Crestron TPMC-8X-BTP
Internal Battery Pack for TPMC-8X
Operations & Installation Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2008 Crestron Electronics, Inc.

Crestron TPMC-8X-BTP Internal Battery Pack for TPMC-8X
Contents
Internal Battery Pack for TPMC-8X: TPMC-8X-BTP 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Specifications ..............................................................................................................2
Physical Description....................................................................................................2
Industry Compliance ...................................................................................................3
Handling ...................................................................................................................... 3
Storage.........................................................................................................................3
Setup ..........................................................................................................................................4
Charging ...................................................................................................................... 4
Installation................................................................................................................... 4
Removal ......................................................................................................................6
More Information....................................................................................................................... 7
Reference Documents.................................................................................................. 7
Further Inquiries .......................................................................................................... 7
Future Updates ............................................................................................................ 7
Return and Warranty Policies ....................................................................................................8
Merchandise Returns / Repair Service ........................................................................ 8
CRESTRON Limited Warranty...................................................................................8
Operations & Installation Guide – DOC. 6556A Contents •i

Crestron TPMC-8X-BTP Internal Battery Pack for TPMC-8X
Internal Battery Pack for
TPMC-8X: TPMC-8X-BTP
Introduction
Features and Functions
• Lithium Ion rechargeable battery pack for the TPMC-8X WiFi
Touchpanel
• Can be charged when TPMC-8X is mounted in the
TPMC-8X-DS Docking Station/Charger (sold separately)
NOTE: For more information on the TPMC-8X touchpanel, refer to the
latest version of the TPMC-8X Isys i/O™ Touchpanel Operations Guide
(Doc. 6539), which is available from the Crestron website
(http://www.crestron.com/manuals).
NOTE: For more information on the TPMC-8X-DS, refer to the latest
version of the TPMC-8X-DS Desktop Docking Station/Charger guide
(Doc. 6541).
Operations & Installation Guide – DOC. 6556A Internal Battery Pack: TPMC-8X-BTP •1

Internal Battery Pack for TPMC-8X Crestron TPMC-8X-BTP
Specifications
Specifications for the TPMC-8X-BTP are listed in the following table.
TPMC-8X-BTP Specifications
SPECIFICATION DETAILS
Battery (6502269)
Output Voltage 7.4 Volts DC
Capacity 2200 mAh
Battery (6501482)
Output Voltage 7.2 Volts DC
Capacity 2000 mAh
Composition Lithium Ion (Li-Ion)
Charging time ~2 hrs. (~2.5 – 3 hrs. when in use)
Weight 3.1 oz (87.9 g)
Physical Description
The TPMC-8X-BTP has a multi-pin connector for attachment inside the
battery compartment of the TPMC-8X.
TPMC-8X-BTP Physical View
2 •Internal Battery Pack: TPMC-8X-BTP Operations & Installation Guide – DOC. 6556A

Crestron TPMC-8X-BTP Internal Battery Pack for TPMC-8X
Industry Compliance
As of the date of manufacture the TPMC-8X-BTP has been tested and
found to comply with specifications for CE marking and standards per
EMC and Radiocommunications Compliance Labelling.
Handling
NOTE: The TPMC-8X-BTP contains a Lithium Ion (Li-Ion) battery.
When the unit can no longer retain a charge, it must be recycled or
disposed of properly. Follow local ordinances and/or regulations for
disposal.
To prevent damage to multi-pin connector and wiring, use care when
handling the TPMC-8X-BTP.
Storage
The TPMC-8X-BTP can be stored in a temperate, dry place (removed
from the touchpanel and docking station) indefinitely without significant
irreversible degradation of its performance. The self-discharge rate is a
function of temperature and internal resistance. High temperature storage
reduces charge retention. Best results occur if the TPMC-8X-BTP is
stored at an optimal temperature of 32° to 104°F (0° to 40°C). After an
extended period of storage, initiate a few charge/discharge cycles to
restore full capacity.
Operations & Installation Guide – DOC. 6556A Internal Battery Pack: TPMC-8X-BTP •3

Internal Battery Pack for TPMC-8X Crestron TPMC-8X-BTP
Setup
Charging
NOTE: A Lithium Ion (Li-Ion) battery typically provides 300-500
charge/discharge cycles.
There are two ways to charge the TPMC-8X-BTP:
• Install the TPMC-8X-BTP in a TPMC-8X touchpanel and connect
the touchpanel to an AC source using its AC adapter or
• Install the TPMC-8X-BTP in a TPMC-8X touchpanel and mount
the touchpanel on an AC powered TPMC-8X-DS Docking
Station/Charger (sold separately).
NOTE: The battery pack may take up to three hours to charge in a
powered touchpanel if the panel is in use during charging.
NOTE: When the external battery pack (TPMC-8X-BTPE, sold
separately) is attached, both the internal and external battery packs charge
simultaneously.
Installation
Use the following procedure to install the TPMC-8X-BTP in a TPMC-8X
touchpanel:
1. Place the touchpanel screen-side down on a clean, soft surface.
2. Remove the two Phillips head screws that hold the internal battery
compartment cover on the rear of the touchpanel.
3. Place the TPMC-8X-BTP in the battery compartment oriented so
the multi-pin connector is in the upper left corner.
4. Carefully connect the multi-pin connector of the TPMC-8X-BTP
with the corresponding connector inside the battery compartment
(refer to illustration on the following page).
4 •Internal Battery Pack: TPMC-8X-BTP Operations & Installation Guide – DOC. 6556A

Crestron TPMC-8X-BTP Internal Battery Pack for TPMC-8X
TPMC-8X-BTP in Battery Compartment of TPMC-8X
NOTE: To prevent battery drain during shipment or for long-term
storage, the TPMC-8X has a battery switch inside the battery
compartment. To use the internal battery, move the switch to the
up (on) position. To conserve battery power when the unit will not
be used for extended periods, move the switch to the down (off)
position. (Refer to illustration on the following page.)
Operations & Installation Guide – DOC. 6556A Internal Battery Pack: TPMC-8X-BTP •5

Internal Battery Pack for TPMC-8X Crestron TPMC-8X-BTP
TPMC-8X Internal Battery Switch
5. Re-attach the battery compartment cover using the two supplied
Phillips head screws.
Removal
Use the following procedure to remove the TPMC-8X-BTP from a
TPMC-8X touchpanel:
1. Place the touchpanel screen-side down on a clean, soft surface.
2. Remove the two Phillips head screws that hold the internal battery
compartment cover on the rear of the touchpanel.
3. Using the flat end of a small slot head screwdriver, gently pry the
multi-pin connector off the corresponding connector in the battery
compartment of the TPMC-8X.
4. With the multi-pin connector detached from the TPMC-8X, lift the
TPMC-8X-BTP out of the battery compartment.
6 •Internal Battery Pack: TPMC-8X-BTP Operations & Installation Guide – DOC. 6556A
