Pyle Squatz Centrum III User manual

www.SQUATZ.com
2
Before use, please read this manual carefully to ensure correct operation.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
Features:
• Easy to Use and Easy to Store
• Foldable Cushions and Foldable Bench
• Space Saver Workout Station Machine
• Design to Train Abs, Thighs, and Glutes
• Help to Build Muscle, Strength, Balance, Durability, and Flexibility
• Made of Premium and Quality Material
• Made of Heavy-Duty Steel Main Frame
• Adjustable Foam Foot Holder
• Comfortable and Adjustable Rear Cushion for Feet and Legs
• Large Steel Non-Slip Footplate
• Adjustable Design Workout Station that Fits Dierent Body Shapes
What’s in the Box:
• Maine Frame
• Fore Foot
• Back Foot
• Support Board
• Pedal
• (2) Foam
• Support Board Adjustment Lever
• Foam Adjustment Lever
• (2) Pulley
• (2) Snap
Technical Specs:
• Construction Material: Steel Tube
• Weight Capacity: 440.9 Lbs.
• Item Weight: 29.7 Lbs.
• Product Dimensions (L x W x H): 42.5" x 21.6" x 22.4" -inches
• (2) Elastic Pull Pin
• (2) Ground Balance Adjustment Nut
• (4) Screw (10x70)
• (4) Nut
• (8) Gasket
• (8) Screw (8x10)
• (8) Gasket
• (2) Screw (8x40)
• (4) Gasket
• (2) Nut
THIS PRODUCT COMES WITH A COMPLETE DIGITAL TRAINING PROGRAM!
DOWNLOAD THE SQUATZ APP TO START TRAINING!

www.SQUATZ.com
3
PARTS IDENTIFICATION
1. Main Frame
2. Front foot
3. Back foot
4. Support board 5. Pedal 6. Foam
7. Support board adjustment lever 8. Foam adjustment lever 9. Pulley
10. Snap 11. Elastic pull pin 12. Ground balance adjustment nut
a. Screw (10x70) -4 / - 8 Gasket / -4 Nut
8. Seat adjustment rod
9. Fist plate adjustment rod

www.SQUATZ.com
4
ASSEMBLY INSTRUCTIONS
Step 1: Install the pedal 5on main frame 1，which is xed by (b) screw.
Then install 12 on the pedals 5.
15
12
1-1 1-2
12
12
1
2
3

www.SQUATZ.com
5
Step 2: Install Front foot 2and Back foot 3separetely on the main frame 1which
is xed by (a) screw. Then install pulley 9and snap 10 on the Front foot 2.
1
3
2
9
9
2
9
9
c
c
2-1 2-3
2-3 2-4
3
10
10

11
www.SQUATZ.com
6
Step 3: Load foam 6into foam rod 8. Then insert installed foam adjustment
lever into 1and turn elastic pull pin 11 into foam adjustment lever.
Step 4:
A: Assemble support board 4and support board adjustment lever 7 with (b) screw.
B: Insert installed support board adjustment lever into main frame 1and then
turn elastic pull pin 11 clockwise to secure support board adjustment lever.
6
8
11
11: Turn 3-4 rounds counter-
clockwise and pull the pin
out, which adjust support
board adjustment lever up
and down. Turn the pin
clockwise to lock and x.
b
74
