Q-Waves Wireless USB Audio/Video Adapter Set User manual

Wireless USB Audio/Video Adapter Set
User Guide

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 2
© 2009 Q-Waves Ltd. All rights reserved. All rights, title and interest, copyrights, patents,
know-how, trade secrets and other intellectual property relating to this publication and to Q-
Waves Ltd products are proprietary products of Q-Waves Ltd. The information presented in
this publication does not form part of any quotation or contract, is believed to be accurate
and reliable, and may change. No part of this publication may be reproduced in any form
whatsoever without prior written approval by Q-Waves Ltd
The Wireless USB A/V Adapter set is protected by patents and pending patent applications.
Any and all other trademarks, product names and other intellectual property rights are the
sole property of their respective owners.
Q-Waves Ltd Proprietary Information
Customer Support:
Tel: [phone]
Fax: [phone]
Email:[e-mail]
Doc. version UG10055 R1.0

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 3
Table of Contents
1 What's in the Package ..................................................................................... 4
2 Positioning the A/V Adapter ........................................................................... 5
2.1 Positioning the PC Adapter...................................................................................... 6
3 Software Installation and First Connection ................................................... 7
3.1 Connect the PC Adapter to the PC ........................................................................ 11
3.2 Connect the A/V Adapter ....................................................................................... 11
3.2.1 Connecting Audio.............................................................................................................11
4 Wireless USB Manager User Interface......................................................... 13
4.1 Wireless USB Manager System Tray Icon ............................................................. 13
4.2 Accessing the Wireless USB Manager................................................................... 13
4.3 Blocking or Disassociating a Device ...................................................................... 16
4.4 Changing Device Names in the Wireless USB Manager ........................................ 17
4.5 Advanced Settings................................................................................................. 17
5 Using and Configuring the A/V Adapter ...................................................... 19
5.1 Using the A/V Adapter ........................................................................................... 19
5.1.1 Using Mirror Mode ...........................................................................................................19
5.1.2 Using Extend Mode..........................................................................................................20
5.1.3 Laptop Operation with the Lid Closed.............................................................................. 20
5.1.4 External Display Only.......................................................................................................20
5.2 Configuring the Display via the Display Icon Context Menu ................................... 21
5.2.1 Setting Mirror Mode .........................................................................................................22
5.2.2 Setting Extend Mode........................................................................................................23
5.3 Configuring the Display via Windows Display Properties ....................................... 24
5.3.1 Selecting the Correct Display Monitor .............................................................................24
5.3.2 Setting the Display to Extend or Mirror Mode ..................................................................24
5.3.3 Adjusting Screen Resolution............................................................................................ 25
5.3.4 Adjusting Color Level ....................................................................................................... 25
5.3.5 Setting the A/V Adapter as the Primary Display ..............................................................25
5.4 Optimizing Wireless Video Display......................................................................... 26
5.4.1 Optimizing Internet Video Viewing ................................................................................... 26
5.4.2 Setting Aero Desktop Theme in Vista..............................................................................27
5.4.3 Recommended Media Player Applications ...................................................................... 28
5.4.4 Recommended Minimum System Requirements ............................................................28
5.5 Setting Audio Output Device.................................................................................. 28
6 LED Indications.............................................................................................. 30
Appendix A: Troubleshooting Help ....................................................................... 31
Appendix B: Pairing Procedure ............................................................................. 35

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 4
1 What's in the Package
Getting Started Guide
Software CD
A/V Adapter
PC Adapter
Device Adapter
A/V Base
HDMI VGA
3.5mm Audio
Power
Power Supply Unit

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 5
2 Positioning the A/V Adapter
The Wireless USB A/V Adapter is designed for two possible mounting options:
Simple table placement – the Audio/Video Base (A/V Base) is placed on a flat horizontal
surface, and the Device Adapter is connected at 90 degrees to the base so that it is
vertical.
Vertical mounting –the A/V Base is fastened to a wall, a projector, or behind a display
screen, and the Device Adapter is connected so that it is flat with the mounting surface,
with the Device Adapter pointing upwards.
Note: For best performance, it is recommended to always position the Device Adapter
vertically so that it is pointing upwards.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 6
2.1 Positioning the PC Adapter
To achieve best performance it is recommended to position the PC Adapter in the upright
position.
Figure 1: PC in working mode - PC Adapter in upright position
When the laptop is not in use, the PC Adapter can be rotated 90 degrees for storage, as seen
in the following illustration:
Figure 2: Laptop inactive - PC adapter in horizontal position for storage.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 7
3 Software Installation and First Connection
Note:If your PC contains a previous Wireless USB Suite driver installation, please perform
a proper uninstall procedure using the Windows Control Panel.
1. Ensure that the PC Adapter is unplugged from the PC.
2. Insert the installation CD in the PC CDROM drive.
3. The installation CD Autoplay menu is displayed.
4. Select .Install Wireless USB Software.
The installer offers two options:
Option 1: Install Directly from CD - initiates the installation process from the CD.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 8
Option 2: Download latest software from t e WEB - provides a link to a web address
where you can download software updates. If you choose this option, follow the
instructions provided on the software download page.
5. If you select Option 1: Install Directly from CD, the install wizard begins installing the
Wireless USB software. The installation process may include more than one stage to
accommodate different drivers that are installed. Following the Wireless USB drivers, the
Display drivers and application are installed.
6. Choose your geographic region to comply with your local radio regulations. This setting
can be changed if needed once the software is installed.
7. Follow the onscreen instructions, and proceed by clicking Next> when prompted, or by
approving authorization requests to continue the installation.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 9
8. When the Wireless USB Driver installation has completed, the Display driver installation
begins.
Click I Accept to approve the end-user license agreement and continue installation.
9. When the installation procedure has successfully finished, you are automatically returned
to the opening screen of the Autoplay menu. You may be requested to reboot.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 10

