USER MANUAL
PLCMDVR 8
PLCMDVR 8
Backup Camera Parking Assist System
Dual Cameras and Monitor with Image & Video Recording

A B C D E F
HHH
IJ
K
L
G GG
1

1. Turn on DVR
Start car engine to tun on DVR power
2. Turn off DVR
Shut off car engine to turn off DVR power.
Note: Short prsee buon, DVR will turn to sleep mode only.
Main Menu
Main Menu
OSD
As above picture showed, green color icon is the icon selected.
Buons
UP: Cursor le
DN: Cursor right
OK: Enter/execute the menu selected
MENU: No funcon.
DVR Power ON/OFF
Driving record funcon
Driving record image SOS image
: Short press“ ” to enter sleep mode.
2

2. Funcon descripon
Stop recording: When there is no SD card or SD card does not insert correctly, it will stop
recording.
Normal recording: In loop mode, whenever the recording me reaches user-set loop recording
me, a new file will be saved. When SD card capacity is full, current recorded normal video file
will cover the first saved one.
SOS recording: Once G-sensor detected value exceeds a given threshold value, it will turn to
SOS recording and current video will be saved as SOS file. In loop recording, SOS file is saved as
three video files(previous video, current video and next video when entering SOS state), which
will not be overwrien. When SOS recording finished, it will return to normal recording.
Auto power off aer car stopped: When the car is stopping and DVR under normal recording
mode, G-sensor will detect and if G-sensor detected value not exceed threshold value(This
value is not same as event trigger value and cannot be set by user) within 5 minutes, the unit
will power off automacally.
Sound recording on
Sound recording off
System beep on
System beep off
1. Icons
3. Buons
: Short press “ ” to enter sleep mode.
OK: Enter/Exit SOS recording
MENU: Exit recording and back to main menu
Motion detection image
Moon Detecon
Open motion detection function when car is stopping. When recording image changes,
it will turn to normal recording; when image is static again, it will continue recording and
be back to motion detection state once it reaches motion detection recording time in
setting menu.
3

1. Icons
10S means when recording image changes and stac again, it will connue recording
10seconds and then stop.
2. Buon Funcon
: Short press“ ” to enter sleep mode.
UP: No funcon
DN: No funcon
OK: No funcon
MENU: Exit recording and back to main menu
Camera image
14MP 12MP (4000 x 3000)
8MP (3264 x 2448) 5MP (2560 x 1920)
3MP (2048 x 1536) 2MP (1920 x 1080)
1.2MP (1280 x 960) VGA (640 x 480)
Cemara Funcon
Buon funcon
UP: Zoom in
DN: Zoom out
OK: Shoot a photo and save a picture of JPG format to SD card.
M: Exit picture size seng interface or camera funcon.
: Short press“ ” to enter sleep mode.
File Browser
1 .The number shows the quanty of documents contained in the four project folders 'REC
Files', 'SOS Files', 'MD' and 'Photos Files'.
2 .Shows memory usage of current SD card.
12
In this mode you can shoot photos of the following sizes:
4

1. Delete files
Select the files that you want to delete, long press 'UP' buon, then click 'OK', the files selected
in project folder will be deleted.
Note: The deleted files in the four folders can not be recovered.
2. Buon funcon
UP(Short press): Cursor le
UP(Long press): Delete file message.
DN: Cursor right
OK: Enter the project folder selected
MENU: Exit File Browser and back to main menu.
: Short press“ ” to enter sleep mode.
REC Files
Image File Playback
Select the image file that you want to replay, then click 'OK'.
When the selected file play completes, it will connue to play subsequent files.
Delete Image Files
5

Buons
UP: Select previous file
DN: Select next file
OK: Pause/Resume play
MENU: Exit play
SOS Files
The operaon and buon funcon is same as 'REC Files'.
Moon Detecon
The operaon and buon funcon is same as 'REC Files'
Select the image files that you want to delete, long press 'UP' buon, then click 'OK', the image
files selected will be deleted.
Note: Deleted image files can not be recovered.
: Short press“ ” to enter sleep mode.
Photos Files
1. Delete photos
Select the photo file that you want to delete, long press 'UP' buon, then click 'OK', the file
selected will be deleted.
Note: Deleted files can not be recovered.
2. Buon funcon
UP(Short press): Select the previous file
UP(Long press): Delete file message.
DN: Select next file
OK: Open selected file.
MENU: Exit and return to previous menu.
: Short press“ ” to enter sleep mode.
6

