Pyronix KX10DP-WE User manual

RINS1421-5
KX10DP-WE 10m Internal detector
White
3mmABS, 0.4mm HDPE in LensArea
868MHz, FMTransceiver Narrow Band
Fully Encrypted Rolling Code
300m Free Space
Low Noise Pyroelectric Sensor
High, Low
Advanced Automatic
10m
28 beams positive and 28 beams negative
0.3 - 3.0 m/s
85
3.0V CR123A Lithium
Greater than 2 years
Front + RearTamper
-20 C to 50 C
-10 C to 40 C
Wall and ceiling mounting brackets optional
EN55022 Class B
EN50130-4
Model:
Colour:
Casing:
Transmission Frequency:
Tranmission Method:
Transmission Range:
Detection Method:
Sensitivity:
Temperature Compensation:
Detection Range:
Detection Zones:
Detection Speed:
Detection Angle:
Battery:
2.5V +/- 5% at 25°C
Low Battery Threshold:
Battery Life:
2 - 2.4m
Nominal Mounting Height:
Tamper Switch:
Storage Temperature:
Certified Operating Temp:
Accessories:
Emissions:
Immunity:
-10 C to 50 C
Nominal Working Temp:
Pyronix Limited, Secure House, Braithwell Way,
Hellaby, Rotherham, S66 8QY. UK
Customer Support Line : [phone]
or telephone [phone]
E-mail: customer[email protected]
website: www.pyronix.com
WARRANTY
This product is sold subject to our standard warranty
conditions and is warranted against defects in
workmanship for a period of two years
In the interest of continuing improvement of quality,
customer care and design, Pyronix Ltd reserves the
right to amend specifications, without giving prior
notice.
(batteries
excluded)
This product is approved for use in the Residential,
Commercial and Light Industrial Environment.
.
Coverage Pattern
®
EN50131-2-2:2008
EN50131-5-3:2005+A1:2008
PD6662:2010
Security Grade 2
Environmental Class II
NOTE: Only the KX10DPHT-WE has
been certified by IMQ.
2
®
KX10DP-WE Specifications
®
KX10DP-WE
10m Wireless PIR Detector
The detector will tolerate animals
of up to 20kg
HORIZONTAL COVERAGE
2m 3m 4m 5m 6m 7m 8m 9m
9m
8m
7m
6m
5m
4m
3m
2m
1m
1m 10m
10m
2.4m VERTICAL COVERAGE
2m 3m 4m 5m 6m 7m 8m 9m
1m 10m
O
85
56 zones
6 planes

Please see the Enforcer 32-WE user, programming and quick set
up manuals for further information
1. The detector will tolerate animals of up to
20kg.
2. Avoid mounting the detector facing stairs.
3. Avoid mounting the detector in direct sunlight.
4. Avoid mounting the detector in direct view of
heaters/radiators.
5. Any windows in the area where the detector is
installed must be closed.
6. Mount the detector on a stable surface.
7. Do not partially or completely obscure the
detectors field of vision with large objects.
CASE LID
SCREW FITTING
NOTE: When mounting the
Part number: FPKXBRACKET
WallCeiling
detector, ensure that it is
not tilting backwards.
Installation Wall Mounting
The KX10DP-WE Printed Circuit Board
Learning the KX10DP-WE onto the Enforcer 32-WE Control Panel
Changing The Battery
Declaration
Optional Bracket Fitting Dimensions Avoiding False Alarms
69mm
(2.72”)
3mm
(0.12")
50mm
(2.2”)
117mm
(4.61”)
Kg = 105g (3.4 oz) without bracket
RINS1421-5
Header On
= HIGH)
Header Off
= LOW
SENSITIVITY
DIGITAL SIGNAL
PROCESSING SELECT
To prevent possible damage to components,
any static charge on your body needs to be
eliminated before touching the inside of the
unit. This can be accomplished by touching
some grounded/earthed metallic conductor
such as a radiator/pipework immediately
before replacing the batteries.
The batteries supplied have been chosen to
provide long service life whilst, for safety
reasons, having limited output current.
Replace only with approved batteries.
Tamper Spring
Sensitivity Settings
Piro Sensor
DO NOT TOUCH
Learn Button
Battery Header for Rear Tamper
+
-
When you are ready to learn the device to the
control panel receiving equipment, and when the
equipment is in the learn mode follow the
procedure below:
1. Make sure the battery is installed correctly
and the plastic wrapping removed.
2. Press and Hold the Learn button until the
3 LEDs start cycling through the different
colours, then release the Learn button.
3. The device is correctly learnt when the
Green LED flashes.
The three coloured LEDs give a visual
indication of the signal strength.
Green indicates good signal strength and is a
good location to install.
Red indicates poor signal strength and the
device should not be installed in that position.
If no LED illuminates then the device is
completely out of range.
The blue LED will illuminate when the device is
activated
RED BLUE GREEN
RED BLUE GREEN
RED BLUE GREEN
RED BLUE GREEN
RED BLUE GREEN
mralA
CR123A
LITHIUM
BATTERY
+-
REAR TAMPER
NVM RESET
CR123A
LITHIUM
BATTERY
+-
For electrical products sold
within the European
Community. At the end of the
electrical products life, it
should not be disposed of
with household waste. Please
recycle where facilities exist.
Check with your Local
Authority or retailer for
recycling advice in your
country.
When disposing of the
product, the battery must be
removed and disposed of
separately in accordance
with the local regulations
Header On
LED ON
LED OFF
Header Off
ALARM LED
Alarm LED ON/OFF
