shipping costs for units repair.
Customers can pick up the unit after repair at their own expense for shipping. Units will
have a rigorous testing before sending it back to customers.
If the unit can no longer be fixed , and it is in the warranty period and determined to be
valid claim, we will ship the customer a new unit within the same year warranty from the
date of replacement.
After parts are repaired or replaced by PureAiro, the original warranty period continues
to apply until it meets its deadline.No extensions to the original warranty period.
1
2
3
4
Removal and re-installation of unit is the sole responsibility of owner.
1
2
3
4
5
6
1
2
3
4
5
6
7
8
9
10
11
PureAiro DSC 120ES
12 13
The foregoing shall constitute the total liability of seller in the case of defective performance of all or any
of the equipment or services provided to buyer. buyer agrees to accept and hereby accepts the foregoing
as the sole and exclusive remedy for any breach or alleged breach of warranty by seller.
Any dishonesty or fraud in connection with PureAiro warranty thoroughly voids all warranty policies.
PureAiro expressly reserves the right to pursue legal action in the event of dishonesty, fraud, or
attempted fraud.
