Pyle PDWM13UH User manual
PDWM13UH
UHF P LL 32CH Wireless Receiver
4 1
www.PyleUSA.com www.PyleUSA.com
SPECIFICATIONS
Overall System
Oscillation Mode: PLL
Frequency Range: 520~544.8MHz
Frequency Stability: +/-10ppm
Channel Space: 800KHz
Frequency Response: 50Hz~20KHz at ±2dB
S/N: 96dB @1Khz, A-weighted
T.H.D: 0.03% @ 1Khz, Vmic=-30dBv
Operating Range: 50M
Operation Temperature: -68°F~122°F
Receiver
Sensitivity: -94dBm
Adjacent channel rejection: 55dB
Max audio output voltage: 0.6Vrms
Output impedance: 600Ω
Power Supply: 2x 1.5V AAA batteries or DC 5V
Current consumption: 100mA
Microphone
Mic Capsule: Dynamic
Antenna: Built-in housing
Transmitting Power: <10mW
Audio Sampling Rate: 48 K H z, 32-bit encryption transmission
Modulation Mode: P 1/4 DQPSK
Power Supply: 2x 1.5V A A batteries
Current consumption: 100mA
FEATURES
1. UHF PLL 32 channels handheld wireless microphone system.
Support several microphones work together at the same time.
2. UHF high band 520~544.8MHz. 50M operating range.
3. Wide frequency response dynamic capsule reproduces original
sound without feedback.
4. Microphone with LED display. Easy to set up and reset
microphone channels.
5. Receiver auto search channels of microphone and SYNC to
the microphone.
6. Portable receiver with 1/4" Interface. Compatible with PA
system, amplier, mixer that has a 1/4" jack.
7. Spare 1/4" input socket on receiver. You can connect another
wired MIC or wireless receiver for more persons can use
simultaneously.
8. Handheld microphone is powered by two AA batteries and
the receiver is powered by two AAA batteries. Receiver can also
be powered by 5V DC.
9. Perfect for karaoke, party, speech etc
PARTS DESCRIPTION
Receiver
1. 6.35 Audio Output
2. RF (power) Indicator
Red: Power On
Green: Ready
Bright Red: Low Battery
3. ON/OFF Switch
4. 5V DC Input
5. Antenna
6. 6.35 MIC Input
7. Battery Cover/Compartment
1
2
3
4
5
6
7
2 3
www.PyleUSA.com www.PyleUSA.com
Handheld Microphone
1. Grille (Capsule Inside)
2. Power Indicator
3. LED Display
4. ON-OFF Switch:
Press Shortly to Turn On;
Press and Hold to Turn O
5. Channel Select Switch: Press to Select Channels
6. Battery Cover/Compartment
OPERATION
1. Open battery cover of handheld microphone and install 2PCS
AA batteries into battery compartment with correct polarity.
Then close the battery cover.
2. Press power switch to turn on the microphone. Power indicator
will light green and LED display will be illuminated.
3. Open battery cover of receiver and install 2PCS AAA batteries
into battery compartment with correct polarity. Then close the
battery cover. Or connect receiver to external 5V DC power
supply.
4. Connect receiver 6.35mm audio output connector to MIC in
jack of your amplier, mixer or active speaker. Set your
amplier, mixer or active speaker to suitable level.
5. Slide ON/OFF switch of receiver to ON position. Receiver will
start searching transmitting signal from microphone
automatically. RF indicator will ash once and turns to light
green to indicate that receiver is synchronized with the
transmitter. Now you are ready to go!
6. If you want to use multi sets simultaneously, press select
button on microphone to set microphones in dierent
frequencies. Receivers will automatically SYNC to their
microphones.
7. During operation if battery icon in LED display of microphone
starts to ash or receiver power indicator lights bright red, it
indicates battery power is low. Please replace new battery.
8. After use please turn o both microphone and receiver to save
battery power. If you are not going to use the wireless
microphone system for a long period of time please take out
the batteries from the microphone and receiver to avoid
possible battery leakage which may damage the unit.
Remarks
Each microphone has a unique ID code. Only receiver which has
been paired with the microphone will work. In each set the
receiver has been pre-paired to the microphone already. Users do
not need to pair the receiver with the microphone. In case you
need to use the receiver with another microphone (for example,
replacement microphone), please pair the receiver with the
microphone before operation as below.
1. Turn o both microphone and receiver.
2. Press and hold both power and select button of microphone
until you see LED display starts to ash.
3. Turn on receiver. Receiver RF indicator will ash about 3 times
and turns to light green. Now receiver is paired to the
microphone.
4. Press select the button of the microphone to nish pairing.
1 2 35
