PureAiro GUARDIAN 155 User manual

Installation & Operations Manual
PUREAIRO
GUARDIAN 155
(Plasma Sterilizer)
PureAiro solutions inc.
Add: Berlin, Germany
Tel: [phone]
E-mail: [email protected]

TABLE OF
CONTENTS
01
PRODUCT INTRODUCE
Warnings and safety instructions
Specification
Unit Diagram
Operation
Wiring Diagram
Warranty
02
02
04
05
07
07
00
PureAiro Guardian 155
It features a powerful ozone occurrence with 10,000mg/h output. It is a
strong ozone generator that is suitable for home use and could be deployed
in large areas, including restaurant garages, offices, and hotels.
It is a broad-spectrum disinfection that will not cause secondary pollution.
Besides, it eliminates musty smell and odor.

02
Do not use this product near high-precision electronic equipment. Radio wave
interference may cause misoperation of high-precision electronic equipment and other
problems . Pay special attention especially in the vicinity of the following equipment:
hearing aids, pacemakers and other medical electronic equipment, fire detectors, and
other high-precision automatic control devices.
Do not disassemble or modify this product, otherwise it will cause damage, leakage and
circuit failure of this product.
Excessive moisture，water or other liquids entering the product may cause leakage and
malfunction of the product.
Avoid wiping the equipment with volatile solvents or organic solvents, which may
damage the surface of the equipment.
Qualified dedicated grounding wire, safe and reliable grounding, the capacity of the line
used is in line with the requirements to ensure the elimination of fire hazards. The
equipment installer must be trained to start the repair.
Remember that equipment maintenance or repair must be performed in a power-off
state to ensure the safety of personnel.
PureAiro Guardian 155
1
SPECIFICATIONS
Plasma generation: +2.000.000/cm3 positive ions, -3.0000.000/cm3 negative ions
Input voltage: A. American standard:110V, 50~60Hz;
B. European standard: 220V, 50~60Hz
Ambient temperature requirements: -10℃~35℃
Environmental humidity requirements: <65%.
Timer: 24h
Service life: 20,000h
Applicable area: 20-30 square meters
2
3
4
5
6
7
WARNINGS AND SAFETY INSTRUCTIONS
1
2
3
4
5
6
03

04 05
PureAiro Guardian 155
OPERATION
Pay attention to placing the equipment on the ground or on the support steadily, keeping
the bottom surface level.
To maintain the disinfection effect, please close the doors and windows. When the
machine is working, both humans and animals can stay indoors.
Turn on the power. There is a interface on the air inlet panel of the machine, just connect
the power cord to the socket.
UNIT DIAGRAM
1
2
3
The air inlet panel is as shown
The tuyere view is as follows
HANDLE
ROTATE THE
BUTTON
AIR
OUTLET
RETAINING CLIPS
(4 ON BASE)
AIR
INLET
POWER
SUPPLY
Vertical,
upright
position
INDICATOR
LIGHT

06 07
PureAiro Guardian 155
WIRING DIAGRAM
OFF is the default shutdown state, the startup state is ON, the indicator light is on, and
the plasma generator and fan are always in operation.
Function description of plasma disinfection machine
(description of the state of switch machine)
Turn the knob arrow to the corresponding position and set the running time to the
corresponding working time between 00:00 and 24:00,During the operation, the
indicator light is on and the plasma sterilizer and fan are always running. When the
knob arrow returns to OFF, the machine is turned off.
Once the operation of the machine is finished, it will take some time for the remaining
ozone to decompose. The room must be suitable for people to stay in before they can
be allowed to occupy it. Note that the standard dictates that people should not smell
the ozone.
Included accessories:
1 x fuse, 1 x manual, 1 x warranty card, 2 x anti-mosquito soft magnetic
stickers.

Return the unit to a certified repair center. If the customer fails to return the unit to our
warehouse, they will bear the cost of freight and shipment. Besides, the customer will
foot for all the duties related to shipment or freight. This will include but not limited to,
palletizing, labeling, wrapping, and cost of pickups.
If the unit is shipped, the customer will be responsible for the risks associated with the
equipment's damage or loss.
The steps we follow
As soon as the purchased goods are delivered, the customer must log in to our website
www.PureAiro.com and fill the warranty form. A duly filled registration form will need to be
submitted to PureAiro Company. We expect to receive the installation and purchasing
details and save them in our system.
If the buyer does not register, the warranty period is considered to start running on the
day the unit left our warehouse. So ensure to capture and record the serial number and
the date the unit was installed. This information will help you receive the RA number.
If the customer feels that they need the warranted service, they will need to contact
PureAiro Tech support or a local technical service phone so that they can receive the
return authorization number (RA) The number allows the customer to forward the unit to
a certified repair center. PureAiro will organize and arrange how the unit can be shipped
back to our PureAiro warehouse. But this will be done at the customer's expense.
1
2
3
4
3
4
08 09
PureAiro Guardian 155
For a period of one year, PureAiro warrants that the dehumidifier will operate free of
material or workmanship defects. The company may elect to replace or repair a
malfunctioning component free of charge, but the owner must pay the cost of transporting
it.
3
For three years starting from the date the unit was purchased, PureAiro warrants that the
evaporator, compressor, and condenser will operate free of workmanship and material
defect. But the company will replace any defective parts and pay for refrigerant and factory
labor. But the owner will pay for the transportation cost.
For a period of five years commencing on the date of purchase, PureAiro warrants that the
evaporator, condenser, and compressor will operate without any defect in the workmanship
or material. The company will thus replace, repair any defective parts, but it will not cater for
labor, refrigerant, and transportation.
Customer's responsibilities
Provide normal care, including maintenance. This is not limited to cleaning the pumps,
coils, and filters.
For the warranty to remain valid, the customer must perform the following functions
Remove and reinstall the unit appropriately.
1
2
Once the unit is received at our warehouse or repair center, PureAiro will have it
inspected. If it is found to be an invalid claim, the exclusion rule will apply. Also, the
customer will pay the associated costs of repair, shipping, and transportation cost.
Customers may pick the unit after it has been repaired and be required to pay for
shipping expenses. Meanwhile, the unit will be rigorously tested before it is shipped back
to the customer. However, if it cannot be fixed, yet it is in the warranty period that has
been determined to be valid, PureAiro will ship a new unit to the customer within the
same warranty years.
Once the parts have been replaced, and the unit has been repaired, the original warranty
period will continue to apply until it expires. The original warranty period cannot be
extended even when new equipment is shipped.
Losses occasioned by improper operation and failure of the machine, or if disinfection or
sterilization fails to meet the standard, will be borne for by the buyer. In such a case, the
company will not assume responsibility.
The company will not assume responsibility for losses occasioned by non-adherence to
instructions.
We will not assume responsibility for any loss caused by natural disaster like floods and
earthquakes. Also, losses due to behavioral accidents, user's intentional or accidental
abuse, and the company will not be responsible.
The company will not assume responsibility for any loss caused by improper operation or
use of the product. Losses such as production interruption loss of profit and others will
not be catered for.
WARRANTY
1
2
3
Limited Warranty
For one year, PureAiro warranties that the warranty will operate free of defects in material
and workmanship. The warranty cannot be assigned or transferred to third parties.
Warranty benefits will only apply to the original buyer. The warranty cannot be transferred
or assigned.
1
2
4
