INTRODUCTION:
LED S ARTLIGHT SINGLE COLOUR PAR CAN
The QTX SmartLIGHT family of LED Par cans have been designed for a variety of
applications, whether you’re a mobile DJ, a band/singer, a bar/nightclub, theater
company or production company then this range of PAR cans will cover most
requirements.
Please read this manual carefully to ensure you get the best out of these products.
This manual is a generic manual that covers all available single colour SmartLIGHTS
in the range
Contents:
Page 3 – 6 Product Safety and Installation instructions
Page 7 – 9 SmartLIGHT Product layout
Page 10 – 11 SmartLIGHT Operation and functions
Page 12 – 13 SmartLIGHT DMX Operation
SmartLIGHT User Manual Page 11
D X
The fi ture is equipped with 3-pin XLR connectors for DMX input and output. The SE
connectors are wired in parallel. Only use a shielded twisted-pair cable designed for 3-pin XLR-
plugs and connectors in order to connect the controller with the fi ture or one fi ture with
another.
Building a serial DMX-chain:
Caution: At the last fi ture, the DMX-cable has to end with a terminator. Solder a 120 Ohm
resistor between PIN 2 (-) and PIN 3 (+) into a 3-pin XLR-plug and plug it in the DMX-output
of the last fi ture.

SmartLIGHT User Manual Page 10
ASTER/SLAVE:
If you have more than one unit you wish to operate the same but do not have a DMX
controller or foot controller then you can do so in the following simple way: Connect a 3 pin
DMX XLR cable from the DMX OUT socket on the master unit and plug in to the DMX IN socket
on the slave device. Then set the Slave device to DMX address to be A001 and it will repeat
whatever operation is current on the master unit. This can be repeated for up to 32 fi tures.
D X OPERATIONS:
Channel Function
1
000-007 Closed
008-190 Dimming 0-100%
191-200 Sound to light pulse
196-200 Sound to light strobe
201-247 Strobe
248-255 Open 100%
SmartLIGHT User Manual Page 3
PACKAGE CONTENTS:
Please check the contents to ensure that the product has been received in good
condition.
SmartLIGHT Bo :
SmartLIGHT Unit 1pcs User’s Guide 1pcs
Power Cord 2pcs (EU and UK)
Mounting brackets 2pcs
If you find any accessory is missing or the product has arrived with any problems,
please contact your local dealer at once. Do not try to fi this item yourself or you
will lose the warranty. Please keep the original package and invoice for any possible
replacement or returned demand.
INSTALLATION:
Every person involved with the installation, operation and maintenance of this device
should be qualified and follow the instructions in this User Guide. We recommend
that this product should be used within the guidelines of “HSG95”. When you connect
to the main power supply the device will take a few seconds before ready for use.
OUNTING INSTRUCTIONS:
The mounting brackets are already attached to the product when you open the bo
but you can adjust them giving more clearance. You can use them as floor standing
or you can fi a G-Clamp to the bracket securely ready for mounting. After finding
the desired position tighten the G-Clamp and use a safety wire the security loop for
e tra security.
When selecting an installation location, take into consideration routine maintenance.
Safety cables must always be used. Never mount in places where the fi ture will be
e posed to rain, high humidity, e treme temperatures changes or restricted
ventilation.

SmartLIGHT User Manual Page 4
CAUTION! TO PREVENT ORTAL ELECTRICAL RISK AND LONG LIFE OPERATION:
For your safety, please kindly pay attention to all of the warnings listed below:
Always plug in the power plug last and disconnect from the mains, when the
device is not in use or before cleaning.
Do not install and operate the device in rain or e treme heat, moisture or dusty
environments.
This device is for indoor use only and in a dry environment.
Do not switch on immediately but wait until it reaches to room temperature, if
the device has been e posed to drastic temperature fluctuations.
Do not shake the device and avoid brute force when installing or operating.
Do not spread a fog or bubble effect machine directly at the device.
Do not use the device during thunderstorms. Disconnect the power.
Do not use solvents or aggressive detergent to clean the device. Use a soft and
clean cloth.
Do not modify the device or the power cord in anyway.
Use appropriate safety-rope for added safety.
Do not stare to the light.
The symbol determines the minimum distance from lighted objects. The
minimum distance between light-output and the illuminated surface must be
more than 0.5m.
SmartLIGHT User Manual Page 9
CONTROL DISPLAY:
1. MODE\ESC: Menu or withdraw the last menu
2. UP: Increase one step each time
3. DOWN: Decrease one step each time
4. ENTER: Confirms the functions you select
*Note the display will turn off if no activity for 20 seconds.
PRI ARY FUNCTION:
LED Display Action
A001 - A512 DMX-512 Address from 1 to 512
Er_L If there is a breakdown in the DMX connection
AUT0 Auto Fade in and fade out
SOU1 Sound to light strobe
SOU2 Sound to light pulse strobe
L 25 Brightness = 25% of full potential
L 50 Brightness = 50% of full potential
L 75 Brightness = 75% of full potential
L100 Brightness = 100% of full potential

SmartLIGHT User Manual Page 8
REAR LAYOUT:
1. DMX IN
2. DMX OUT
3. Sound sensitivity
4. Microphone
5. IEC Power OUT
6. IEC Power IN (Fuse F1A and F3A for SL-Q12)
SmartLIGHT User Manual Page 5
CONNECT WITH POWER SUPPLY – THE GROUND WIRE UST BE CONNECTED:
Use the IEC plug to connect to the main power supply as follows:
Wire Connection International signal
Brown Live L
Blue Neutral N
Yellow /Cyan Earth
QUICK TROUBLE SHOOTING
If the unit is not functioning properly follow the below guidelines
Check the IEC cable is fitted correctly.
Check the fuse hasn’t blown in both the IEC cable and unit (see below)
Check any DMX cables are connected correctly
Check the DMX address has been set correctly
Check the operating mode of the device (see later on in this manual)
If the unit still fails to respond then contact your retailer. DO NOT ATTEMPT TO
REPAIR YOURSELF.
REPLACING FUSE
First disconnect from the main power supply then remove the fuse holder above the
IEC Socket to reveal the fuse. Replace with the correct fuse rating as stated on the
product safety label. Then lock the fuse holder cover back into place.

SmartLIGHT User Manual Page 6
GENERAL AINTENANCE
To maintain optimum performance and minimise wear, fi tures should be cleaned
frequently. Usage and environment are contributing factors in determining frequency.
As a general rule, fi tures should be cleaned at least twice a month. Dust build-up
reduces light output performance and can cause overheating. This can lead to
reduced life and increased mechanical wear. Be sure to power off the fi ture before
conducting maintenance.
Unplug fi ture from the mains and use a vacuum or air compressor and a soft brush
to remove dust collected on e ternal vents and internal components. Clean all glass
and Perspe when fi ture is cold with a mild cleaning solution to the cloth or tissue,
and drag dirt and grime to the outside of the lens. Gently polish optical surface until
they free of haze and lint.
The cleaning of e ternal optical lenses must be carried out periodically to optimise
light output. Cleaning frequently depends on the environment in which the fi ture
operates: damp, smoky or particularly dirty surroundings can require cleaning fluid.
Always dry the parts carefully. Clean the e ternal optics at least every 20 days.
SmartLIGHT User Manual Page 7
FRONT LAYOUT GENERAL:
1. LED Output
2. Secondary bracket
3. Mounting point for G-Clamp
4. Secondary mounting points for more clearance
5. Thumb screw to hold brackets in place
6. Primary bracket
