Pyle P2001BT User manual
www.PyleUSA.com
2
Safety Instructions
CAUTION: To reduce the risk of electric shock, DO NOT ATTEMPT TO OPEN
THE AMPLIFIER OR REMOVE THE COVER. There are no user serviceable parts
inside - please use a qualied technician for all servicing.
WARNING: To prevent electrical shock or re hazard ,this amplier should
not be exposed to rain or moisture. Do not place objects lled with liquid,
such as vases, on the amplier.
WHEN USING ELECTRICAL PRODUCTS, CAUTION SHOULD ALWAYS BE USED.
PLEASE READ AND KEEP THESE SAFETY INSTRUCTIONS.
Precaution
1. Power Source
The unit should be connected to a power supply AC-115V/60Hz,
AC-230V/50Hz.
2. Ventilation
The unit should be situated so that its location or position does not
interfere with its proper ventilation. Place the unit at least 10cm away
from the walls.
3. Water and Moisture
The unit should not be used near water-for example, near a swimming
pool in a wet basement, etc.
4. Electric Shock
If a metal object, such as hair pin or needle comes into contact inside this
unit, a dangerous electric shock may result. For families with children,
never permit children to put anything, especially metal, inside this unit.
Intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may
be strong enough to create a risk electric shock to a person.
Intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
www.PyleUSA.com
3
5. Enclosure Removal
Never remove the enclosure. If the internal parts are touched accidentally,
a serious electric shock might occur.
6. Abnormal Smell
If an abnormal smell or smoke is detected, immediately turn the power
OFF and pull out the power cord. Contact your dealer or nearest service
station.
FRONT PANEL
1. POWER SWITCH: Press to switch the power unit ON or OFF.
2. : This knob is used to select the preview station which has been kept
in system.
3. RPT button: Repeat music control
4. : This knob is used to select the next station which has been kept in
system.
5. EQ button control for Hall, Live, Jazz, Rock, Pop, Normal.
6. : play/pause song button on USB/SD card
7. AM/FM SELECTOR
8. Mode switch button for input choice like USB/SD/BT/FM
9. Source Input OPTI/COAX
10. FUNCTION DISPLAYED FLUORESCENT WINDOW
11. SUB. VOLUME CONTROL
12. LED DIMMER
13. MASTER VOLUME CONTROL: Adjusts the blue lights and blue rings.
Adjusts the volume level. Turn the knob clockwise to increase the volume.
14. ECHO CONTROL: Turn the knob to adjust the MIC echo level.
2
11
467 81018
1191
20 117 114 111 1
12
13
116 115 1211
22
23 24
1
25
3 5 9
www.PyleUSA.com
4
15. TREBLE: Adjusts the master treble
16. BASS: Adjusts the master bass
17. MIC VOLUME: Adjusts the volume level. Turn the knob clockwise to
increase the MIC volume .
18. USB/SD: Card input
19. MIC INPUT JACKS 1 & 2 KARAOKE MIC: Connect to these jacks.
20. HEADPHONE JACK: Headphone connect to this jack.
21. INPUT SELECTOR: Turn this button to choose the favorable input
22. USB CHARGE SELECTOR
23. BT ANTENNA
24. REMOTE CONTROL WINDOW
25. AUX 1 Input
BACK PANEL
1. TUNER ANT: Connect for AM and FM antennas.
2. AUDIO INPUT JACKS:
Connect the audio output jacks of CDNCD/DVD, AUX to these jacks.
3. SUB-WOOFER OUTPUT JACKS 1 & 2: Connect IPOD/MP3 to this jack.
4. LINE OUTPUT JACKS: Connect the line input jacks to these jacks.
5. A SPEAKER OUTPUT TERMINALS: Connect your speaker system to these
terminals.
6. B SPEAKER OUTPUT TERMINALS:
Connect your the other speaker system(s) to these terminals.
7. COOLING FAN
8. 115V/230V SWITCH: According to power voltage, push this button to the
station of the 115V or 230V.
