Pyle PYLE View Series PLVSR7IR User manual

7" TFT LCD SUN VISOR MONITOR
PLVSR7IR

1
* MONITOR
1. SPECIFICATION---------------------------------------------------2
2. FUNCTION KEYS AT FRONT PANEL---------------------------2
3. FUNCTION DESCRIPTIONS-------------------------------------3
4. CONNECTION -----------------------------------------------------3
5. REMOTE CONTROL ----------------------------------------------4
6. DIMENSION ------------------------------------------------------ -4
7. SUN VISOR KIT----------------------------------------------------4

2
MONITOR
1. SPECIFICATION
* VIDEO
- SCREEN SIZE ----------------------------------- 7" DIAGONAL
- RESOLUTION ---------------------------------- 1440(H) x 234(V)
- COLOR CONFIGURATION ------------------- RGB Stripe
- DOT PITCH -------------------------------------- 0.107(H) x 0.372(V)
- VIEWING ANGLE ------------------------------ Top: 50 deg. / Bottom: 20 deg.
Left: 45 deg. / Right: 45 deg.
* ELECTRICAL
- COLOR SYSTEM ------------------------------- NTSC/PALAuto Switch
- VIDEO INPUT ---------------------------------- 1 Vp-p, 75ohms
- POWER COMSUMPTION -------------------- DC12V 1A MAX. 6VA
- AUDIO OUTPUT POWER--------------------- 0.5W(MAX)
2. FUNCTION KEYS AT FRONT PANEL:

3. FUNCTION DESCRIPTIONS:
* Power : Press the "POWER" button from the main unit to
turn on the monitor.
* Menu : Press the MENU from the main unit to pop up the OSD
functions by turns.
* Mode : Vedio source swing
* UP/DOWN : Using menu button together can adjust the other function
OSD Menu:
Main Menu
Press the "MENU" from the main unit to pop up the functions.
Each mode will process by turns, you may use
UP/DOWN together to increase or decrease parameters as well
COL
BRT
TINT
-
-
-
-
+
+
+
+
CON
3
4. CONNECTION:

5. REMOTE CONTROL
6. DIMENSION
7. SUN VISOR KIT
4
