Pyle PWA25WIFIBT User manual

In-WallWi-FiWirelessAudioControl
Wireless BT Streaming Wall Plate Switch Receiver,
Aux (3.5mm) Input
PWA25WIFIBT

www.PyleUSA.com
2
Introduction
Pyle’s Wireless Audio Streaming Wall Plate Amplier Receiver is a quick
and easy way to get your music playing through a connected speaker
system. The simple wall plate design allows multiple sound streaming
options including WiFi Wireless Network Audio, Bluetooth Wireless Audio,
and Connected Audio via the unit’s front panel Aux (3.5mm) Input Jack.
Enjoy versatile streaming ability wired & wireless with the Pyle Wall Plate
WiFi & Bluetooth Audio Amplier System.
Compatibility:
This product occupies standard single gang device space and is compatible
with most deep sized electrical boxes or low voltage bracket systems. Minor
fitting adjustments may be necessary for mounting the wall plate amplifier
receiver in certain wall installation applications.
Power the Unit:
The unit will be powered via the included power supply cable.
Wireless Setup & Connection:
There are (2) dierent types of wireless connection audio streaming
methods, WiFi and Direct Connect. Please read the following method
information and understand the dierence between the connection types
prior to connecting your device.
Method 1 - Connecting via WiFi:
This method is used for streaming internet radio services, through the
Wall Plate Receiver, via your compatible device.
Method 2: Direct Connection (Streaming Music Saved on Your Device):
This method is used for streaming compatible audio les, through the Wall
Plate Receiver, that are saved directly on your device’s memory.

www.PyleUSA.com
3
Control & Function Layout
Features and Controls:
1. PWR: POWER LED
2. WIFI: WIFI Signal LED
3. BT: Bluetooth Signal LED
4. MASTER: MASTER VOLUME CONTROL WITH POWER ON/OFF
5. MP3/CHARGE: MP3(USB) Card Reader Port & Charge for Mobilephone
6. :WIFI/USB Button Swiches to Next Song
7. :WIFI/USB Button Switches to Play or Pause
8. :WIFI/USB Button Switch to Previous Song
9. Mode: Button Switch to WIFI/BT/MP3 Player
10. AUX IN: (3.5mm) Audio Input Jack on top right, can Connect & Instantly
Stream Audio From Your Favorite Devices.
11. Store: 6 Pre-Store Folders, you can pre-store 6 Music Folders as your
favorite ones, and can loop playback, or choose one of them by press
the button.
12. WPS: WIFI Protected Setup
13. DC12V IN
14. Speaker Output Terminal
+
DC12V IN
STORE
USB
ON/
OFF
VOLUME
BT WIFI PWR
AUX IN
MODE WPS
1
2
3
4
5
6
7
8
9
10
11
12
13
SPEAKER OUT
L+ L- R- R+
14
RearPanel

www.PyleUSA.com
4
Important Notes & Troubleshooting Tips
• Please ensure you carefully read and understand all system instructions
and functions to allow for optimum performance & safe operation.
• RESTORE DEFAULT SYSTEM SETTINGS: Press and hold down the WPS
button for ~15 seconds to restore the unit to factory settings (Any saved
wireless networks will be forgotten and you will be able to re-establish
and recongure new wireless connections).
• Ensure all speaker and power wires/cables are connected securely.
• Before establishing any type of wired or wireless connection, ensure the
unit is powered on.
• Blinking/ashing indicator lights indicate the receiver is ready for
connection -- with regard the designated connection method.
• Once an indicator light stops blinking and remains solid, a successful
connection has been established.
• The unit may fail to successfully establish a WiFi connection if the
surrounded area is populated with multiple neighboring WiFi networks.
If possible, deactivate neighboring WiFi networks or re-locate the WiFi
wall plate receiver to an area free of WiFi networks.
• The ‘MUZO Player’ App is available for download on iOS and Android
devices. Download and install the app before attempting to make any
type of wireless connection.
• When you have connected to the Wall Plate via WiFi Method 2:
Direct Connection (Streaming Music Saved on Your Device)’ - the internet
radio streaming services will be inaccessible. Since your device’s WiFi
connection has become dedicated to the WiFi wall plate, all mobile data
to your device will be deactivated while connected Wall Plate via WiFi
‘Method 2: Direct Connection’.