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 11
3.1 Connect the PC Adapter to the PC
Connect the Wireless USB PC Adapter to a high speed PC USB port. The system will
automatically detect and install the drivers for the connected PC Adapter
[Vista] [XP]
System Tray icon turns red to indicate that the PC Adapter (Host) is ready to
connect to any paired device in range
[Vista] [XP]
3.2 Connect the A/V Adapter
1. Attach the A/V Adapter to the remote display device (TV/Projector/Monitor), and ensure
the PC (with PC Adapter attached) is within 3 meter distance from the A/V Adapter for
the initial connection. Ensure the two adapters have clear line-of-sight. Connect the
provided power supply to the A/V Base power receptacle.
Note: The PC Adapter and Device Adapter in this set are already paired and do not require
performing a pairing procedure. If you should need to perform pairing manually for
any reason (e.g. connecting to a new host PC Adapter, or adding a Device Adapter
that was not purchased in a set), please refer to Appendix B: Pairing Procedure
2. Wait for the System Tray icon to turn green , indicating that a wireless connection
with the A/V Adapter has been established. The Display icon is also displayed as
soon as a connection is established and the Display drivers are active.
Note:If you do not see the icon changing to green, or do not see the Display icon, please
see Appendix A: Troubleshooting Help for suggestions.
3.2.1 Connecting Audio
The following options can be used to connect an Audio Output Device to the A/V Adapter:

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 12
Using the HDMI connector. Connect the HDMI cable to the A/V Base. Both video and audio
are delivered on the same HDMI cable. Connect the other end of the cable to the appropriate
HDMI port on the TV/Projector/Monitor.
Using the dedicated 3.5mm port. Connect an audio cable with a 3.5mm (mini-stereo) plug to
the audio jack on the A/V Base. Connect the other end of the cable to the appropriate audio
input jack on the audio device.
Note: The audio output is activated automatically. If you need to set the audio output device
manually, see Setting Audio Output Device.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 13
4 Wireless USB Manager User Interface
The Wireless USB Manager allows you to monitor and control the available Wireless USB
devices and connections that are within range of the PC.
4.1 Wireless USB Manager System Tray Icon
The Wireless USB Manager icon is automatically displayed in the Windows System Tray
whenever Windows starts. The color and shape of the icon indicates the current activity state,
as described in the following table:
Icon Color Status
Connected (green icon)
A wireless connection is established with a Wireless USB Device Adapter.
Host Hardware Enabled (red icon)
Wireless USB PC Adapter is connected to the PC (PC Adapter is enabled), but no
wireless connection is detected.
Host Hardware Disconnected (gray icon)
Wireless USB PC Adapter is not connected.
Host Hardware Disabled (gray icon wit X)
Wireless USB PC Adapter is disabled.
Note: Under the Japan regional setting, this icon is displayed whenever the AC power
source is disconnected from the PC.
Wireless USB C annel is Busy (green icon wit exclamation)
Low channel quality detected, but at least one Wireless USB device is still connected.
To improve connection quality, see Appendix A: Troubleshooting Help for
suggestions.
Wireless USB C annel is not available (red icon wit exclamation)
No available channel detected. To improve connection quality, see Appendix A:
Troubleshooting Help for suggestions.
4.2 Accessing the Wireless USB Manager
To access the Wireless USB Manager:
Right click the Wireless USB Manager System Tray icon and select Wireless USB
Connections to display the Wireless USB Manager screen.
Figure 3: System Tray Icon - Context menu

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 14
Table 1: Context menu options
Menu Option Description
Wireless USB
Manager
Displays the main user interface, which displays a list of Wireless USB devices that
are available, and their connection status (Connected, Not Connected,
Blocked)
Help Opens the help/troubleshooting file (HTML format) in a browser
About Displays the About screen, containing version information for the drivers and software.
Exit Closes the Wireless USB Manager application
Figure 4: Wireless USB Manager – remote device connected

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 15
Table 2: Wireless USB Manager Options
Menu Option Description
Host ID Displays the currently connected PC Adapter ID number
Connection Quality: The following are the different states of the connection status icon which indicates the
connection quality:
Blocked –
Not connected –
Connected–
Medium-
Good –
Very Good-
Excellent –
Advanced Settings Displays the Advanced Settings screen, allows configuration of the PC Adapter RF
settings.
Close Closes the Wireless USB Manager screen, does NOT close the Wireless USB Manager
application.
About Displays the About screen containing basic information regarding the software version
and vendor details
(Help) Opens the help/troubleshooting file (HTML format) in a browser

