QBASIC PLUS
MOTOR CONVERSION KIT
INSTALLATION INSTRUCTIONS
IMPORTANT
Read and understand all instructions before installing.
Step 1 Remove the End Caps.
End caps are
held on by magnets.
Step 2 Remove the Fascia.
Step 3 Remove the Fascia Clips.
Pull down gently
and rotate bottom of
Fascia towards you.
Step 4 Remove the Shade.
Fascia
Clip
2Rotate the bottom of
the clip toward you.
1Push the snap feature
at the bottom of the
Fascia Clip towards the
center of the shade.
Lift up and then out
the end of the shade
opposite the Chain.
NOTE: If your shade does not have a fascia, you may
skip Steps 1,2, 3, and in step 10, install the shade
without adding a fascia.

Pub #9000278r1 04/2018
For more information visit us at qmotionshades.com or call 877.849.6070
© 2018 QMotion. QMotion is a trademark. All rights reserved.
Step 5 Remove the Clutch and Clutch Adapter. Step 6 Insert the Motor
Step 7 Install the included Battery
Access Hole Cover as shown.
Remove the clear Battery Access Cover and discard.
Insert the Motor such that the batteries are accessible
through the Battery Change Port.
Attach bracket using three
screws just removed.
Unscrew the
three insert
screws
Step 8 Remove the Manual Shade Bracket Insert.
Step 9 Install the Motorized Shade Bracket Insert Step 10 Reinstall the Roller Shade, Fascia
Clips, Fascia, and End Caps in this order.