9. POWER CORD: Connect to AC 115V/60Hz & 230V/50Hz outlet.
10. WIRELESS MIC ANTENNA
1
1
1
21
31
4
1
10 1
51
61
71
81
9
www.PyleUSA.com
5
STEPS FOR CONNECTING WITH WIRELESS BT DEVICE
A. Press MODE button under the LCD display screen and enter into Wireless BT
mode.
B. Search on the Wireless BT device and you can fnd the Wireless BT name
"PYLE PRO"
C. Select the "PYLE PRO" Wireless BT name and wait for the device to pair.
D. The unit will make a signal to confrm that the device has successfully paired
and the screen will display "BLUETOOTH CONNECTED"
E. Once being paired, you can play music from your BT device. You can also use
the control buttons on the unit to select the tracks from your BT device.
AM/FM
ANTENNA
www.PyleUSA.com
6
Remote Control
A. Remote control should be operated within 6 meters with a scope of 30°
in front of the receiver.
B. Make sure that there is no large obstacle between the remote control and
the machine.
C. Remote sensor should be far away from the light, high amounts of light
can aect its performance.
1. Standy By Button
2. Equalizer Button:
(HaII, Live, Jazz, Rock, Pop, NormaI)
3. Previous Song Button:
Short press for previous music;
Press and hold for fast backward
4. Source Input Volume -
5. MODE:
Menu Control Button
Press to select BT/USB/SD/AM/FM/
LINE IN etc. audio input
6. MUTE Button
7. Source Input Volume +
8. SCAN Button
9. Next Song Button:
Short press for next music;
Press and hold for fast forward
10. Play/Pause Button
11. Repeat Song Button:
Repeat one music or repeat all
12. Number Buttons for Song Selection
www.PyleUSA.com
7
How to replace the preset radio stations?
Use the remote control to set the radio stations.
NOTE: The preset stations can't be deleted, BUT CAN BE REPLACED.
Operations Steps
1. Press TUNER MODE on the remote control
2. Press AM/FM, and select FM
3. Press PRE/NEXT to select the stations you don't want to keep
4. Press TUNING again, choose the radio stations you want to keep
5. Press MEMORY to save the new stations.
In this way, you can replace the preset radio stations.
SAFETY INSTRUCTIONS
1. Make sure that all connections are properly connected and the main
volume is set to minimum level before turning ON the unit.
2. When more than one pair of speakers are used, (specially the main
speaker output) make sure that the speakers used are of the same wattage
and impedance, otherwise the unit maybe damaged under high power or
long term operation.
3. To avoid humming sounds and unwanted noise, make sure that all the
wires are properly inserted
4. For speaker cords, strip o the vinyl coating and twist the wire tip.
Push down the pink jack or loosen the screw terminal, before inserting the
wire tip, then fasten it and tighten the screw. Be careful not to let the wires
stick out ofthe terminal otherwise this may cause a short circuit when
wires of dierent terminal contact each other.
5. After the unit is turned ON, adjust the main volume to the desired level
same with the bass and treble volume, etc.
www.PyleUSA.com
8
P2001BT
Home Theater Amplier Receiver with Wireless BT
Multi-Channel Pro Audio Stereo Pre-Amplier with USB Charge & Digital Optical/
Coax, MP3/USB/SD Readers, FM/AM Radio, Rack Mount (2000 Watt)
Features:
• Home Theater Audio Receiver System
• High-Powered Hybrid Pre-Amplier
• Multi-Channel Source Audio Selection
• Built-in Bluetooth for Wireless Music Streaming
• Digital LCD Display with AM/FM Radio
• Dual USB Device Charge Ports
• Connect & Stream Audio from External Devices
• MP3 Audio File Playback Support
• USB Flash & SD Memory Card Readers
• Aux (3.5mm) Input Jack
• (2) 1/4’’ Microphone Inputs
• Headphone Jack, 1/4’’ -inch
• RCA (L/R) Audio Input/Output Jacks
• Dedicated Subwoofer Output
• Screw-Type Speaker Terminal Binding Posts
• Front Panel Button & Rotary Control Center
• LED Backlight Illumination with Dimmer Control
• Microphone & Volume Audio Conguration Settings
• Integrated Overload & Short Circuitry Protection
• Universal Rack Mount Design
• Built-in Cooling Fan
What’s in the Box:
• Hybrid Pre-Amplier
• Detachable Rack-Mount Brackets
• FM/AM Antenna/BT Antenna
• Remote Control
• Power Cable
www.PyleUSA.com
9
Wireless BT Connectivity:
• Built-in Receiver for Wireless Audio Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
(Smartphones, Tablets, Laptops, Computers, etc.)
