QShred QS-Pro User manual

1.567.999.100 A – 11/2014
QS-Pro
OPERATING INSTRUCTIONS
PAPER SHREDDER
QS-Pro

2 QS-Pro 11/2014
QS-Pro
1 Proper use, warranty
Check the name plate on the back of the
machine to find out the cutting width and
mains voltage for your document shredder
and observe the applicable instructions in
the operating manual.
2 Safety instructions
Classification
Safety notice Explanation
WARNING Failure to observe
this warning can
lead to serious or
fatal injury.
Notice Failure to observe
this instruction can
cause damage.
Before using the machine for the
first time, read the operating man-
ual, and keep it for later use and to
pass on to any subsequent users. Observe
all safety instructions on to the machine.
WARNING
Dangerous for children and
others!
The machine may not be used by
persons (including children under
14 years of age) with limited physi-
cal, sensory or mental capabilities
or with a lack of experience and
knowledge, unless they are supervised by
a responsible person or are instructed by
them on the use of the machine. Children
must be supervised to ensure they do not
play with the machine. Do not leave the
document shredder switched on when it is
unattended.
WARNING
Risk of injury!
Do not reach into the paper feed
slot.
Risk of injury from being pulled
in!
Keep long hair, loose articles of
clothing, ties, scarves, jewellery,
etc. away from feed opening. Ma-
terial with the tendency to form
loops, e.g. tapes, strapping mate-
rial, etc. must not be shredded.
The shredder is designed for destroying
paper. Depending on the cutting type, it can
also handle small quantities of the following
materials:
Its sturdy drive mechanism is not damaged
by paper clips and staples.
The warranty period for the document
shredder is 2 years. There is a special war-
ranty for the solid steel cutting rollers in
the document shredder, which is provided
independently of the guarantee, and re-
mains valid for the entire service life of the
machine (Lifetime Warranty). This warranty
and guarantee exclude wear and damage
caused by improper handling or actions
taken by third parties.
Shred width (mm) 3.9x50 1.9x15
Credit cards, CDs USB sticks ●●
Floppy disks ●
DAT cassettes ●

11/2014 QS-Pro 3
QS-Pro
WARNING
Dangerous mains voltage!
Improper handling of the machine
can lead to an electric shock.
– Before you insert the power plug, make
sure that the voltage and frequency of
your power supply comply with the infor-
mation on the name plate.
– Make sure that the power plug is easily
accessible.
– Make sure that no water gets into the
shredder. Do not immerse the power ca-
ble or the power plug in water.
– Never touch the power plug with wet
hands.
– Never pull the plug out of the socket us-
ing the power cable. Always pull out the
plug directly.
– Only use the machine in a dry room in-
doors. Never operate the machine in
damp rooms or in the rain.
Check the machine and cable
regularly for damage. Switch the
shredder off if it is damaged or
not working correctly or before
relocating or cleaning it and dis-
connect it from the mains.
– Keep the machine, the plug and cable
away from open fire and hot surfaces.
The ventilation slots must not be blocked
or covered and there must be at least
5 cm space between the shredder and
any wall or furniture.
Service work may only be carried
out by The Warehouse.Com Ltd
Customer Service or by the ser-
vice technicians of our contrac-
tual partners.
See page 8 for our customer ser-
vice address.
Notice Danger from improper use
Only operate this machine in accordance
with the instructions outlined in “Proper
use”.
Risk of injury from slivers!
Splinter protection from the cross cut ma-
chines is only guaranteed if the safety ele-
ment is covering the paper feed opening.
Feed hard credit cards, CDs, discs or DAT
cassettes only into the insertion slot.

