PureLink SC-DS1 User manual

SC-DS1 Owner’s Manual
DVI or HDMI 3G/HD-SDI Format Converter
PureLinkTM
535 East Crescent Ave
Ramsey, NJ 07446
Tel: [phone]
Fax: [phone]
Website : www.purelinkav.com
E-mail : [email protected]
For Technical Support, contact us at
: [email protected]

Contents
Contents p. 2
Description, Features p. 3
Product Specification p. 4
Environmental and Reliability Specifications p. 5
Video Connection p. 5
Mechanical Specification p. 6
Technical Specification p. 7
Warranty Information p. 8
Troubleshooting p. 9

PureLink by Dtrovision
3
Package Contents
Please make sure all of the following items are included in the package:
1 x SC-DS1 Unit
1 x 5V Power adapter
1 x User Manual
Description
Purelink’s SC-DS1 Signal Converter transforms any DVI or HDMI signal to a 3G/HD-SDI output.
The interface consists of a single 3 Gb/s serial link, and is standardized in SMPTE 424M for Dual-
Link 3G/HD-SDI. The pure digital conversion from DVI/HDMI to SDI guarantees lossless
transformation for both audio and video.
Main Features
High Quality Picture - No Signal Loss and Digital Noise Free
Our SC-DS1 is designed to deliver the highest quality picture preserving the native
resolutions of the video sources without any signal loss. At the same time, the digital
noises that may affect the picture quality will be eliminated. Due to the nature of the
digital signals and passing through multiple stack of connection, it is important to
eliminate the digital noises and boost the signal strength to preserve/enhance the video
signal quality, which SC-DS1 does.
Signal Amplification for signal reliability and long length signal transmission.
SC-DS1 uses external DC 5V power to run an internal chipset, which was designed to tra
nsmit high quality visual signal to long distance.
Compact and Practical Design
The SC-DS1 is designed compactly and practically allowing customers more ease and con
venience
Full HD without changing display
With previously used HDMI/DVI display user can enjoy full HD from new source device w
ithout quality degradation
HDCP (High-bandwidth Digital Content Protection)
SC-DS1 fully supports HDCP
Currently every digital visual product sends high resolution signal with HDCP signal. You
cannot see the picture if the product is not compliant to HDCP.
Compliance to HDMI Ver 1.4
SC-DS1 fully supports the latest HDMI Ver 1.4

PureLink by Dtrovision
4
Product Specification
ITEM DESCRIPTION
Model Name SC-DS1
Input Signal HDMI/DVI
Output Signal HD-SDI/SDI
Resolution 480p~1080i/p
Receptacle
DC Power Jack
BNC Female
HDMI 19 Pin Female
Interface
SMPTE
HDMI Ver 1.4
DDWG DVI 1.0
Power Consumption DC 5V Power Adapter(Included)
Max 5 W
Dimension 4.0 x 3.07 x 1.18 in. |102x78x30 mm
Weight 0.66 Lbs | 0.3 Kg

PureLink by Dtrovision
5
Environmental and Reliability Specifications
Recommended environmental conditions for the operation are temperature range of 10°C~40°C,
non-condensing humidity levels of 10%-80%, and altitude ceiling of 3,000 meters (9,840 feet).
Environmental limits for transportation are temperature range of -25°C~60°C, non-condensing
humidity levels of 5%~95%, and altitude ceiling of 15,000 meters (49,200feet)
Environmental limits for storage are established at temperature range of -20°C~45°C, non-
condensing humidity levels of 5%~95%, and altitude ceiling of 3,000 meters (9,840 feet)
The SC-DS1 Converters expected to function for more than 50,000 hours of use at a 90%
confidence level. The device is tested according to the identical standards for testing LCD
monitors.
Video Connection
Step 1: Ensure the digital video source and display is turned off
Step 2: Connect the HD-SDI , HDMI cable
Step 3: Connect power adapter jack
Step 5: Turn on the display
Step 6: Turn on the source

PureLink by Dtrovision
6
Mechanical Specification
Dimension: 4.0 x 3.07 x 1.18 in. | 102 x 78 x 30 mm
Front part
DC 5V: DC 5V power input port
HD-SDI Out: HD-SDI Output port(Loop Back)
EDID S/W : Switch for loading EDID
S/P : Service port for firmware upgrade.
Rear part
POWER LED: display the status of power
STATUS LED: display the status of signal input
HDMII In: HDMI(DVI) input port
SD/HD/3G LED: display the status of Input Signal operation

PureLink by Dtrovision
7
Technical Specification
Input - Data Format HDMI( YCbCr(4:2:2))
Input Resolution SC-DS1
Input Signal
Up to Full HD(1920*1080p)
1080p @ (60/59.94)
1080i @ (60/59.94/50)
1080p @ (25/24/23.976)
720p @ (60/59.94/50)
480i @ (59.94)
Input signal standard HDMI
Input connector type HDMI Female 19P
Output - Data Format SDI format YCbCr(4:2:2)
Output Resolution
Up to Full HD(1920*1080p)
SMPTE-425M -1080p @(60/59.94)
SMPTE-274M -1080i@ (60/59.94/50)
SMPTE-260M -1080p @(25/24/23.976)
SMPTE-296M -720p@(60/59.94/50)
SMPTE-125M -480i @(59.94)
Output connector type BNC Female
Power consumption 5 Watts Max.
Power supply DC 5V, 2A

PureLink by Dtrovision
8
Manufacturer’s Warranty (2-Year)
PureLink warrants this SC-DS1 DVI or HDMI to 3G/HD-SDI Format Converter to be free from
defects in workmanship and materials, under normal use and service, for a period of two (2)
year from the date of purchase from PureLink or its authorized resellers.
If the product does not operate as warranted during the applicable warranty period, PureLink
shall, at its option and expense, execute one of the following as necessary:
1. Repair the defective product or part
2. Deliver to customer and equivalent product or part to replace the defective item
3. Refund to customer the purchase price paid for the defective product
All products that are replaced become the property of PureLink. Replacement products may be
new or reconditioned. Repaired or replacement products or parts come with a 90-day warranty
or the remainder of the warranty period. PureLink shall not be responsible for any software,
firmware, information, or memory data loss of contained in, stored on, or integrated with any
products returned to PureLink for repair under warranty.
Customer Service
Any customer service inquiries can be submitted electronically through the Q&A form on our
website ( www.purelinkav.com ).
For immediate assistance please contact us at [phone] to reach our customer care or
tech support team.

PureLink by Dtrovision
9
Troubleshooting
The SC-DS1 Converter is designed for years of trouble free, please refer to the troubleshooting
chart below if experiencing trouble with the device.
Problem Solution
No picture(or signal)
1. If you are using copper based HDMI cable, overall length of
the cables (length of the cable from video source to switch and
length of the cable from switch to display) should not exceed
20ft. Exceeding 20ft. with copper based cables will result in no
or poor picture quality. To extend beyond 20ft, please use fiber
optical HDMI/DVI extension cables.
2. Use high quality HDMI cables.
3. If you are using computers, try other refresh rate settings.
Most HDTV’s have refresh rate of 48Hz and computer’s video
cards are usually set at higher refresh rate.
Try lower refresh rates.
4. Make sure all HDMI connectors are tightly secured to all
HDMI ports. Loose plugging on the HDMI connectors will result
in no or poor picture.
5. Turn off all equipments (video source, switch and HDTV) and
restart all equipments.
Converter not Operate
Make sure the 5V power is plugged on the
back of the unit.
Check to see if the power LED light is on.
Incorrectly sized
picture /
resolution or No
Reset the product by power off.
