Pylontech Force-L2 User manual

19PIFP0301
Lithium-Ion Phosphate Battery
Force-L2 Product Manual
Information Version: 2.2
Pylon Technologies Co., Ltd.
No. 73, Lane 887, ZuChongzhi Road, Zhangjiang Hi-Tech Park
Pudong, Shanghai 201203, China Zip Code: 201203
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: http://www.pylontech.com.cn

19PIFP0301
This manual introduces Force-L2 from Pylontech. Force-L2 is a 48Vdc Lithium-Ion Phosphate
Battery storage system. Please read this manual before you install the battery and follow the
instruction carefully during the installation process. Any confusion, please contact Pylontech
immediately for advice and clarification.
CONTENT
1. SAFETY PRECAUTIONS .....................................................................................................................1
1.1 Before Connecting....................................................................................................................1
1.2 In Using.....................................................................................................................................2
2. INTRODUCTION ......................................................................................................................................3
2.1 features:....................................................................................................................................3
2.2 Specifications............................................................................................................................4
2.2.1 The parameter of system.......................................................................................................4
2.2.2 Battery Module (FL4874M)....................................................................................................6
2.2.3 Control Module FC0048M-100 (internal power supply) ........................................................7
Definition of RJ45 Port Pin ...........................................................................................................11
3. EMERGENCY SITUATIONS...............................................................................................................12

19PIFP0301
1/ 13
1. Safety Precautions
Reminding
1) It is very important and necessary to read the user manual carefully (in the accessories)
before installing or using battery. Failure to do so or to follow any of the instructions or
warnings in this document can result in electrical shock, serious injury, or death, or can
damage battery, potentially rendering it inoperable.
2) If the battery is stored for long time, it is required to charge them every six months, and
the SOC should be no less than 90%;
3) Battery needs to be recharged within 12 hours, after fully discharged;
4) Do not expose cable outside;
5) All the battery terminals must be disconnected for maintenance;
6) Please contact the supplier within 24 hours if there is something abnormal.
7) Do not use cleaning solvents to clean battery;
8) Do not expose battery to flammable or harsh chemicals or vapors;
9) Do not paint any part of battery, include any internal or external components;
10) Do not connect battery with PV solar wiring directly;
11) The warranty claims are excluded for direct or indirect damage due to items above.
12) Any foreign object is prohibited to insert into any part of battery.
Warning
1.1 Before Connecting
1) After unpacking, please check product and packing list first, if product is damaged or
lack of parts, please contact with the local retailer;
2) Before installation, be sure to cut off the grid power and make sure the battery is in the
turned-off mode;
3) Wiring must be correct, do not mistake the positive and negative cables, and ensure no
short circuit with the external device;
4) It is prohibited to connect the battery and AC power directly;
5) The embedded BMS in the battery is designed for 48VDC, please DO NOT connect
battery in series;
6) Battery system must be well grounded and the resistance must be less than 1Ω;
7) Please ensured the electrical parameters of battery system are compatible to related

19PIFP0301
2/ 13
equipment;
8) Keep the battery away from water and fire.
1.2 In Using
1) If the battery system needs to be moved or repaired, the power must be cut off and the
battery is completely shut down;
2) It is prohibited to connect the battery with different type of battery.
3) It is prohibited to put the batteries working with faulty or incompatible inverter;
4) It is prohibited to disassemble the battery (QC tab removed or damaged);
5) In case of fire, only dry powder fire extinguisher can be used, liquid fire extinguishers are
prohibited;
Please do not open, repair or disassemble the battery except staffs from Pylontech or authorized
by Pylontech. We do not undertake any consequences or related responsibility which because
of violation of safety operation or violating of design, production and equipment safety
standards.

