Qlight S80SOL User manual

S80SOL/ S100SOL/S125SOL
Thank you for purchasing Q.Light product. Please read this
manual carefully before installing this product for safe and long
use.
▪High brightness LED flashing product of solar cell type which
needs neither power supply nor wiring.
▪Apply a system which automatically detects the darkness of
environment.
▪Excellent in diffusing signal light by employing unique
direct-diffusion system.
▪Transparent water-proof cover is additionally installed on
solar cell in order to protect the solar cell perfectly from dust
, moisture and so on. It raise the effectness of battery charge
and extend the self-life.
▪Material : Lens-AS, Body-ABS
▪Flashes : 60-80/Min.
▪Protection Class : IP54
1) S80SOL
▪ General Specification
Model
Battery
Voltage
Battery
current
Operating
Time
Weight
Color
S80SOL
2.4V
0.700Ah
30H
0.27Kg
RED-R
AMBER-A
▪External View Drawing
S80SOL
2) S100SOL
▪ General Specification
Model
Battery
Voltage
Battery
current
Operating
Time
Weight
Color
S100SOL
2.4V
0.700Ah
40H
0.41Kg
RED-R
AMBER-A
▪External View Drawing
S100SOL
3) S125SOL
▪ General Specification
Model
Battery
Voltage
Battery
current
Operating
Time
Weight
Color
S125SOL
2.4V
0.700Ah
50H
0.51Kg
RED-R
AMBER-
A
▪External View Drawing
S125SOL
OPERATING MANUAL
Solar Cell LED Flashing Light

①SOLAR CELL COVER
②SOLAR CELL
③GLOBE
④BODY
Outdoor
▪This product is manufactured for outdoor use. Please install the
product where solar cell can receive sunshine well.
▪Mount at the place where exists low vibration, low impact, low
moisture and low dust as long as possible.
▪Refer to below information and drill necessary mounting holes on
profitable part of the product.
(Make sure PCD from external view drawing.)
▪Fix the product by using nuts(S80SOL,S100SOL : M4-3EA ,
S125SOL : M5-3EA) originally equipped on mounting bolt on
bottom of the product.
(S80SOL)
(S100SOL)
(S125SOL)
Product Structure
Wiring Instruction

▪If lens or body of the product is contaminated by chemicals such
as thinner, benzene, the product can be damaged, discolored
or deformed. Please be careful.
▪Do not give strong impact to the product. It can be a reason of
wire disconnection or short circuit.
▪Install the product where solar cell can receive sunshine well.
Situation
Main reason
Solution
Non- Lighting Partly
LED is partly damaged
Change LED
Feeble Lighting
Supplying Voltage
Lower Than Rated
Voltage
Making Sure the battery
Not Working
Battery badness
Change the battery
Solar Cell penal
badenss
Contact Q.Light or Their
Agent
Q-LIGHT CO., LTD.
http://www.qlightkr.com
E-mail : qlightk[email protected]
Overseas Marketing Team /Plant
Tel) 055-328-4082Fax)055-328-4083
178-1 Woogye-Ri, Sangdong-Myun, Kimhae-Si,
KyungNam, Korea