Recording Mode
1. Video Quality
1296SHD: 2304x1296；
1080FHD: 1920x1080；
720HD: 1280x720；
2. Buon funcon
: Short press to enter sleep mode.
UP: Select previous item
DN: Select next item
OK: Enter seng or confirm the change of sengs.
MENU: Exit or discard the change of seng.
Note: If no special instrucons, the buon funcon operaon for all sengs are same as above.
Sengs
Photo Size
Photo size can be set as 14MP, 12MP, 8MP, 5MP, 3MP, 2MP, 1.2MP, VGA
Loop Recording
Loop recording me can be set to 1 minute/ 2 minutes/ 3 minutes for each file. Default seng is 1
minute.
7

ON: Record video with sound(default seng)
OFF: Record video without sound.
Sound Record
Set MD sensivity as HIGH/MIDDLE/LOW.
Off/High/Medium/Low sensivity for different environment. Default seng is MIDDLE
MD Sensivity
G-Sensor
ON: Turn on buon sound.
OFF: Turn off buon sound.
Buon Sound
8

Volume seng on Mute or 5%~100%.
Volume Seng
Backlight Time
ON: Turn on backlight all the me(Default seng).
30s: Turn off backlight aer no operaon for 30s.
1 min: Turn off backlight aer no operaon for 1 minute.
5 min: Turn off backlight aer no operaon for 5 minutes
Light Frequency
50Hz: Remove light frequency interference of 50Hz
60Hz: Remove light frequency interference of 60Hz
Note: This funcon is to remove the interference of indoor fluorescent light 50Hz or 60Hz to
system CMOS image.
9

Buon funcon
UP: +
DN: -
OK: To confirm the change of date and return to previous menu.
MENU: Switch to next adjustment.
Set Clock
: Short press“ ” to enter sleep mode.
Language
The system supports English, Simplified Chinese, Tradional Chinese, Korean, Russian, Deutsch,
French and Japanese.
Reset Setup
Inialize all sengs to factory default sengs.
Buon funcon
UP: Move yellow cursor
DN: Move yellow cursor
OK: Click 'OK' to restore default sengs; Click 'Cancel' to cancel and return to previous menu.
MENU: Cancel Reset Setup and return to previous menu.
: Short press“ ” to enter sleep mode.
10

Buon funcon
UP: Move yellow cursor
DN: Move yellow cursor
OK: Click 'OK' to format SD Card; Click 'Cancel' to cancel and return to previous menu.
MENU: Cancel Format seng and return to previous menu.
Format
: Short press“ ” to enter sleep mode.
Precauons
Before formang, pls make sure there is no important data in SD card.
It is suggested to format the SD card once a week, in order to free up space and refresh SD card
fragmentaon.
Aer mulple read and write operaon, system will cause huge disc fragmentaon, which may
lead to recorded video not playing smoothly. In this case just simply format the SD card, then it
will work properly.
Back up all important data to your PC.
11

System Message
No SD Card
In video recording or camera mode, if the unit does not
detect SD card, this picture and voice prompt will appear on
screen. Insert SD card, the prompt will disappear and it can
start recording or shoong photos.
SD Card has no storage space
In video recording or camera mode, if SD card has no storage
space, this picture and voice prompt will appear on screen,
and recording will stop. Clean up SD card. It is suggested to
use a special SD card for recording.
Preparing SD Card
Insert SD card, this picture prompt will appear on screen.
This prompt will disappear automacally aer SD card
ready. The me for preparing SD card is different due to
different SD card quality. When preparing SD card, PLS DO
NOT pull out it.
Auto power off countdown me
Aer seng auto power off me, when there is no external
power supply, the system will enter the countdown and be
powered off when the countdown ends. If external power
supply restored during countdown, the auto power off
countdown will be canceled.
SD Card error
When SD card error message appears, try to remove it and
insert correctly again. If error message sll appears aer a
few mes, pls check on PC whether the SD card is good or
bad
Video file corrupon
If pull out SD card when recording video, it can cause file
corrupon and playback failure.
SD card space is insufficient
Pls check SD card and do read and write test.
Auto shutdown aer car stopped
When the car is stopping and DVR under normal recording
mode, G-sensor will detect and if detected value not exceed
threshold value(This value is not same as event trigger value
and cannot be set by user) within 5 minutes, the system will
emit a beep for 9 mes, then unit will power off
automacally.
Related operaons being processed, please wait.
12

Pyle ‘PLCM’
Backup Camera Systems
Angle Adjustable Camera Lens
Located on the camera housing are 2 screws which
lock the camera lens angle in position.
The screws may be loosened to allow camera lens
angle adjustment
Loosen the screws, adjust the camera lens into the
desired angle. then tighten the screws securely.
Be sure as to not overtighten the screws.
13

14
Back up camera
Power: DC 12V
ACC
Reverse Trigger
Video & Power
Wiring Harness
PLCMDVR8
GND