19PIFP0301
3/ 13
2. Introduction
Force-L2 lithium iron phosphate battery is one of new energy storage products developed and
produced by Pylontech, it can be used to support reliable power for various types of equipment
and systems. Force-L2 is especially suitable for application scene of high power, limited
installation space, restricted load-bearing and long cycle life.
Force-L2 has built-in BMS battery management system, which can manage and monitor cells
information including voltage, current and temperature. What’s more, BMS can balance cells
charging and discharging to extend cycle life.
Multiple batteries can connected in parallel to expand capacity and power in parallel for larger
capacity and longer power supporting duration requirements.
2.1 features:
➢The whole module is non-toxic, non-polluting and environmentally friendly;
➢Cathode material is made from LiFePO4 with safety performance and long cycle life;
➢Battery management system (BMS)has protection functions including over-discharge,
over-charge, over-current and high/low temperature;
➢The system can automatically manage charge and discharge state and balance current
and voltage of each cell;
➢Flexible configuration, multiple battery modules can be in parallel for expanding capacity
and power
➢Adopted self-cooling mode rapidly reduced system entire noise;
The module has less self-discharge, up to 6 months without charging it on shelf, no memory
effect, excellent performance of shallow charge and discharge;
➢Working temperature range is from -10℃to 50℃, (Charging 0~50℃; discharging -10~50℃)
with excellent discharge performance and cycle life;
➢Small size and light weight, stackable connection comfortable for installation and
maintenance;

19PIFP0301
4/ 13
2.2 Specifications
2.2.1 The parameter of system

19PIFP0301
5/ 13
Product Type
FORCE-L2
(48V148AH)
FORCE-L2
(48V222AH)
FORCE-L2
(48V296AH)
Cell Technology
Li-ion (LFP)
Battery System Capacity(kWh)
7.10
10.65
14.20
Battery System Voltage (Vdc)
48
Battery System Capacity (Ah)
148
222
296
Battery Controller Name
FC0048M-100
Battery Module Name
FL4874M
Battery Module Quantity(pcs)
2
3
4
Battery Module Capacity(kWh)
3.552
Battery Module Voltage (Vdc)
48
Battery Module Capacity (AH)
74
Battery Module Cell Series Quantity(pcs)
15
Battery System Charge Upper-Voltage (Vdc)
53.5
Battery System Charge Current (Standard)
30
45
60
Battery System Charge Current (Normal)
75
100
100
Battery System Charge Current (Max.@15S)
110
110
110
Battery System Discharge lower-Voltage
(Vdc)
44.5
Battery System Discharge Current (Standard)
30
45
60
Battery System Discharge Current (Normal)
75
100
100
Battery System Discharge Current (Max.@15S)
110
110
110
Efficiency (Max.)
96%
96%
96%
Depth of Discharge
90%
90%
90%
Dimension(W*D*H,mm)
450*296*822
450*296*1120
450*296*1415
Communication
RS485\CAN
Protection Class
IP55
IP55
IP55
Weight (kg)
83
119
155
Operation Life (Years)
15+
Operation Temperature (℃)
0~50℃
Storage Temperature (℃)
-20~60℃
Product Certificate
VDE2510-50, IEC62619, CE
Transfer Certificate
UN38.3
1) Battery Controller Dimensions(W*D*H)
2) Battery Module Dimensions (W*D*H)
3) Battery bottom base Dimensions(W*D*H)
450×296×190 mm
450×296×296mm
450×296×40 mm

19PIFP0301
6/ 13
2.2.2 Battery Module (FL4874M)
Product Type
FL4874M
Cell Technology
Li-ion (LFP)
Battery Module Capacity (kWh)
3.552
Battery Module Voltage (Vdc)
48
Battery Module Capacity (Ah)
74
Battery Module Serial Cell Quantity (pcs)
15
Battery Cell Voltage (Vdc)
3.2
Battery Cell Capacity (AH)
37
Dimension (W*D*H, mm)
450*296*296
Weight (kg)
35
Operation Life
15+Years
Operation Cycle Life
5,000
Operation Temperature
0~50℃
Storage Temperature
-20~60℃
Transportation Certificate
UN38.3

19PIFP0301
7/ 13
2.2.3 Control Module FC0048M-100
(internal power supply)
Control Module (FC0048M-100) Display Panel
LED Button
Short Press
Display the LED panel for 20sec.
Long Press
(more than
5sec)
When all LED flash blue ●, loss the button, then it is chosen
115200 baud rate of RS485.
When all LED flash orange ●, loss the button, then it is chosen
9600 baud rate of RS485.