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLE PRO’
• Wireless Range: 40’+ ft.
Technical Specs:
• Power Output: 2000 Watt MAX
• 600 Watt @ 2 Ohm
• 300 Watt @ 4 Ohm
• 200 Watt @ 8 Ohm
• Frequency Response: 40Hz-15kHz, +/-2dB
• S/N Ratio: >76dB
• T.H.D.: <1%
• Radio Station Memory Presets: 30
• Digital Media File Playback Support: MP3/WMA/WAV/FLAC/APE
• Maximum USB/SD Flash Memory Support: Up to 64 GB
• Battery Operated Remote: Requires (1) x ‘CR-2025’ Battery
• Power Cord Length: 4.5’ft.
• USB Power: (2) 5V/2A
• Power Supply: 115/230V, Switchable
• Unit Dimensions (L x W x H): 18.89’’ x 12.04’’ x 3.14’’ –inches
www.PyleUSA.com
10
P3001BT
Wireless BT Hybrid Amplier Receiver
Multi-Channel Pro Audio Stereo Pre-Amplier with USB Charge & Digital Optical/
Coax, MP3/USB/SD Readers, FM/AM Radio, Rack Mount (2000 Watt)
Features:
• Home Theater Audio Receiver System
• High-Powered Hybrid Pre-Amplier
• Built-in Bluetooth for Wireless Music Streaming
• Digital LCD Display with FM/AM Radio
• Connect & Stream Audio from External Devices
• MP3 Audio File Playback Support
• USB Flash & SD Memory Card Readers
• Dual USB Device Charge Ports
• Front Panel Button & Rotary Controls
• LED Backlight Illumination with Dimmer Control
• RCA (L/R) Audio Input/Output Jacks
• Dedicated RCA (L/R) Subwoofer Output Jacks
• Screw-Type Speaker Terminal Binding Posts
• Headphone Jack, 1/4’’ -inch
• Aux (3.5mm) Input Jack
• (2) 1/4’’ Microphone Inputs
• Microphone Volume/Tone/Echo Control
• Audio Source Conguration Settings
• Built-in Cooling Fan
• Universal Rack Mount Amplier Design
What’s in the Box:
• Hybrid Pre-Amplier
• Remote Control
• Rack-Mount Brackets
• Power Cable
• FM/AM Antenna/BT Antenna
www.PyleUSA.com
11
Wireless BT Connectivity:
• Built-in Receiver for Wireless Audio Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
(Smartphones, Tablets, Laptops, Computers, etc.)
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLE PRO’
• Wireless Range: 40’+ ft.
Technical Specs:
• Power Output: 3000 Watt MAX
• 850 Watt @ 2 Ohm
• 550 Watt @ 4 Ohm
• 300 Watt @ 8 Ohm
• Frequency Response: 40Hz-15kHz, +/-2dB
• S/N Ratio: >76dB
• T.H.D.: <1%
• Radio Station Memory Presets: 30
• Tuner: Quartz Synthesized Radio
• Digital Media File Playback Support: MP3, WMA, WAV, APE, FLAC
• USB Power: 5V/2A (x2)
• Power Cord Length: 4.9’ft.
• Power Supply: 115/230V, Switchable
• Unit Dimensions (L x W x H): 18.89’’ x 12.04’’ x 3.14’’ -inches
This product can expose you to a chemical or group of checmicals, which may include
“Lead (PB)” which is known in the state of California to cause cancer, birth defects, or
other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
