Pyle PMEM1 User manual

Element........................................................................Back Electret Condenser
Polar Pattern...............................................................Omni-directional
Frequency Response....................................................20Hz- 20KHz
Sensitivity...................................................................-45dB± 3dB
Output Impedance.......................................................2000Ω ± 30%
Max.Input SPL.............................................................130dB
S/N Ratio.....................................................................>70dB
Power Supply................................................................1.5V-10V
Cable............................................................................Φ1.5*1.2M
Dimension....................................................................Φ5mm
Color............................................................................Skin
Connector..............................................(PMEMS10)SHURE type 4pin mini XLR
(PMEM1)Standard 3.5mm plug+1/4'’Atapte
r
Accessories.................................................................Windscreen
Model...........................................................................PMEMS10/PMEM1
Specifications
Figure 1: Polar pattern
Figure 2: Frequency response
PYLE PMEMS10/PMEM1 mini ear-hanging microphone is ideally suited for
vocal sound and speech application which requires much freedom of movement.
The unique tiny size and super light weight provides a comfortable and optimum
fit for any occasion.
Such as dance and sports instructors, Great for video use ,the mini microphone
is practically invisible.
The microphone ensures a perfect blend of the microphone for discreet
appliance.
It is available in Skin and Black Color.
General
Features
High quality back electret condenser capsule
Flat frequency response and superior EMI suppression
Omni-directional polar pattern
Easy to wear headband
Easy fit foam windscreen
1. Place the headband around the side of the head.
2. Aim the microphone toward the corner of the speakers mouth.
3. Connect the microphone to the appropriate wireless headset.
4. Always use the supplied foam windscreen to control breath noise.
General rules for use
Connectors
Connectors:
SHURE type 4pin mini XLR
Accessories
Accessories: windscreen
Standard 3.5mm plug
1/4'’Atapter
Address: 1600 63rd.Street Brooklyn N.Y. 11204,USA
Tel: [phone]-PYLE
Fax: [phone]
URL: http://www.pyleaudio.com
E-mail: [email protected]
PYLE AUDIO INC.
2012-PYLEAUDIO-PMEMS10-PMEM1-A0001
USER MANUAL
PYLE AUDIO INC.
http://www.pyleaudio.com
[email protected]
MINI EAR-HANGING MICROPHONES
PMEMS10
PMEM1