4 QS-Pro 11/2014
QS-Pro
1 Inspection door
2 Paper feed opening
Safety element / splinter protection
3 Safety instructions
4 Cover
5 Membrane keyboard
6 Mains switch
7 Name plate
8 Caution label
9 Bottom frame
10 Roller
11 Guide roller
12 Door
Membrane keyboard
Reversing pushbutton
Cutting system runs in reverse
direction.
Stop pushbutton
Cutting system stops.
Shredder remains in standby
function.
ON pushbutton
Shredder is switched on.
Cutting system runs in feed
direction.
Front door opened
red LED
Paper jam – electric motor
overloaded
red LED
Cut material bag full
red LED
Ready for operation
green LED
3 Machine components
11
10
12
1 4 5
6
9
Schnittbreite Baujahr
Spannung
Leistung
NennstromMasch.-Nr.
Modell
Made in Germany
Seriennummer
   
   
 
 
 
 
7
8


2 3
4 Scope of delivery
• Paper shredder, ready for connection, in
carton packing, carton on pallet, tied with
strapping tape
• 5 bags for shredded material
• Special cutting block oil
• Operating instructions
Accessories
• 5 Bags for shredded material,
order No.: 1.442.995.100
• Special cutting block oil 250 ml,
order No.: 1.235.997.403
See page 12 for our customer service
addresses.

11/2014 QS-Pro 5
Switching the paper shredder on
• Set mains switch at rear of paper
shredder to „I“.
Green LED lights.
Paper shredder is ready for ope-
ration (standby)
Feed paper
• Feed paper. See
„Technical data“ for
sheet capacity.
The shredding pro-
cess is started by a
photo–cell in the paper
feeding opening.
When the paper feed
opening is free again,
the cutting system au-
tomatically switches
off after approx. 3 sec.
and returns to standby.


The document shredder can also
be started by pressing the green
arrow button:
• Press briefly:
Cutting device starts.
Automatic stop approx. 3 seconds
after the last piece of paper was
drawn in, or manual stop when
the stop button is pressed.
• Hold down for longer than
2 seconds:
constant operation without light
barrier function.
The cutting device runs until it is
switched off with the stop button.
5 Commissioning
• Open the door of the document shredder.
• Take the frame (A) and a waste bag.
• Place the waste bag on the frame and
fold over the top approx. 20 cm.
A
• Slide the frame (with bar B facing the
front of the cupboard) again into the
guide rails.
B
• Close the door of the document shredder.
• Plug the machine into a properly
installed socket.
• Undo the wing screws securing the unit
during transportation.
6 Operation
WARNING
Before switching the machine on,
make sure that you observe all
safety instructions.

6 QS-Pro 11/2014
QS-Pro
Switching paper shredder off
• Set mains switch at rear of paper
shredder to „0“.


Destroying credit cards, CDs, discs or
DAT cassettes:
Cross cut machines:
Fold the safety element down, switch the
machine on to continuous operation and
feed the material into the insertion slot.
only for cutting type
3.9x50 mm
DAT cassettes
Paper jam
You have fed in too much paper.
Paper shredder jammed.
Red LED in the key pad flashes.
Paper shredder reverses auto-
matically.
Notice!
Do not press dashed arrow button and
green arrow button alternately forwards and
backwards. Cutting unit can be damaged.
• Pull paper out of the paper feed-
ing opening.
If material is not completely pushed
out, then
• Press dashed arrow button.
Paper is pushed out.
• Pull paper out.
• Separate paper stack
• Feed in paper successively.
Electric motor overheated
Red LED on membrane key-
board lights.
Paper shredder switches off au-
tomatically.
• Allow paper shredder to cool
down for approx. 15 to 20 min.
Front door is open
Red LED on membrane key-
board lights.
Paper shredder stops automati-
cally.
• Close front door.
Note If the door is opened when the
cutting device is running, the document
shredder must be started again using the
green button after the door of the document
shredder has been closed.
7 Troubleshooting
Destroying USB sticks
Insert USB sticks in the centre of the paper
feed.