www.PyleUSA.com
5
Bluetooth Setup
The In-Wall Amplier has built-in Bluetooth receiver ability, allowing you
to wirelessly stream audio to your connected speaker system. Follow
these steps to get connected:
1. Power ON the system and ensure the unit is in‘Bluetooth Mode’. You can
enter Bluetooth Mode by pressing the ‘MODE’ button, until the Blutooth
Indicator Light begins to blink continuously -- indicating the unit is ready to
pair with your smart device. You may also hear the voice prompts,‘Power
ON’ and ‘Pairing’, while the unit is in Bluetooth Mode.
2. Then, from your compatible smart device, make sure Bluetooth ability is
turned ON and search for the Wireless Network named ‘BT-RY’ from the
pairing device list & connect.
3. Upon successful pairing, you will hear the voice prompt,‘Your device is
connected’, and the Bluetooth Indicator Light will stop blinking and shine
solid. (If your device fails to connect, reset the system to default settings by
holding in the rotary knob dial/button and retry pairing.
Connect More External Devices
Aux (3.5mm) Input Audio Playback:
Once the unit is powered on, any device connected to the wall plate via Aux
connection cable, will play automatically. As soon as the wall plate detects
audio transmission, via Aux input, it will play -- overriding any Bluetooth or
WiFi streaming audio.
*If you wish to playback audio using Bluetooth or WiFi Wireless options,
please disconnect any Aux input to the wall pate.

www.PyleUSA.com
6
The ‘Muzo Player’ App
• Conveniently Access Your Music Library
• 'Multi—Room Mode’Connects Multiple Devices & Rooms
• Compatible with Spotify, iHeartRadio,Tidal,TuneIn & More
• Available for iOS and Android
• Free to Download
Connect your smart device to the Muzo Player App to unlock wireless
music streaming ability. ln-App prompts and instructions will provide
a walk—through of the connection process.
Please refer to the ’lmportant Notes &Troubleshooting Tips’for help, or if
you run into difficulties connecting.
See the next few pages for the desired connection methods for Android
and Apple iOS.

www.PyleUSA.com
7
Instructions for PWA25WIFIBT WIFI SET-UP on Smartphones
1. Open the app “MUZO Player”.
2. Wait for the app to nish“Searching for MUZO Wireless HIFI System”,
and then click “Add device”.
3. The app will display two options: “Please select the category of
speakers you want to add ”and “ MUZO Cobblestone”, please select the
“MUZO Cobblestone” option.
4. You will then see the “SETUP” screen, at the bottom of the screen
select “Settings”.
5. Your phone's“Wi-Fi Settings”should open up, then select the
“raysound_8720”option and connect to it.
6. Once connected to “raysound_8720”go back to the“MUZO Player”
app.
7. The app should display “select network” screen, now select the home
Wi-Fi network you typically use, and input your network password,
then click “Continue”.
8. It will display “Connecting”for a minute.
9. Then it will display “Connected”, please click ”Next” to continue.
10. On the “Name Device” screen, you can change the name of the
PTAUWIFI46 as displayed on your home network or keep it the same.
11. Now you’ll see the “Connect phone back to router” screen, please
click the “Wi-Fi Settings”text which will open up your phone’s Wi-Fi
settings again, and now connect back to your normal home Wi-Fi.
12. After that, go back to the“MUZO Player” app and click “Continue to
MUZO app”, and the Wi-Fi setup is complete.

www.PyleUSA.com
8
PWA25WIFIBT
In-Wall Wi-Fi Wireless Audio Control
Wireless BT Streaming Wall Plate Switch Receiver, Aux (3.5mm) Input
Features:
• In-Wall, Wall Plate Audio/Music Control
• Wi-Fi Wireless Connectivity Receiver
• Search, Stream & Control Your Music via the Downloadable App
• Bluetooth Wireless Audio Streaming
• Stream Internet Radio Services
• Aux (3.5mm) Audio Input Jack
• Connect & Stream Audio from External Devices
• USB Flash Memory Reader for Media Playback
• USB Input Doubles as Device Charge Port
• Universal Standard Wall Plate Size
• Fits U.S. Electrical Gang Boxes
• Full Range Audio & Stereo Sound Transmission
• Rear Panel Screw-Type Speaker Terminals
• Includes DC Power Adaptor
• LED Connection Indicator Lights
• Perfect for the Home, Oce or Business
• Lab Tested, Safety Certied & Approved
The MUZO Player’ App:
• Conveniently Access Your Music Library
• ‘Multi-Room Mode’Connects Multiple Devices & Rooms
• Compatible with Spotify, iHeartRadio, Tidal, TuneIn & More
• Available for iOS and Android
• Free to Download

www.PyleUSA.com
9
Bluetooth Connectivity:
• Easy & Hassle-Free Wireless Connection
• Compatible with All of Today’s Latest Devices
(Smartphones, Tablets, Laptops, Computers, etc.)
• Bluetooth Version: 4.0
• Bluetooth Wireless Range: 30’+ ft.
Wi-Fi Connectivity:
• Connects to Your Wireless Home Network for Audio Streaming
• Extended Network Audio Transmission Range
• *Device Data may be Deactivated While WiFi Streaming
What’s in the Box:
• Audio Control Wall Plate
• Decorative Plate Frame Cover
• Wall Power Adapter
Technical Specs:
• Frequency Response: 40Hz-20kHz
• Input Sensitivity: 200mV/1V
• Power: 120/240V, 12V DC Adapter