19PIFP0301
8/ 13
Status
System Status: blue means working normally; Orange means protection or failure.
Blue, slow flashing.
Power Relay CLOSE. Alarm exist but can work continue.
Blue, lighting.
Power Relay CLOSE. Normal.
Orange, slow flashing.
Power Relay OPEN. Normal protection, can recover on
its own (Over Voltage, Under Voltage, etc.).
Orange, lighting.
Power Relay OPEN. Important protection, failure, lost
efficacy etc. Or failed to assign address.
Battery Module Status
Battery Module Status: blue means working normally; Orange means protection or failure
Blue, slow flashing.
Alarm exist but can work continue.
Blue, lighting.
Normal.
Blue, light once.
1~n LED lights on one by one, for address distribution.
Orange, slow flashing.
Module offline.
Orange, lighting.
Module protection, failure, etc.
System Capacity
Indicate the system SOC.
Blue, slow flashing.
Each LED indicate 25%SOC. Idle
Blue, flashing.
Each LED indicate 25%SOC. Discharge
Blue, lighting.
Each LED indicate 25%SOC. Charge
Remark: Slow flashing: 1.5s ON/0.5s OFF. Flashing 0.5s ON/0.5s OFF.
Fast flashing: 0.1s ON/0.1s OFF.

19PIFP0301
9/ 13
Control Module (FC0048M-100) Cable Panel
Power Switch
Switch A (1P). ON: the battery system’s controller able to turn on. OFF: whole system turns OFF.
Switch B (2P). Main breaker.
Caution: When the breaker is tripped off because of over current or short circuit, must wait
more than 30min then can turn on it again, otherwise may cause the breaker damage.
Start
Start function: press more than 5sec until the
buzzer rings, to turn on controller.
Black start function: when system turn on, and
relay is OFF, press more than 5sec, and relay will turn on for 3 min (depends on conditions).
Wi-Fi
Currently not available. Function reserved.
Power Terminal (+/-)

19PIFP0301
10 / 13
Connect power cables of battery system with Inverter.
Communication Terminal (RS485 / CAN / RS232 / Link Port 0 / Link Port 1)
RS485 Communication Terminal: (RJ45 port) follow RS485 protocol, for communication between
battery system and inverter.
CAN Communication Terminal: (RJ45 port) follow CAN protocol, for communication between
battery system and inverter.
CAN Communication Terminal: (RJ45 port) follow CAN protocol,
Link port0/1 for communication between battery piles.

19PIFP0301
11 / 13
RS232 Communication Terminal: (RJ45 port) follow RS232 protocol, for manufacturer or
professional engineer to debug or service.
Definition of RJ45 Port Pin
CAN
RS485
RS232
---
---
---
---
---
---
---
---
TX
CANH
---
---
CANL
---
---
GND
RX
---
RS485A
---
---
RS485B
---
Note: Other Pin must be NULL, if not may influence the communication of system.

19PIFP0301
12 / 13
1. Emergency Situations
1) Leaking Batteries
If the battery pack leaks electrolyte, avoid contact with the leaking liquid or gas. If one is
exposed to the leaked substance, immediately perform the actions described below.
Inhalation: Evacuate the contaminated area, and seek medical attention.
Contact with eyes: Rinse eyes with flowing water for 15 minutes, and seek medical attention.
Contact with skin: Wash the affected area thoroughly with soap and water, and seek medical
attention.
Ingestion: Induce vomiting, and seek medical attention.
2) Fire
NO WATER! Only dry powder fire extinguisher can be used; if possible, move the battery pack to
a safe area before it catches fire.
3) Wet Batteries
If the battery pack is wet or submerged in water, do not let people access it, and then contact
Pylontech or an authorized dealer for technical support.
4) Damaged Batteries
Damaged batteries are dangerous and must be handled with the utmost care. They are not fit
for use and may pose a danger to people or property. If the battery pack seems to be
damaged, pack it in its original container, and then return it to Pylontech or an authorized
dealer.
NOTE
Damaged batteries may leak electrolyte or produce flammable gas. If such damage occurs,
please contact Pylontech: [e-mail]

19PIFP0301
13 / 13
Pylon Technologies Co., Ltd.
No. 73, Lane 887, ZuChongzhi Road, Zhangjiang Hi-Tech Park
Pudong, Shanghai 201203, China
T [phone] | F+86-21-51317698
E [email protected]
W www.pylontech.com.cn
