Pyle SQUATZ SQSUB-1 User manual

www.SQUATZ.com
PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
Features
•Sit-Up Bar for Floor and Resistance Bands
•Easily Installed on the Floor
•CanWithstand More than 661 lbs.
•Double Suction Cup, Strong Grip
•Cold Rolled Steel Body
•Abdominal Exercise Machine
•Allows to Exercise Without the Help of Others
•Increase the Foot Support Bar for More Comfortable Use
•Two 4.5-inch Bottom Suction Cups
•Thickened Sponge Provide Strong Stability and Soft Comfort
•Protect Feet from Injury
•Suitable for Men and Women
•Suitable For Dierent Body Types
•Contains Two Pull Ropes, Two Grippers, and a Door Clamp
What's in the Box:
•(1) Base Set
•(1) Top
Technical Specs:
•Construction Materials: Iron, PVC, EVA
•Weight Capacity: 1.5 lbs.
•Product Dimensions (L x W x H): 10.2" x 10.2" x 7.08" -in.
www.SQUATZ.com
Abs Master Sit-up Bar Installation
Parts:
1. T shape bar
2. Suction bottom
3. Foam x2
4. Bar
5. Stopper x2
Assembly Method
1. Align the T shape bar1 button and bottom 2 holes.
2. Press and hold the button on the side of T shape bar1, and push down to connect with bottom 2.
Check if the button and holes are locked.
3. Insert bar 4.
4. Attach the two foam 3at the bar4.
5. Assemble the bar 4 stopperat the end of the bar.
6. Pull-up theT shape bar1to check if secured and locked.
1
1
2
2
1
2
3
1
2
4
4
3
3
4
53
3
4
4
6
2
Questions? Comments?
We are here to help!
[email protected]

APPLICABLE FLOOR
Set up the Sit-up Bar in a spacious at and smooth ground (wood oor, ceramic tile, marble, terrazzo).
Do not install on uneven/slit oors/carpeted oors, because they cannot produce adsorption!
The bottom of the bottom suction cup is 15cm.
CONVENIENT INSTALLATION
1. Before use, wipe the oor with a damp cloth to remove dust, and then put the suction cup on a smooth
surface to ensure that there are no gaps at the bottom.
2. Put down the Sit-up Bar on the ground. Put some moisture in between the suction cup and the surface
that you're sticking it. Pull down the lock, and nally adjust the gear. Push button so you can adjust the
actual height of it just depending on where you need it to be. (as picture show)
3. Before working out, please conrm if the equipment is well sucked on the oor to prevent accidents.
Q and A
Q: Why the Suction Cup can’t suck on the ground?
A: Please conrm if the ground is at and smooth enough (works best on wood oor, ceramic tile, marble,
terrazzo). Before use, wipe the oor with a damp cloth to remove dust, and then put the suction cup on
a smooth surface to ensure that there are no gaps at the bottom. Put some moisture in between the
suction cup and the surface that you're sticking it.
Q: Why does the product smell?
A: After the product is molded at high temperature, it is normal for the product to have a little smell.
If the product is placed in a ventilated environment for two or three days, the smell will disappear
naturally, which will not aect the normal use
Q: Can children use it?
A: It can be used, but it should be used reasonably under the supervision of an adult, and pay attention to
safety.
Important Safety Precautions
Please keep this instruction manual in a safe place for future reference
1. Please allow your child to exercise reasonably under the supervision of an adult.
2. You can use yoga mat to make your trainning more comfortable.
3. Wrong use or excessive exercise will cause muscle damage.
It is recommended to do some test excise to your waist to avoid waist injury.
4. After loading the add weight contents, please ensure that the equipment has been rmly installed
before exercising.
5. In order to prolong the life of the product, the equipment should be avoided from being exposed to the
sun, humid and hot, wind and rain and other adverse environments. It is also necessary to avoid corrosive
chemicals such as oil stains, strong acids and alkalis on the product.
6. Please make sure to use the equipment in the way specied in the manual. Please check whether the
product is in good condition when using it, and do not use if the product is defective.
7. Exercise should be gradual and should not be over exercised.
It is recommended that the duration of each exercise should not exceed 1 hour.
8. This equipment is only suitable for exercising waist and abdomen, not for other purposes.
9. Before using the training equipment, please check whether all buttons that need to be fastened have
been locked and can be used only after ensuring that they are locked.
Only regular repair and maintenance of parts that are easy to be damaged, worn and broken can ensure
the safe use of the training equipment.
10. The training equipment is not suitable for use as medical equipment.
www.SQUATZ.com www.SQUATZ.com
1
2
2
1
Pull down the suction lever 2on both side of
the device. Put on your feet to both Support Bar.
Pull upT shape bar1part with normal power,
if the suction plate2on the oor doesn’t
move, it means its stable and ready to use.