11/2014 QS-Pro 7
QS-Pro
Bag for shredded material full
Red LED on membrane key-
board lights.
Paper shredder stops automati-
cally.
Notice Empty the cut material container,
immediately because if it is too full, malfunc-
tions can occur in the cutting system.
Note Reversing the cutting device
(“Reverse” button) is also possible even
when the shredded material container is full.
• Insert new bag.
Switch off the shredder and pull out the
mains plug. When cleaning only use a soft
cloth and a mild soap-water solution. How-
ever, no water must enter the equipment.
Oil the cutting unit when
cutting performance de-
creases or the device
becomes noisy, or every
time you empty the waste
container:
• Spray special cutting block oil
through paper feed opening
across the whole width of the cut-
ting system blades.
• Run cutting system forwards and
backwards several times without
feeding paper.
Paper dust and particles are
shaken off.
8 Cleaning and maintenance
For all other malfunctions, before calling
customer service please check
– if the motor was overloaded
Let the shredder cool down for approx.
15 – 20 mins. before using it again.
– if the light barrier is soiled with paper
dust.
Clean the light barrier in the paper feed
using a dry brush or cloth.

8 QS-Pro 11/2014
QS-Pro
9 Disposal / Recycling
Electrical and electronic old de-
vices contain a variety of valuable
materials, but also hazardous
substances which were required
for function and safety. Incorrect
disposal or handling can be dan-
gerous to your health and the environment.
Never dispose of old devices in the house-
hold waste. Observe the current applicable
regulations and use the collection points for
returning and recycling electric and elec-
tronic devices. Dispose of all the packaging
materials also in an environmentally-respon-
sible way.
10 Technical data
* The maximum number of sheets (DIN A4, 70 g/m² or 80 g/m²), fed lengthways, which can be cut in one cycle. The
performance data is determined when the motor is cold and the cutting device is freshly oiled. A weaker mains voltage
or a different mains frequency to the one specified could result in less sheet capacity and increased noise during op-
eration. The sheet capacity can vary depending on the structure and properties of the paper and on the way it enters.
Cutting type Cross cut
Shred size (mm) 3.9 x 50 1.9 x 15
Safety rating DIN 66399 P-3 / O-2 / T-3 / E-2 P-5 / O-4 / T-5 / E-4 / F-2
Cutting capacity * (sheets), DIN A4 70 g/m2
80 g/m2
38 - 40
33 - 35
26 - 28
20 - 22
Cutting speed 110 mm/s
Weight 82 kg
Noise level (Idle running / load) 60 dB(A) / 75 dB(A)
Loading width 400 mm
Voltage 230 V, 50 Hz
100 V, 50/60 Hz – 115 V, 60 Hz
Power for the maximum number of sheets 2 100 W
Ambient conditions in operation:
Temperature
Relative humidity
Height above sea-level (MSL)
-10 °C to +25 °C
max. 90 %, without condensation
max. 2,000 m
Dimensions W x D x H (mm) 595 x 470 x 990
Volume of shredded material bag 146 l

11/2014 QS-Pro 9
QS-Pro
EC Declaration of Conformity
The manufacturer HSM GmbH + Co. KG,Austraße 1 - 9, 88699 Frickingen / Germany hereby declares that the
design and construction of the supplied version of the machine QShred QS-Pro meet the fundamental health and
safety requirements of the following EC directives:
Low voltage directive 2006 / 95 / EEC
EMC directive 2004 / 108 / EC
Applied standards:
EN 953 EN 1037 EN 1088 EN ISO 12100
EN 13849-1 EN ISO 13857 EN 55014-1 EN 55014-2
EN 60204-1 EN 60950-1 EN 61000-3-2 EN 61000-3-3
EN 61000-6-1 EN 61000-6-2 EN 61000-6-3 EN 61000-6-4
EN 62061
Frickingen, 2.6.2014
ppa. Hubert Kötzinger - Chief Technical Officer (CTO)

10 QS-Pro 11/2014
QS-Pro

11/2014 QS-Pro 11
QS-Pro

The Warehouse.Com Ltd
2 Wood Street
Queen Square
Bath
BA1 2JQ
Tel: [phone]
Fax: [phone]
E: [email protected]
