Pyle PLM3 User manual

Address: 1600 63rd.Street Brooklyn N.Y. 11204,USA
Tel: [phone]-PYLE
Fax: [phone]
URL: http://www.pyleaudio.com
E-mail: [e-mail]
PYLE AUDIO INC.
20 12-PYLE AU DIO-PLMS3 0- PLM3-A000 1
USER MANUAL
PYLE AUDIO INC.
http://www.pyleaudio.com
[e-mail]
LAVALIER MICROPHONES
PLMS30
PLM3
High quality back electret condenser capsule
Flat frequency response and superior EMI suppression
Uni-directional polar pattern
Easy to match clothes
Easy to fit foam windscreen
1. Convenient being hidden in clothes somewhere.
2. Aim the microphone toward the corner of the speakers mouth.
3. Connect the microphone to the appropriate wireless system.
4. Always use the supplied foam windscreen to control breath noise.
PYLE PLMS30/PLM3 lavalier microphone is an ideal choice for stage
performances as it sets you freefrom holding a microphone and lets you be
totally yourself on the stage.
With a small and light tie-clip you can enjoy the sound quality similar to the
one delivered by a standard condenser microphone,which makes it perfectly
suitable for a variety of applications
such as stage performances,dramas,speeches,etc.
Element........................................................................Back Electret Condenser
Polar Pattern...............................................................Uni-directional
Frequency Response....................................................50Hz- 16KHz
Sensitivity...................................................................-45dB± 3dB
Output Impedance.......................................................2000Ω ± 30%
Max.Input SPL.............................................................130dB
S/N Ratio.....................................................................>70dB
Power Supply................................................................1.5V-10V
Cable............................................................................Φ2*1.0M
Dimension....................................................................Φ12mm
Color............................................................................Black
Connector..............................................(PLMS30)SHURE type 4pin mini XLR
(PLM3)Standard 3.5mm plug+1/4'’Atapter
Accessories.................................................................Windscreen,Tie-Clip
Model...........................................................................PLMS30/PLM3
Specifications
Figure 1: Polar pattern
Figure 2: Frequency response
General
Features
General rules for use
Connectors
Connectors:
SHURE type 4pin mini XLR
Accessories
Accessories: windscreen, Tip-Clip
Standard 3.5mm plug
1/4'’Atapter