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 16
4.3 Blocking or Disassociating a Device
The Wireless USB Manager screen allows you to remove devices or to temporarily disable
them from connecting to the Host.
To Block a device temporarily, and prevent it from connecting to the Host:
Right click the device name in the Connection list and select Block Device.
Figure 5: Wireless USB Manager Context Menu
To remove a device from the list of available devices completely:
Right click the device name in the Connection list and select Disassociate Device
Figure 6: Wireless USB Manager– remote device blocked
Note: The Disassociate Device option is only available for Device Adapters that are
purchased separately and not in a set.
For information about pairing an Adapter set, see Appendix B: Pairing Procedure.
Table 3: Context Menu Options
Menu Option Description
Block/UnBlock Device Allows you to temporarily disable a device from connecting with the Host.
Disassociate Device Removes the device from the list. To return the device to the list, Pairing must
be performed again.
Properties Displays the properties screen for this device.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 17
4.4 Changing Device Names in the Wireless USB Manager
The Wireless USB Manager screen allows you to modify the name of the device that appears
in the connections list.
To modify the device name:
1. Double-click the device name
2. Enter the text that you want.
3. Click anywhere outside of the device name area to finalize.
Figure 7: Editing Device Name in Wireless USB Manager
4.5 Advanced Settings
The Advanced Settings screen of the Wireless USB Manager allows viewing advanced
settings, and allows configuration of the Channel and Region selection in the Host.
To access the Advanced Settings screen:
In the Wireless USB Manager screen, click Advanced Settings
Figure 8: Advanced Settings Screen

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 18
Option Description
Region: Allows selecting the regulatory region: USA, Europe, Japan, Korea, China
Current Channel
(read only)
Displays the current PHY Channel
Channel Quality (read only) Displays Channel quality: Excellent, Very Good, Good, Low, Not Connected
Select Channel Allows selecting PHY Channels: 13*, 14, 15#
Select Rate (Mbps) This option is not active.
OK Applies configuration changes that were made
Close Closes the Advanced Settings screen
Notes: * This is the default value for USA region.
# This is the only available option for Europe, Japan, Korea and China regions.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 19
5 Using and Configuring the A/V Adapter
The following are suggested work modes for connecting a display screen to the A/V Adapter:
Mirror Mode
Extend Mode
Laptop with Lid Closed
External Display Only
Note: The display properties for the A/V Adapter can be configured in two ways: as
described in Sec. 5.2 Configuring the Display via the Display Icon Context Menu, or
as described in Sec. 5.3 Configuring the Display via Windows Display Properties.
When changing settings, or during first connection between the PC Adapter and A/V
Adapter, the PC display may flicker or turn on and off as the screen resolution is
automatically adjusted.
5.1 Using the A/V Adapter
Upon first time operation, the A/V Adapter is in Extend mode, this section (Sec. 0) describes
the different modes that can be set. In Sec. 5.2 and 5.3 you will find the procedures for
configuring these modes.
5.1.1 Using Mirror Mode
Mirror mode is used to display the identical content on the additional screen as is shown on
the main PC/Laptop screen. Mirror mode is generally used to display the PC contents on a
larger or higher definition display. See Figure 9: Mirror Mode - displaying PC desktop on a
larger display screen.
Figure 9: Mirror Mode - displaying PC desktop on a larger display screen
Note: Mirror mode is not recommended for playing HD video.

Wireless USB A/V Adapter Set User Guide
www.q-waves.com Page 20
5.1.2 Using Extend Mode
Use the Extend mode to display different content on each display screen. In Extend mode,
the display attached to the A/V Adapter becomes an extended part of the Windows desktop.
The extra desktop area is a great productivity aid, allowing you to view or work with more
applications or documents at the same time. You can also use this mode to extend your
desktop to fill multiple screens that are positioned next to each other for a larger continuous
work space.
PC screen External
(extended) screen
Figure 10: Illustration of extend mode
Note: Extend mode is recommended for playing HD video.
Figure 11: Extend Mode - using second display for an additional application or a movie
5.1.3 Laptop Operation with the Lid Closed
You can work conveniently with a laptop by setting its default action upon closing the lid to
"Do not ing" (to prevent the laptop from entering "sleep" or "hibernation" mode, Control
Panel > Power Options, "W en I close t e lid:" - "Do not ing"), and then set the A/V
Adapter screen as the primary display while disabling the main screen (see Sec. 5.3.5 Setting
the A/V Adapter as the Primary Display).
The laptop lid can then be closed, and the laptop can be used with the A/V Adapter screen
and an external keyboard and mouse attached to the laptop. This configuration can be used
together with either Mirror mode or Extend mode.
5.1.4 External Display Only
When you want to use the external display only, (see Sec. 5.3.5 Setting the A/V Adapter as
the Primary Display), you can close your main monitor and view movies on the external
display attached to the A/V Adapter.
